| 1. | YN03M01350F1 | [1] | CONTROL | KOBBox, Left Hand, Incls. Refs. 1-1 & 1-2 |
| 1-1. | 2405R312D1612 | [1] | BUSHING | KOBID 16 x OD 18 x 12mm Long Superseded by part number: 2405U101D1612 |
| 1-2. | 2405R312D2010 | [1] | BUSHING | KOBID 20 x OD 23 x 10mm Long |
| 2. | YM03MU1009P4 | [1] | Control Box, Right Hand | |
| 3. | YN03M01336P1 | [1] | LEVER | KOBIncls. Refs. 3-1 |
| 3-1. | YN03M01336P1002 | [1] | LEVER | KOBGrip Superseded by part number: YN03M01336P1 |
| 4. | YN03M01297P1 | [1] | SHAFT | KOB |
| 5. | YN03M01339P1 | [1] | ROD | KOB |
| 6. | YN03M01366P1 | [1] | PLATE | KOB |
| 7. | YN03M01347P1 | [1] | ROLLER | KOB |
| 8. | YN03M01333P1 | [1] | YOKE | KOB |
| 9. | YN03M01447P2 | [1] | PLATE | KOB |
| 10. | YT03M01117P1 | [2] | RUBBER | KOB |
| 11. | YT03M01105F1 | [1] | LOCK ASSY | KOB |
| 12. | PH03M01017P1 | [1] | SPRING | KOB |
| 13. | PY06C01040P1 | [1] | STOP | KOB |
| 14. | YN50S01001P1 | [1] | SWITCH | KOB(Used for Safety Lever Lock, Safety) Superseded by part number: YN50S01001P2 |
| 15. | ZP45X06020 | [1] | PIN | KOBOD 06 x 20mm Long |
| 16. | ZR36X00500 | [1] | SNAP RING | KOBE-Ring -- Shaft 05mm x OD 11mm Superseded by part number: 800-436 |
| 17. | ZR36X00700 | [1] | RING | KOBE-Ring -- Shaft 07mm x OD 14mm |
| 18. | ZR36X01200 | [1] | RING | KOBE-Ring -- Shaft 12mm x OD 23mm |
| 19. | ZR16X01600 | [1] | SNAP RING | KOBRetaining -- ID 14.7 x OD 16 x Th 1.0mm |
| 20. | ZS31C04045 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 45mm | KOB |
| 21. | ZM66C06020 | [2] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 22. | ZM12C08020 | [1] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) |
| 23. | ZM27C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 24. | ZW16K04000 | [4] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 25. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 26. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 27. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 28. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 29. | ZW26X04000 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 30. | ZN18F10008 | [1] | NUT | KOBM10x1.25mm |
| 31. | ZN18C04003 | [2] | NUT | KOBM04x0.7mm |
| 32. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 33. | ZN18C14011 | [1] | NUT | KOBM14x2.0mm |
| 34. | ZP16K01616 | [1] | COTTER PIN | KOBOD 1.6 x 16mm Long |
| 35. | ZW16X20000 | [1] | WASHER | KOBID 20 x OD 37 x Th 3.2mm |
| 36. | ZR16X02000 | [1] | RING | KOBRetaining -- ID 18.5 x OD 20 x Th 1.2mm |
| 37. | PM22C01020DK | [1] | TRIM PANEL | KOB250mm Long (9-27/32 in) |
