| . . | 2438U909F1 | [1] | CYLINDER ASSY (ARM) | CYLINDER ASSY (ARM) |
| 1. | 2438U699S1 | [1] | TUBE,CYLINDER | |
| 2. | 2438U287S4 | [2] | BUSHING | KOB |
| 3. | 2445R138D2 | [4] | SEAL,55mm ID x 70mm OD x 4mm Thk | KOBDUST |
| 4. | 2438U909S4 | [1] | ROD, PISTON | ROD, PISTON |
| 5. | 2438U909S5 | [1] | PISTON | |
| 6. | R45T0098D4 | [2] | PISTON RING | KOBRING,WEAR |
| 7. | R45P0049D9 | [1] | SEAL | KOB |
| 8. | R45P0051D14 | [1] | O-RING | KOB |
| 9. | ZD12G07000 | [1] | O-RING,69.40mm ID x 75.60mm OD x 3.10mm | KOBID 69.40 ± 0.61 x OD 75mm |
| 10. | 2438U695S10 | [1] | NUT,PISTON | |
| 11. | 2438U695S11 | [1] | RING | KOB |
| 12. | 2438U909S12 | [1] | COVER,ROD | |
| 13. | B38K0039E6 | [1] | LOCK WASHER | |
| 14. | ZD12P12500 | [1] | O-RING | KOB |
| 15. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 16. | B38K0025E9 | [1] | BUSHING | KOB Superseded by part number: 2405U104D7040 |
| 17. | B38K0040E9 | [1] | SNAP RING | KOB Superseded by part number: B38K0033E15 |
| 18. | R45P0050D1 | [1] | SEAL | KOB |
| 19. | 45Z91D17 | [1] | O-RING | KOB |
| 20. | 2438U796S8 | [1] | PACKING,ROD | |
| 21. | 2438U697S15 | [1] | SEAL,DUST | |
| 22. | B38K0025E10 | [1] | SNAP RING | KOB |
| . . | 2438U909R100 | [1] | REPAIR KIT,CONSISTS OF REF 14,15,18-21 | |
| . . | 2438U909R200 | [1] | REPAIR KIT,CONSISTS OF REF 6-9 | |
