| . . | 24100N2364F2 | [1] | GRAPPLE ASSY,FORK(SINGLE) | |
| 4. | 2406T1639 | [1] | LINK,IDLER | |
| 5. | 2406T1638 | [1] | LINK,IDLER | |
| 7. | 2419T3333 | [1] | PIN | |
| 10. | ZN17C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 11. | ZS13C12130 | [2] | SCREW | KOBM12x1.75x130mm Superseded by part number: ZS18C12130 |
| 12. | 2445Z869 | [4] | O-RING,9mm Thk x 115mm ID | KOBID 115 ± 0.40 x OD 133mm |
| 13. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 14. | 2445R138D3 | [4] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 15. | 2445R220D2 | [2] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| 17. | 2419P1564D1 | [1] | PIN | KOB |
| 19. | 24100J4211D2F1 | [1] | GRIP (UPP) | |
| 19-15. | 2405T869 | [4] | BUSHING | KOB |
| 20. | 24100J4210D2 | [1] | GRIP (LOW) | |
| 21. | 2406N775F1 | [1] | LINK,BUCKET | |
| 21-6. | 2405T825 | [2] | BUSHING | KOBID 65 x OD 80 x 60mm Long |
| 21-7. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 22. | 2419P1643 | [1] | PIN | KOB |
| 23. | 2419P1643D2 | [1] | PIN | |
| 24. | ZN12C14011 | [4] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 25. | ZS13C14120 | [2] | SCREW | KOBM14x2.0x120mm Superseded by part number: ZS18C14120 |
