神钢零件查询(NIBBLER) - BREAKER & EXTRA ATTACHMENTS - SK220 ASN LQU0001 & SK200LC ASN LLU0601 (1/91-12/97) (04-002[01]) - BOOM ASSY 6.02M (19FT-8IN) (EXTRA & BREAKER BOOM SAFETY) Kobelco

作者：广数供应链运营团队
浏览数：
时间：2025-01-23 09:39:27
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos.Part NoQtyParts nameComments
. . 24100J15277F3 [1]  BOOM ASSY, 6. 02M
2. 2438U1135F1 [1]  CYLINDER KOB
3. 2438U1136F1 [1]  CYLINDER KOB Superseded by part number: 2438U1135F1
4. 2438U1137F1 [1]  CYLINDER KOB Superseded by part number: 2438U1137F2
5. 2418P26610 [1]  RIGID TUBE KOBTUBE Superseded by part number: 2418P22190
6. 2418P27923 [1]  TUBE KOB
7. 2418P26612 [1]  RIGID TUBE KOB Superseded by part number: 2418P22527
8. 2418P26613 [1]  REPAIR KIT KOB
9. 2418P26614 [2]  RIGID TUBE KOBTUBE Superseded by part number: 2418P22189
10. 2418P22188 [1]  RIGID TUBE KOB
11. 2444R1176D1 [1]  FLEXIBLE HOSE KOB940mm Long (37 in), Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1090D1
12. 2418P22194D1 [1]  RIGID TUBE KOB
13. 2418P22194D2 [1]  TUBE KOB
14. 2444R2522D1 [1]  FLEXIBLE HOSE KOB900mm Long (35-7/16 in)
15. ZS23C12040 [4]  SCREW,Hex Socket Head, M12 x 40mm KOBM12x1.75x40mm
16. 2444R1177D2 [2]  FLEXIBLE HOSE KOB940mm Long (37 in)
17. 2444R1090D1 [3]  HOSE KOB, Serial Range: LLU00703-LLU00829
18. ZX26T12080 [2]  FLEXIBLE HOSE KOBHOSE, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1177D1
18. 2444R1177D1 [2]  FLEXIBLE HOSE KOB800mm Long (31-1/2 in) LLU00830 to
19. 2444R1171D1 [2]  HOSE KOB800mm Long (31-1/2 in)
20. ZX26T16080 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1175D1
20. 2444R1175D1 [1]  HOSE KOB800mm Long (31-1/2 in) LLU00830 to
21. 2420R1187D325 [1]  HOSE  HOSE
22. 2420R1187D265 [1]  HOSE  HOSE
23. 2420R1187D094 [2]  HOSE  HOSE
24. ZF23B28000 [2]  HYD CONNECTOR KOB Superseded by part number: 47641651
25. ZH22Z04000 [3]  HYD CONNECTOR KOB1/4"PTx1/4"PFx37mm Long
26. ZW22K12000 [4]  LOCK WASHER KOBID 12.2 x OD 17.8 x Th 2.5mm
27. ZG91S02000 [9]  LUBE NIPPLE,1/8" NPT x 1/8" NPT KOB1/8" PT -- Straight
28. ZH32Z04000 [2]  ELBOW KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100)
29. 2432T2434 [6]  CLAMP KOBDouble Line -- 129x38x15mm (Ø29xØ36mm)
30. ZC26X28014 [4]  CLAMP KOBSingle Line -- 75x37x38mm (Ø28mm)
31. ZE13X16000 [2]  FLANGE KOBClamp, Half -- (Incls. Capscrew & Lockwasher)
32. 2432T2363 [1]  CLAMP KOB Superseded by part number: YN42H01078P1
33. ZS13C10020 [1]  SCREW KOBM10x1.50x20mm Superseded by part number: ZS18C10020
34. ZS13C10070 [16]  SCREW KOBM10x1.50x70mm Superseded by part number: ZS18C10070
35. ZS13C12055 [12]  SCREW KOBM12x1.75x55mm Superseded by part number: ZS18C12055
36. ZS13C12065 [1]  SCREW KOB Superseded by part number: ZS18C12065
37. ZS13C12090 [4]  SCREW KOBM12x1.75x90mm Superseded by part number: ZS18C12090
38. ZS13C14030 [2]  SCREW KOBM14x2.0x30mm Superseded by part number: ZS18C14030
39. ZS13C16030 [2]  SCREW KOBM16x2.0x30mm
40. 2420T4330D2 [1]  SCREW,M16 x 2 x 150mm KOBM16x2.0x150mm Superseded by part number: HS18C16150G1
