| 1. | YN54S00041P1 | [1] | RECEIVER-DRYER | SM Superseded by part number: LQ54S00005P1 |
| 2. | YN20M01469P1 | [1] | BRACKET | KOB |
| 3. | YT96V00001S009 | [2] | SCREW | KOBScrew -- M08x25mm Long |
| 4. | YT96V00001S010 | [2] | CAP | KOBScrew -- M06x25mm Long |
| 5. | YN20M01546F1 | [1] | TUBE | KOBHose, (Includes O-Ring 2445Z1604D5) |
| . . | 2445Z1604D5 | [1] | O-RING | KOB(Part of YN20M01546F1), 5/8 in, Not Shown |
| 6. | YN20M01644F1 | [1] | HOSE ASSY. | KOB(Includes O-Rings 2445Z1604D4) |
| . . | 2445Z1604D4 | [2] | O-RING | KOB(Part of YN20M01644F1), 1/2 in, Not Shown |
| 7. | YN20M01547F1 | [1] | FLEXIBLE HOSE | SML - Hose, (Includes O-Rings 2445Z1604D6) |
| . . | 2445Z1604D6 | [2] | O-RING | KOB(Part of YN20M01547F1), 08mm, Not Shown |
| 8. | YN20M01617F1 | [1] | FLEXIBLE HOSE | SM(Includes O-Rings 2445Z1604D6) |
| 9. | YN20M01582F1 | [1] | HOSE ASSY. | KOB(Includes O-Ring 2445Z1604D5) |
| 10. | YN20M01518F1 | [1] | RIGID TUBE | SML - Tube, (Incls. O-Ring 2445Z1604D6) |
| 11. | YN20M01675P1 | [1] | CONDENSER | SMSee Figure 02-66 |
| 12. | YN20M00107F2 | [1] | AIR CONDITIONER | SMAIR CONDITIONING See Figure 02-67 Superseded by part number: YT20M00022F4 |
| 13. | YX91V00001F1 | [1] | AIRCOND. COMPRESSOR,W/ Pulley | KOBSee Figure 02-69 |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBED195-8 BLADE RUNNER ACERA MARK 8 EXCAVATOR DOZER (TIER 3) ASN YL04U-0301 |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
