神钢零件查询(NIBBLER) - BREAKER & EXTRA ATTACHMENTS - SK220 ASN LQU0001 & SK200LC ASN LLU0601 (1/91-12/97) (03-007[03]) - UPPER HYDRAULICS (BREAKER) Kobelco

作者：广数供应链运营团队
浏览数：
时间：2025-01-23 09:38:24
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos.Part NoQtyParts nameComments
. . 24100J15266F1 [1]  HYD LINES,UPP
1. 2444R1071D1 [1]  FLEXIBLE HOSE KOB
2. ZC15X10500 [4]  CLIP KOB
3. 2418P23745 [1]  TUBE KOB
4. ZD11G07500 [1]  O-RING,74.40mm ID x 80.60mm OD x 3.10mm KOBID 74.40 ± 0.65 x OD 80mm
5. ZS23C12030 [4]  SCREW,Hex Socket Head, M12 x 30mm KOBM12x1.75x30mm
6. ZW22K12000 [4]  LOCK WASHER KOBID 12.2 x OD 17.8 x Th 2.5mm
7. ZE13X12000 [4]  CLAMP KOBHalf -- (Incls. Capscrew & Lockwasher)
8. ZD12P02600 [4]  O-RING KOBID 25.70 ± 0.26 x OD 32mm
9. ZS13C10035 [2]  SCREW KOBM10x1.50x35mm, Start Serial: LLU00682 Superseded by part number: ZS18C10035
10. ZW22X10000 [12]  LOCK WASHER KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
11. 2444Z2323D9 [2]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1172D3
11. 2444R1172D3 [2]  HOSE KOBLLU00830 to
12. ZC36X28014 [5]  CLAMP KOBDouble Line -- 100x38x16mm (Ø30mm)
13. 2418P26605 [1]  TUBE  TUBE
14. 2418P26606 [1]  TUBE KOB Superseded by part number: 2418P22208
15. 2416T26634 [1]  BLOCK KOB
16. ZS13C12060 [4]  SCREW KOBM12x1.75x60mm Superseded by part number: ZS18C12060
17. ZW22X12000 [11]  LOCK WASHER KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
18. ZA23F28016 [13]  CONNECTION KOB1" PF - M36x1.50x49mm Long
19. ZD12P02900 [19]  O-RING KOBID 28.70 ± 0.29 x OD 35mm
20. 2436U2816F1 [1]  CONTROL VALVE KOB Superseded by part number: 2436U2816F2
21. 2420T4331D4 [3]  SCREW,M12 x 1.75 x 150mm KOBM12x1.75x150mm
22. ZN13C12010 [6]  NUT KOBM12x1.75mm Superseded by part number: ZN18C12010
23. 2420T2948D5 [2]  U-BOLT KOBM08x1.25x ID 45 x 80.5mm Long LLU00692 to
24. ZS13C16055 [4]  SCREW KOBM16x2.0x55mm
25. ZW22X16000 [6]  WASHER, LOCK KOBID 16 x OD 28.0 x Th 4.0mm
26. 2416P19377 [1]  SUPPORT KOBLLU00692 to
27. ZA23F28012 [3]  HYD CONNECTOR KOB
28. ZD12P02400 [4]  O-RING KOBID 23.70 ± 0.24 x OD 30mm
30. 2418P12279 [1]  RIGID TUBE KOB
31. 2432T2242 [2]  CLAMP KOBDouble -- 106x38x12mm (Ø23xØ29mm)
32. 2416P14905 [1]  SUPPORT KOB
34. ZW11X08000 [3]  WASHER KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000
35. ZA33F22012 [1]  ELBOW KOB
36. 2418P26607 [1]  TUBE  TUBE
37. 2418T23797 [1]  TUBE *5  TUBE *5
38. 2418P18112 [1]  RIGID TUBE KOB
39. 2418T23798 [1]  TUBE  TUBE
40. 2432Z467 [2]  CLAMP KOB
41. 2405T1717 [2]  BUSHING KOB
42. ZS13C12100 [1]  SCREW KOB Superseded by part number: ZS18C12100
43. ZW13H10000 [2]  WASHER KOBID 11 x OD 24 x Th 3.2mm LLU00692 to Superseded by part number: ZW16H10000
44. ZW13H08000 [4]  WASHER KOBLLU00692 to
