| . . | YY42H00090F1 | [1] | HYD, BOOM | |
| 1. | YX42H01056P1 | [1] | TUBE | KOB |
| 2. | YX42H01057P1 | [1] | TUBE | KOB |
| 3. | YX42H01058P1 | [1] | RIGID TUBE | KOB |
| 4. | YX42H01059P1 | [1] | TUBE | KOB |
| 5. | YX42H01054P1 | [1] | TUBE | KOB |
| 6. | YX42H01055P1 | [1] | TUBE | KOB |
| 7. | ZX22M08100 | [1] | HOSE | KOB |
| 8. | ZX23M06110 | [1] | HOSE | KOB |
| 9. | ZD12A01600 | [10] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 10. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 11. | YX42H01117P1 | [1] | GUIDE | KOB Superseded by part number: YX42H01117P2 |
| 12. | YX42H01129P1 | [2] | COVER | KOB |
| 13. | YX42H01027P1 | [1] | CLAMP | KOB |
| 14. | YX42H01028P1 | [2] | CLAMP | KOB |
| 15. | YX42H01029P1 | [1] | CLAMP | KOB |
| 16. | YX42H01030P1 | [2] | CLAMP | KOB |
| 17. | YX42H01033P1 | [1] | GROMMET | KOB |
| 18. | YY42H01163P3 | [1] | RUBBER | KOB Superseded by part number: YX42H01132P1 |
| 19. | YX42H01069P2 | [1] | PLATE | KOB |
| 20. | YY42H01164P1 | [1] | BLOCK | KOB |
| 21. | LF42H01009P1 | [1] | BRACKET | KOB |
| 22. | YR42H01023P1 | [2] | SPACER | KOB |
| 23. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 24. | 2444R402D4 | [3] | HYD CONNECTOR | HIT(Incls. O-Ring ZD12P01400) |
| 25. | HH25R06006G1 | [1] | HYD CONNECTOR | KOB3/8" PF x 40mm Long (Incls. O-Ring ZD12P01400) |
| 26. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 27. | 2444R399D9 | [1] | HYD CONNECTOR | KOBElbow -- (Incls. O-Ring ZD12P01400) |
| 28. | 2414Z199D050 | [1] | PROTECTIVE SLEEVE | KOBHose -- 500mm Long (19-11/16 in) |
| 29. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 30. | ZS18C10016 | [1] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 31. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 32. | ZS18C10040 | [4] | SCREW,Hex, M10 x 40mm | KOBM10x1.50x40mm |
| 33. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| 34. | ZS18C10075 | [2] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 35. | ZS18C10085 | [1] | SCREW,Hex, M10 x 85mm | KOBM10x1.50x85mm |
| 36. | ZS28C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 37. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 38. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 39. | ZW26K10000 | [2] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 40. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 41. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 42. | YX42H01130P1 | [1] | WASHER | KOB |
| 43. | B16T0442D71 | [2] | SHIM,60mm OD x 37mm ID x 1.6mm Thk | KOBID 37 x OD 60 x Th 1.6mm |
| 44. | ZC46X46014 | [1] | CLIP | KOBClamp -- Ø46mm Single Cable |
| 45. | YX03H01046P1 | [1] | CLIP | KOBWire, Tie -- 564mm Long (22-13/64 in) |
| 46. | YX13E01012P1 | [1] | GROMMET | KOB |
