| . . | YY64H00139F1 | [1] | CONTROL, VALVE | |
| 1. | YY64H01119P1 | [1] | | |
| 2. | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 3. | YY35V00015F1 | [1] | VALVE, SOLENOID | |
| 4. | LC52S00011P1 | [2] | SENSOR | KOBPressure (Low Pressure) (Incls. O-Ring ZD12P01100) Superseded by part number: LC52S00019P1 |
| 4-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 5. | YX64H01036P1 | [1] | | |
| 6. | HH25X06006GA | [2] | HYD CONNECTOR | KOB3/8"PFx3/8"PFx37.5mm Long (Incls. O-Ring ZD12P01400) |
| 7. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 8. | YW06H01005P1 | [1] | | |
| 9. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 10. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 11. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 12. | ZX23M06080 | [1] | HOSE ASSY. | KOB |
| 13. | ZX23M06135 | [1] | | |
| 14. | PU13E01010D4 | [1] | TUBE | KOB |
| 15. | 2418Z1333D38 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 700mm Length | KOBProtective Plastic |
| 16. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| 17. | 2420R537D080 | [1] | HOSE,9.60mm ID x 800mm L | KOB |
| 18. | ZX23M04036 | [1] | | |
| 19. | YN21V00005F2 | [1] | CHECK VALVE | KOBCheck, PF 3/8, (Incls. O-Ring ZD12P01400) |
| 20. | PY01P01043D5 | [4] | CABLE TIE,301mm L | KOBWire Ties -- 292mm Long |
| 21. | 2432R233D3 | [1] | CLIP | KOB50x16x60mm |
| 22. | ZS18C08075 | [4] | SCREW,Hex, M8 x 75mm | KOBM08x1.25x75mm |
| 23. | ZW16P08000 | [4] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 24. | ZS18C12030 | [3] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 25. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 26. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 27. | ZW16H12000 | [3] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 28. | YX64H01041P1 | [2] | TEE | KOB Superseded by part number: YN06H01046P1 |
| 29. | 2444Z2894 | [2] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 30. | YY13E01159P1 | [1] | | |
| 31. | YY13E01158P1 | [1] | | |
| 32. | 2418Z1333D32 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 650mm Length | KOBProtective Plastic |
| 33. | 2418Z1333D24 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1200mm Length | KOBProtective Plastic |
