| 1. | YM21P01004P1 | [1] | FUEL HOSE,6mm ID x 2000mm L | KOB |
| 2. | YM21P01003P1 | [1] | FUEL HOSE,6mm ID x 2500mm L | KOB |
| 3. | YM21P01002P1 | [1] | FUEL HOSE,6mm ID x 2800mm L | KOB |
| 4. | YN21P01044P1 | [1] | FUEL HOSE,6mm ID x 2200mm L | KOB |
| 5. | YM21P01006P1 | [1] | FUEL HOSE,6mm ID x 2350mm L | KOB |
| 6. | ZC46X31014 | [1] | CLIP | KOBClamp -- Ø31mm Single Cable |
| 7. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 8. | ZW16H12000 | [1] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 9. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 10. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 11. | YM21P01013F1 | [1] | FILTER ASSY | SMFilter Assembly, Fuel (Incls. Filter Element & Sensor), Serial Range: -6 |
| 11-1. | 84337371 | [1] | FUEL FILTER | KOBKobelco (Part of YM21P01013F1), See Figure 01-01, Not Shown Superseded by part number: 84348882 |
| 11-1. | 87438159 | [1] | SENSOR | FARWater in Fuel (Part of YM21P01013F1), Not Shown |
| 12. | HX11Y04040DX | [1] | HOSE,6mm ID x 400mm L | KOBID 06 x OD 08 x 40mm Superseded by part number: 72280610 |
| 13. | YN21P01060P1 | [1] | PLUG | KOBNo service parts |
| 14. | PY01P01043D3 | [8] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 15. | YN13E01375P1 | [2] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 16. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 17. | LQ21P01005P1 | [4] | COUPLING,M14 x 1.5 x 12mm ID x 7mm ID | KOBQuick Disconnect -- M14x1.5x26mm Long (No O-Ring Supplied) |
