| E1. | YY05B00006P2 | [1] | BOOM | KOBUPP |
| E1-11. | YX05B01020P1 | [1] | BLOCK | KOB |
| E1-12. | YX05B01034P1 | [1] | BLOCK | KOB |
| E1-13. | YX05B01040P1 | [2] | BLOCK | KOB |
| . . | YY02B00148F1 | [1] | BOOM GROUP | |
| F1. | YX02B01019P1 | [2] | PIN | KOB |
| F2. | YX02B01020P1 | [2] | PIN | KOB |
| F3. | YX02B01022P2 | [1] | COVER | KOB |
| F4. | YY02B01067P1 | [1] | SUPPORT | KOB |
| F5. | YX02B01028P1 | [1] | SUPPORT | KOB |
| F6. | ZC26X15009 | [1] | CLAMP | KOB |
| F7. | ZS18C08040 | [1] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| F8. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| F9. | HS18C14130G1 | [4] | CAPSCREW,M14 x 130mm, Cl 10.9 | KOBSCREW M14x2.0x130mm |
| F10. | ZM32C10025 | [5] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| F11. | ZM32C12030 | [1] | BOLT | KOBM12x1.75x30mm (Incls. Washer & Lockwasher) |
| F12. | ZN18C14011 | [8] | NUT | KOBM14x2.0mm |
| F13. | ZW26X08000 | [1] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| F14. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| F15. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| F16. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| F17. | ZG91V02000 | [8] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| F18. | 2445R138D6 | [10] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| F19. | B16T0442D1 | [8] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| F20. | YR02B01277P1 | [5] | BACK-UP RING | KOB |
| F21. | YR02B01278P1 | [4] | RUBBER SLEEVE | KOB |
| F22. | YR02B01279P1 | [1] | GASKET | KOB |
| F23. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| F24. | 2444R1117D070 | [1] | HOSE,6.40mm ID x 700mm L | KOB700mm Long (27-1/2 in) |
| F25. | 2444R1117D074 | [1] | HOSE,6.40mm ID x 740mm L | KOB740mm Long (29-1/8 in) |
| F26. | 2444R1117D195 | [2] | HOSE,6.40mm ID x 1950mm L | KOB Superseded by part number: HX21E04195DY |
| F27. | 2444R1117D060 | [1] | HOSE,6.40mm ID x 600mm L | KOB600mm Long (23-5/8 in) |
| F28. | PY01P01043D2 | [5] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
