| . . | 24100N2358F1 | [1] | INSTAL,HYDR LINES ARM 1.9 M (NIBBLER & BREAKER) | |
| 1. | 2418T10181 | [1] | TUBE | |
| 2. | 2418T8974 | [1] | TUBE | |
| 3. | 2444R873D1 | [1] | HOSE | |
| 4. | 2444R698D2 | [1] | HOSE | KOB |
| 5. | 2416T9825 | [2] | BRACKET | BRACKET |
| 6. | 2416T9823 | [1] | BRACKET | |
| 7. | 2416T9824 | [1] | BRACKET | |
| 8. | 2432T1686 | [1] | CLAMP | |
| 10. | 2420T4345 | [2] | PLUG | KOB |
| 11. | 2444Z2110 | [1] | CONNECTOR | CONNECTOR |
| 12. | ZD12P02240 | [4] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 13. | R44T0187 | [1] | CONNECTOR | CONNECTOR |
| 14. | 24100P1006F1 | [2] | VALVE | KOBSTOP Superseded by part number: 24100P1006F2 |
| 14-1. | 2436P230 | [1] | VALVE BODY | KOB |
| 14-2. | 2436T304 | [1] | VALVE | KOB |
| 14-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 14-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 14-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 14-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 14-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 14-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 14-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 14-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 14-11. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 15. | ZC26X28014 | [1] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 16. | ZC26X22011 | [1] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 17. | ZS13C08022 | [8] | SCREW | KOBM08x1.25x22mm Superseded by part number: ZS18C08022 |
| 18. | ZW22X08000 | [8] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 19. | ZS13C12050 | [1] | SCREW | KOBM12x1.75x50mm Superseded by part number: ZS18C12050 |
| 20. | ZW22X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 21. | ZS13C10040 | [1] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 22. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