41. 2420T4330D3 [2]  SCREW,M16 x 2 x 160mm KOBM16x2.0x160mm
42. 2420R1187D275 [1]  HOSE  HOSE
43. ZN13C16013 [6]  NUT KOBM16x2.0mm
44. 2420Z1047 [1]  SLOTTED NUT KOBM56x5.5mm Castle
45. ZW22X10000 [37]  LOCK WASHER KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
46. ZW22X12000 [17]  LOCK WASHER KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
47. ZW22X14000 [12]  LOCK WASHER KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000
48. ZW22X16000 [2]  WASHER, LOCK KOBID 16 x OD 28.0 x Th 4.0mm
49. 2418Z715 [1]  WASHER KOBID 58 x OD 105 x Th 9.0mm
50. ZD12P02600 [4]  O-RING KOBID 25.70 ± 0.26 x OD 32mm
51. ZD12P03400 [2]  O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro KOBID 33.70 ± 0.33 x OD 40mm
52. 2445R220D13 [2]  DUST CAP KOBSeal -- ID 100 x OD 120 x Th 7mm
53. ZP15D08100 [1]  SPRING KOBCotter -- OD 08 x 100mm Long
54. 2418T17477 [2]  COLLAR CLAMP KOB
55. 2419T4676 [1]  PIN KOBOD 100 x 894mm Long Superseded by part number: 2419T7608
56. 2419T4680D1 [1]  PIN KOB
57. 2419P3690 [2]  PIN KOBPin -- OD 90 x 227mm Long Superseded by part number: 2419P4079
58. 2419P3418 [1]  PIN KOB Superseded by part number: 2419P3398D2
59. 2419T4681 [1]  PIN KOB Superseded by part number: 2419P3438
60. B16T0442D83 [1]  SHIM,205mm OD x 102mm ID x 1.2mm Thk KOBID 102 x OD 205 x Th 1.2mm
61. B16T0442D38 [1]  SHIM,205mm OD x 102mm ID x 1.6mm Thk KOBID 102 x OD 205 x Th 1.6mm
62. B16T0442D35 [2]  SHIM,160mm OD x 97mm ID x 1.6mm Thk KOBID 97 x OD 160 x Th 1.6mm
63. B16T0442D13 [3]  SHIM,160mm OD x 92mm ID x 1.2mm Thk KOBID 92 x OD 160 x Th 1.2mm
64. B16T0442D14 [3]  SHIM,160mm OD x 92mm ID x 1.6mm Thk KOBID 92 x OD 160 x Th 1.6mm
65. B16T0442D84 [1]  SHIM,205mm OD x 102mm ID x 0.9mm Thk KOBID 102 x OD 205 x Th 0.9mm
66. B16T0442D60 [1]  SHIM,205mm OD x 102mm ID x 0.5mm Thk KOBID 102 x OD 205 x Th 0.5mm
67. B16T0442D53 [4]  SHIM,92mm ID x 160mm OD x 0.5mm Thk KOBID 92 x OD 160 x Th 0.5mm
68. 2416T13056 [1]  BRACKET KOB
69. 2418T12469 [1]  PLATE KOB150 x 50 x Th 12mm, 2-Ø16 Holes
70. 2418T17550 [2]  PLATE KOBID 18 x OD 60 x Th 06mm
71. 2436R767F2 [2]  VALVE KOB
72. 2432R229F1 [2]  BAND KOB
72-1. 2438U914D1S24 [1]  U-BRACKET KOB
72-2. 2436R764S2 [1]  BAND  BAND
72-3. ZW26X10000 [4]  LOCK WASHER KOBID 10 x OD 18 x Th 2.5mm
72-4. ZS11C10035 [2]  SCREW,Hex, M10 x 35mm, Cl 4.8 KOBCAPSCREW -- M10x1.50x35mm Superseded by part number: ZS18C10035
72-5. ZS23C10025 [2]  SCREW,Hex Socket Head, M10 x 25mm KOBM10x1.50x25mm Superseded by part number: ZS28C10025
72-6. ZN16C10008 [2]  NUT KOBM10x1.50mm Superseded by part number: ZN18C10008
73. 2418P23919 [1]  RIGID TUBE KOB
74. 2418P23920 [1]  RIGID TUBE KOB
75. 2418P29002 [1]  TUBE KOB
76. 2418P29003 [1]  TUBE KOB
77. 2418P29004 [1]  TUBE KOB
78. 2418P29005 [1]  TUBE KOB
79. 2444R1133D5 [4]  HOSE KOB760mm Long (29-59/64 in)
80. 2444R1102D1 [1]  FLEXIBLE HOSE KOB1050mm Long (41-21/64 in)
81. ZA23F15006 [2]  HYD CONNECTOR KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied)
