| . . | 2436U881F1 | [1] | JOINT, SWIVEL ASSY | JOINT, SWIVEL ASSY |
| . . | 2436U881F2 | [1] | JOINT, SWIVEL ASSY | JOINT, SWIVEL ASSY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSTEM,(FOR F1 ONLY) |
| 3. | 2436P256 | [1] | PLATE | KOBPLATE |
| 4. | 2436P251 | [1] | COVER,(FOR F1 ONLY) | |
| 5. | 2445Z736 | [5] | GASKET | KOBSEAL ASSY |
| 6. | 2445R152D1 | [2] | O-RING,5.7mm Thk x 79.6mm ID, 70 Duro | KOBID 79.6 ± 0.40 x OD 91mm |
| 7. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOBID 94.40 ± 0.81 x OD 100mm |
| 8. | ZS23C08020 | [2] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 9. | ZS23C08030 | [3] | SCREW,Hex Socket Head, M8 x 30mm | KOBM08x1.25x30mm Superseded by part number: ZS28C08030 |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 11. | NSS | [2] | NOT SOLD SEPARAT | CONCLEVIS,(FOR F1 ONLY) |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONSTEM,(FOR F2 ONLY) |
| 13. | 2436P264 | [1] | COVER,(FOR F2 ONLY) | |
| 14. | NSS | [2] | NOT SOLD SEPARAT | CONCLEVIS,(FOR F2 ONLY) |
