| 1. | 2420R349D017 | [1] | Hose -- 170mm Long (6-11/16 in) | |
| 2. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 3. | 2420R349D065 | [1] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in) Superseded by part number: HX21E04065DX |
| 4. | 2420R349D080 | [1] | HOSE,6.35mm ID x 800mm L | KOB800mm Long (31-1/2 in) |
| 5. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 6. | 2420R349D028 | [1] | HOSE,280.00 mm | KOB Superseded by part number: 2420R349D030 |
| 7. | 2444R1120D017 | [1] | HOSE | KOB170mm Long (6-11/16 in) |
| 8. | 2420R349D072 | [1] | FLEXIBLE HOSE | SM720mm Long (28-11/32 in) Superseded by part number: 24820R63D072 |
| 9. | 2444T2524 | [2] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| . . | ZD12P01100 | [1] | O-RING | KOB(Part of 2444T2524), ID 10.8mm x OD 13.2mm, Not Shown |
| 10. | 2444T2544 | [1] | ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 11. | 2444Z2294 | [6] | HYD CONNECTOR | KOB1/4" PF x 41mm Long (Incls. (2) O-Rings ZD12P01100) |
| 12. | HH55Q04004G1 | [3] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 13. | 2420R349D060 | [1] | HOSE,6.35mm ID x 700mm L | KOB600mm Long (23-5/8 in) |
| 14. | YN26V00001F2 | [6] | VALVE | KOB |
| 15. | ZH22X04000 | [8] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring 237-6004) |
| . . | 237-6004 | [1] | O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro | CAS(Part of ZH22X04000), SAE No. 4-1, Not Shown Superseded by part number: 165202, 72186131 |
| 17. | ZH32X04000 | [12] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 24. | YN68HU1002P1 | [1] | BLOCK | KOB132x44.45x44.45mm |
| 25. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 26. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 27. | ZW16X08000 | [5] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 28. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 29. | PY03M01026P1 | [1] | PIN | KOBM08x1.25x115mm Long |
| 30. | ZS28C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 31. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 32. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 34. | YN03M01319P1 | [1] | PEDAL | KOB |
| 35. | YN03M01266P2 | [1] | RUBBER SLEEVE | KOB |
| 37. | ZS18C08065 | [2] | SCREW,Hex, M8 x 65mm | KOBM08x1.25x65mm |
| 38. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 39. | YN30V00080F1 | [1] | VALVE | KOBSee Figure 08-18 |
| 40. | YT30M01005F1 | [1] | LOCK | KOBAssembly |
| 41. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