82. ZA23F15008 [2]  HYD CONNECTOR KOB
83. ZA33F10004 [2]  ELBOW KOB
84. ZD12P01100 [2]  O-RING KOBID 10.8mm x OD 13.2mm
85. ZD12P01400 [2]  O-RING KOBID 13.80 ± 0.19 x OD 18mm
86. ZD12P01800 [2]  O-RING KOBID 17.8mm x OD 20.2mm
87. 2432P2237 [2]  CLAMP KOB
88. 2432T2340 [2]  CLAMP KOB
89. ZS13C10025 [4]  CAPSCREW KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025
90. ZS13C10040 [4]  SCREW KOBM10x1.50x40mm Superseded by part number: ZS18C10040
91. ZS13C10060 [8]  SCREW KOBM10x1.50x60mm Superseded by part number: ZS18C10060
92. ZN13C10008 [4]  NUT KOBM10x1.50mm Superseded by part number: ZN18C10008
92. B16T0442D40 [3]  SHIM,92mm ID x 160mm OD x 0.9mm Thk KOBID 92 x OD 160 x Th 0.9mm
96. B16T0442D85 [2]  SHIM,160mm OD x 97mm ID x 1.2mm Thk KOBID 97 x OD 160 x Th 1.2mm
97. B16T0442D86 [2]  SHIM,160mm OD x 97mm ID x 0.9mm Thk KOBID 97 x OD 160 x Th 0.9mm
98. B16T0442D87 [2]  SHIM,160mm OD x 97mm ID x 0.5mm Thk KOBID 97 x OD 160 x Th 0.5mm
99. ZS13C10035 [4]  SCREW KOBM10x1.50x35mm Superseded by part number: ZS18C10035
100. ZD12G03000 [2]  O-RING,29.40mm ID x 35.60mm OD x 3.10mm KOBID 29.4 ± 0.29 x OD 35mm
200. 2411J5038D3F1 [1]  BOOM
200-39. 2405T1825 [2]  BUSHING KOB
200-41. 2416T24891D2 [2]  LINK BLOCK KOB
200-42. 2416T12924D3 [4]  LINK BLOCK KOB
200-43. 2416T24922 [1]  SUPPORT
200-44. 2416T14115 [2]  BLOCK KOB
201. 2418P28985 [2]  TUBE KOB
203. 2418P28987D1 [1]  TUBE KOB
204. 2418P28987D2 [1]  TUBE KOB
205. 24100P1005F1 [2]  VALVE KOB Superseded by part number: 24100P1005F3
205-1. 2436P229 [1]  VALVE BODY KOB
205-2. 2436T303 [1]  VALVE KOB
205-3. 2418T8945D1 [1]  SPACER KOBID 40 x OD 60 x Th 3.2mm
205-4. ZR16X04000 [1]  RING KOBRetaining -- ID 37 x OD 40 x Th 1.8mm
205-5. ZS23C06010 [1]  SCREW,Hex Socket Head, M6 x 10mm KOBM06x1.0x10mm
205-6. ZD11G04000 [2]  O-RING,39.40mm ID x 45.60mm OD x 3.10mm KOBID 39.40 ± 0.37 x OD 45mm
205-7. ZD12G04000 [1]  O-RING,39.40mm ID x 45.60mm OD x 3.10mm KOBID 39.40 ± 0.37 x OD 45mm
205-8. ZD75G04000 [1]  BACK-UP RING KOBID 40 x OD 45 x Th 1.25mm
205-9. ZD12G03500 [1]  O-RING,34.40mm ID x 40.60mm OD x 3.10mm KOBID 34.40 ± 0.33 x OD 40mm
205-10. ZD85G03500 [1]  RING KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm
206. ZF23B35000 [2]  HYD CONNECTOR KOB
211. ZC26X35016 [10]  CLAMP KOBSingle Line -- 85x44x38mm (Ø35mm)
212. ZS13C14060 [10]  SCREW KOBM14x2.0x60mm Superseded by part number: ZS18C14060
214. 2444R950D1 [2]  HOSE KOB
215. 2420Z985 [2]  PLUG KOB
216. 2418P29035D2 [1]  TUBE KOB
217. 2418P29035D1 [1]  TUBE KOB
219. 2414Z199D100 [6]  PROTECTIVE SLEEVE KOBHose -- 1000mm Long (39-3/8 in)
220. ZC26X18011 [2]  CLAMP KOB Superseded by part number: ZC26M18011
223. 2444Z2093 [4]  HYD CONNECTOR KOB
224. ZD12P02400 [6]  O-RING KOBID 23.70 ± 0.24 x OD 30mm
225. 2444T2179 [2]  HYD CONNECTOR KOB
226. 2418T16550D2 [2]  TUBE
227. ZT22A05000 [1]  KEY KOBScrew -- 05mm
230. 2432P2807 [1]  TYPE PLATE KOB Superseded by part number: 2432P2276
231. 2432P2806 [1]  TYPE PLATE KOB Superseded by part number: 2432P2275
