| . . | 2436U1240F1 | [1] | SOLENOID VALVE | KOBASSY. CONSISTS OF FOLLOWING PARTS 1 TO 12 |
| . . | 2436U1240F2 | [1] | VALVE ASSY, SOLENOID CONSISTS OF FOLLOWING PARTS 1 TO 12 | VALVE ASSY, SOLENOID CONSISTS OF FOLLOWING PARTS 1 TO 12 |
| . . | 2436U1240F3 | [1] | VALVE ASSY, SOLENOID CONSISTS OF FOLLOWING PARTS 1 TO 12 | VALVE ASSY, SOLENOID CONSISTS OF FOLLOWING PARTS 1 TO 12 |
| 1. | 2436U1240S1 | [1] | HOUSING,FOR F1-F3 ONLY | |
| 2. | ZD12P01500 | [6] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm, FOR F1-F3 Only |
| 4. | 2436U1240S4 | [1] | SPOOL | KOBFOR F1 ONLY |
| 5. | 2436U1240S5 | [2] | SPOOL FOR F1,F3 ONLY | SPOOL FOR F1,F3 ONLY |
| 6. | 2436R688S321 | [3] | SPRING FOR F1-F3 ONLY | SPRING FOR F1-F3 ONLY |
| 7. | 2436U1159S7 | [1] | COVER,FOR F1-F3 ONLY | |
| 8. | ZS23C04010 | [8] | SCREW,Hex Socket Head, M4 x 10mm | KOBM04x0.7x10mm, FOR F1-F3 Only |
| 9. | 2436U1159S9 | [3] | SOLENOID VALVE | KOBFOR F1-F3 ONLY |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE,FOR F1-F3 ONLY |
| 11. | 2436U1170S14 | [2] | PIN | KOBPIN,FOR F1-F3 ONLY |
| 12. | 2436U1240S12 | [1] | SPOOL FOR F3 ONLY | SPOOL FOR F3 ONLY |
