Pos.	Part No	Qty	Parts name	Comments
1.	YB03H01052P1	[1]	RIGID TUBE	KOBTUBE
2.	YB03H01016P1	[1]	TUBE	KOB
3.	YB03H01049D1	[1]	HOSE	KOBHOSE
4.	YB03H01032D1	[1]	HOSE	KOBHOSE
5.	2444T2682	[1]	HYD CONNECTOR	KOBCONNECTOR
5-1.	ZD12P02400	[1]	O-RING	KOBID 23.70 ± 0.24 x OD 30mm
6.	HG23H12012G1	[1]	HYD CONNECTOR	KOB(Incls. O-Ring ZD12P02400)
6-1.	ZD12P02400	[1]	O-RING	KOBID 23.70 ± 0.24 x OD 30mm
7.	24100P2599F2	[1]	VALVE PRESSURE RELIE	KOB
7-11.	LS30V01001P1	[1]	BODY, VALVE
7-12.	YF30V01007P1	[1]	SHAFT
7-13.	YZ30V01002P1	[1]	SPACER	KOBSPACER
7-14.	ZR16X06000	[1]	RING	KOB
7-15.	ZS28C06010	[1]	CAPSCREW,Hex Socket Head, M6 x 10mm	KOBSCREW M06x1.0x10mm
7-16.	ZD12P05090	[1]	O-RING	KOBO-RING
7-17.	ZD12P06000	[1]	O-RING	KOB
7-18.	ZD11G06000	[2]	O-RING,59.40mm ID x 65.60mm OD x 3.10mm	KOBID 59.40 ± 0.61 x OD 65mm
7-19.	ZD85P05090	[1]	BACK-UP RING	KOBRING, BACK UP
7-20.	ZD85P06000	[1]	BACK-UP RING	KOBRING, BACK UP
8.	ZG33F12012	[1]	90 ELBOW,1 3/16"-12 UN x PF 3/4"	KOB90° -- 1-3/16" -12UN x 3/4" PF (Incls. O-Ring ZD12P02400)
8-1.	ZD12P02400	[1]	O-RING	KOBID 23.70 ± 0.24 x OD 30mm
9.	ZD12P03400	[4]	O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro	KOBID 33.70 ± 0.33 x OD 40mm
10.	ZE13X16000	[4]	FLANGE	KOBClamp, Half -- (Incls. Capscrew & Lockwasher)
11.	HH35X16016G1	[1]	90 ELBOW	KOB90° -- (Incls. O-Ring ZD12P02900)
11-1.	ZD12P02900	[1]	O-RING	KOBID 28.70 ± 0.29 x OD 35mm
12.	YB03H01060P1	[1]	U-BRACKET	KOBBRACKET
13.	YB03H01051P1	[1]	SUPPORT	KOBSUPPORT
14.	YB03H01046P1	[1]	CLAMP	KOBCLAMP
15.	ZS18C10030	[4]	SCREW,Hex, M10 x 30mm	KOBM10x1.50x30mm
16.	ZS18C12030	[5]	SCREW,Hex, M12 x 30mm	KOBM12x1.75x30mm
17.	ZS18C12085	[2]	SCREW,Hex, M12 x 85mm	KOBM12x1.75x85mm
18.	ZW16H10000	[4]	WASHER	KOBID 11 x OD 24 x Th 3.2mm
19.	ZW16H12000	[9]	WASHER	KOBID 13 x OD 26 x Th 3.2mm
20.	ZN18C12010	[2]	NUT	KOBM12x1.75mm
21.	ZD12A01800	[2]	O-RING,1.78mm Thk x 18.77mm ID, Cl 6	KOBID 18.77 ± 0.12 x OD 22.33mm
22.	ZD12A02100	[2]	O-RING	KOBID 23.52 ± 0.15 x OD 27.08mm
23.	ZS28C12070	[4]	CAPSCREW,Hex Socket Head, M12 x 70mm	KOBSCREW M12x1.75x70mm
24.	ZS28C12040	[8]	SCREW,Hex Socket Head, M12 x 40mm	KOBM12x1.75x40mm
25.	ZW26K12000	[12]	LOCK WASHER	KOBID 12 x OD 17.8 x Th 2.5mm
26.	ZA33F18008	[3]	ELBOW	KOB
27.	ZD12P01800	[8]	O-RING	KOBID 17.8mm x OD 20.2mm
28.	YT03H01038D4	[1]	HOSE	KOB Superseded by part number: YT03H01080D4
29.	ZE72X04000	[1]	PLUG	KOB(PF 1/4) (Incls. O-Ring ZD12P01100)
