| . . | 24100J6276F1 | [1] | INSTAL,HYDR LINES,ARM 2.5 M(8 FT-2 IN)(CHANGE BACKHOE/CLAMSHELL) | |
| 1. | 2418T12742 | [1] | TUBE | |
| 2. | 2418T12743 | [1] | TUBE | |
| 3. | 2418T12741 | [1] | TUBE | |
| 4. | 2418P12047D1 | [1] | TUBE | |
| 5. | 2418T12744 | [1] | TUBE | |
| 6. | 2418T12745 | [1] | TUBE | |
| 7. | 24100P1005F1 | [1] | VALVE | KOB Superseded by part number: 24100P1005F3 |
| 7-1. | 2436P229 | [1] | VALVE BODY | KOB |
| 7-2. | 2436T303 | [1] | VALVE | KOB |
| 7-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 7-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 7-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 7-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 7-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 7-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 7-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 7-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 8. | 2418T12747 | [1] | PLATE | |
| 9. | 2418T10388 | [2] | COLLAR | COLLAR |
| 10. | ZX58N10064 | [2] | HOSE | |
| 11. | 2420T4381 | [1] | U-BOLT | |
| 12. | 2416T9804 | [4] | BLOCK | KOBTapped -- 70x38x16mm |
| 13. | ZC26X22011 | [5] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 14. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 15. | ZA23H22012 | [2] | HYD CONNECTOR | KOB |
| 16. | ZA53B22000 | [1] | TEE | KOB |
| 17. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 18. | ZS13C08038 | [2] | SCREW | KOBM08x1.25x38mm Superseded by part number: ZS18C08040 |
| 19. | ZS13C10045 | [5] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 20. | ZN12C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 21. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 22. | ZW22X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 23. | 2444Z2221 | [2] | CONNECTOR | CONNECTOR |
| 24. | 2420T4383 | [2] | PLUG | PLUG |
