| . . | 24100N3999F2 | [1] | REWORK,HYDR LINES(WITH BOOM SAFETY)(FOR SWEDEN), Serial Range: YP0301--YP0378 | |
| . . | 24100N3999F4 | [1] | REWORK,HYDR LINES YP0379- to | |
| 1. | 2444Z2333 | [2] | TEE | KOB, Serial Range: YP0301--YP0378 |
| . . | 2444Z2333 | [1] | TEE | KOBYP0379- to |
| 2. | 2420R537D150 | [1] | FLEXIBLE HOSE,9.60mm ID x 1500mm L | KOB3/8" PF, 1500mm Long (59-1/16 in), Serial Range: YP0301--YP0378 Superseded by part number: HX21E06150DX |
| 3. | 2418P12215 | [1] | RIGID TUBE | KOB |
| 4. | 2416P8664 | [1] | SUPPORT | KOB |
| 5. | 2416P8663 | [1] | FLANGE | KOBSUPPORT |
| 6. | 2432T2340 | [2] | CLAMP | KOB |
| 7. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| 8. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 9. | 2418P12216 | [1] | TUBE | |
| 10. | ZX15K08140 | [1] | TUBE, NYLON TUBE,NYLON | TUBE, NYLON TUBE,NYLON |
| 12. | 2418P12217 | [1] | TUBE | |
| 14. | 24100J6239F7 | [1] | HYDR LINES,UPP,SEE (04-001), Serial Range: YP0301--YP0378 | |
| 15. | ZH21M08006 | [1] | HYD CONNECTOR | KOB |
| 16. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006, Serial Range: YP0301--YP0378 |
| 17. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006), Serial Range: YP0301--YP0378 |
| 18. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 YP0379- to |
| 19. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) YP0379- to |
| 20. | ZH42X04006 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB45° -- 1/4"PFx3/8"PFx53.5mm Long (Incls. O-Ring 237-6006) YP0379- to |
| 22. | 24100J6239F13 | [1] | HYDR LINES,UPP,REF:P.221-01 YP0379- to | |