30.	2444Z3713	[2]	HYD CONNECTOR	KOB(Incls. O-Ring ZD12P01800)
30-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
31.	HH55Q08008G3	[3]	TEE,PF 1/2" x PF 1/2", O-Ring	KOB(PF 1/2) (Incls. O-Ring ZD12P01800)
31-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
32.	HH25R08004G1	[1]	HYD CONNECTOR	KOB1/4"PFx1/2"PFx36mm Long (Incls. O-Ring ZD12P01800)
33.	ZS18C08025	[4]	SCREW,Hex, M8 x 25mm	KOBM08x1.25x25mm
34.	ZW16H08000	[4]	WASHER	KOBID 08 x OD 18 x Th 3.2mm
35.	ZX25M08150	[2]	HOSE ASSY.	KOB
36.	ZA23H18008	[2]	HYD CONNECTOR	KOB
37.	ZH32X08000	[4]	90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring	KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800)
37-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
38.	YB03H01020P1	[1]	BLOCK	KOBBLOCK
39.	HH25V08008G1	[1]	HYD CONNECTOR	KOBCONNECTOR
40.	YM30H01008P1	[1]	FLANGE	KOBFLANGE
41.	ZS28C10045	[4]	SCREW,Hex Socket Head, M10 x 45mm	KOBM10x1.50x45mm
42.	ZW26K10000	[4]	LOCK WASHER	KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679
43.	2444T2958	[3]	HYD CONNECTOR	KOB(Incls. O-Ring ZD12P01800)
43-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
44.	2414Z199D100	[2]	PROTECTIVE SLEEVE	KOBHose -- 1000mm Long (39-3/8 in)
45.	ZA23F18008	[3]	HYD CONNECTOR	KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied)
46.	YN03H01473D1	[2]	HOSE	KOBHOSE
47.	PH32H01006P1	[1]	HYD CONNECTOR	KOB
47-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
48.	YB03H01053P1	[1]	TUBE	KOBTUBE
49.	ZH22X08000	[1]	HYD CONNECTOR	KOB(Incls. O-Ring ZD12P01800)
50.	YY20V00003F1	[1]	VALVE	KOB
51.	ZH22X04006	[1]	HYD CONNECTOR	KOB(Incls. O-Ring 237-6006)
52.	2444Z3715	[1]	90 ELBOW	KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800)
52-1.	ZD12P01800	[1]	O-RING	KOBID 17.8mm x OD 20.2mm
55.	LC52S00012P1	[1]	SENSOR	KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1
55.	LS52S00015P1	[2]	SENSOR	KOB(New part #) (Added by SB S030-41-K003)
55-0.	YY52S00033F1	[1]	PRESSURE SWITCH	KOBKit Includes Ref 55 - 55-3 (Refer to SB S030-41-K003)
55-1.	LS30H01024P1	[1]	HYD CONNECTOR	SM(Added with new part # press switch)
55-2.	ZD12P01400	[1]	O-RING	KOBID 13.80 ± 0.19 x OD 18mm
55-3.	YT42H01128P1	[1]	90 ELBOW	KOB(Added with new part # press switch)
56.	2444T2544	[1]	ELBOW	KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100)
56-1.	ZD12P01100	[1]	O-RING	KOBID 10.8mm x OD 13.2mm
57.	HH35R04006G1	[1]	ELBOW, 90
