| 1. | YN13E01509P1 | [1] | HARNESS | KOBHarness (Includes 5 - YN02D01001P1, Diodes) Date 03/30/2007 - 05/18/2007 Superseded by part number: YN13E01509P4 |
| 1. | YN13E01509P2 | [1] | WIRE HARNESS | KOBHarness (Includes 5 - YN02D01001P1, Diodes) Date 05/18/2007 - 12/31/2007 Superseded by part number: YN13E01509P4 |
| 1. | YN13E01509P3 | [1] | HARNESS | KOBHarness (Includes 5 - YN02D01001P1, Diodes) Date 12/31/2007 - 03/24/2008 Superseded by part number: YN13E01509P4 |
| 1. | YN13E01509P4 | [1] | HARNESS | KOBHarness (Includes 5 - YN02D01001P1, Diodes) Date 03/24/2008 - UP |
| 1-1. | YN13E01518P1 | [1] | HARNESS | KOB(Attaches to Upper Harness, Solenoid Valve Solenoids, Proportional Solenoids, Stepping Motor, Engine Stop Solenoid, Battery Relay) |
| 1-1. | YN13E01519P1 | [1] | HARNESS | KOB(Attaches to Controller, Upper Harness, Floor Harness, Fuse/Relay Box) |
| 1-2. | YN02D01001P1 | [5] | DIODE,3 Amp, 400V | KOB(Part of YN13E01509P1), Not Shown (Black) |
| 2. | YN13E01462P1 | [1] | CABLE,2670mm L | KOB |
| 7. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in) |
| 22. | EZ09H01066P1 | [2] | CLIP | KOBClamp, Double -- Ø32x93mm Long |
| 26. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 29. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOB(Incls. Washer) |
| 36. | LC13E01150P1 | [1] | PLATE | KOB |
| 39. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOB(Incls. Washer) |