45. 2444Z2399D8 [4]  FLEXIBLE HOSE KOB, Serial Range: LLU00601-LLU00634 Superseded by part number: 2444R1173D2
45. 2444R1173D2 [4]  FLEXIBLE HOSE KOB, Start Serial: LLU00635
46. ZH22X08000 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
47. ZX21M08110 [1]  FLEXIBLE HOSE KOB1100mm Long (43-19/64 in)
48. ZH52X08000 [1]  TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring KOB(Incls. O-Ring 237-6008)
49. ZX21M08150 [1]  HOSE KOB1500mm Long (59-3/64 in)
50. ZS13C12055 [1]  SCREW KOBM12x1.75x55mm Superseded by part number: ZS18C12055
51. ZH22X12016 [2]  HYD CONNECTOR KOB
52. 2444Z2517D2 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1170D4
52. 2444R1170D4 [1]  HOSE KOBLLU00830 to
53. 2444Z2418 [1]  ELBOW KOB
54. ZS13C08050 [1]  SCREW KOBM08x1.25x50mm Superseded by part number: ZS18C08050
55. ZH32X12000 [1]  90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012)
56. ZX32M12135 [1]  FLEXIBLE HOSE KOB
57. 2418P22207 [1]  TUBE KOB
58. ZD11G06000 [1]  O-RING,59.40mm ID x 65.60mm OD x 3.10mm KOBID 59.40 ± 0.61 x OD 65mm
59. ZS13C10030 [4]  SCREW KOBM10x1.50x30mm Superseded by part number: ZS18C10030
60. R44P0089D13 [3]  COUPLING KOB Superseded by part number: ZG15F04500
60-3. R44P0089D7S3 [2]  GASKET KOB
61. 2418P23146 [1]  RIGID TUBE KOB
62. 2432T2388 [1]  CLAMP  CLAMP
63. ZX21M12040 [1]  FLEXIBLE HOSE KOB400mm Long (15-3/4 in)
64. ZW22X08000 [3]  LOCK WASHER KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583
65. 2416T24091 [1]  BRACKET
66. ZS13C08035 [2]  SCREW KOBM08x1.25x35mm Superseded by part number: ZS18C08035
67. 2418P22214 [1]  TUBE KOB
68. R44P0089D8 [1]  ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L KOB
68-3. R44P0089D8S3 [2]  GASKET KOB
69. 2436R393S4 [1]  VALVE KOB
70. R44P0089D4 [1]  COUPLING KOB Superseded by part number: ZG15F05100
70-3. R44P0089D4S3 [2]  GASKET,50.85mm ID x 67.20mm OD KOB
72. 2444T2958 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
73. 2444Z3359D5 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00601-LLU00634 Superseded by part number: 2444R1168D1
73. 2444R1168D1 [1]  HOSE KOB, Start Serial: LLU00635-
74. 2444Z3449D9 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00601-LLU00634 Superseded by part number: 2444R2486D2
74. 2444R2486D2 [1]  HOSE KOB, Start Serial: LLU00635
75. ZA23F18008 [2]  HYD CONNECTOR KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied)
76. ZA33F18008 [1]  ELBOW KOB
77. ZD12P01800 [4]  O-RING KOBID 17.8mm x OD 20.2mm
80. 2418T24411D2 [2]  SPACER KOB
81. 2418T24324D4 [1]  SPACER
82. 2432R225D12 [2]  CLAMP KOBClamp, Single -- ID 31 x 69.5mm Long Superseded by part number: ZC46X31014
83. ZW13H16000 [6]  WASHER KOBID 17 x OD 32 x Th 4.5mm
84. ZN13C08007 [1]  NUT KOBM08x1.25mm LLU00601, Serial Range: -LLU00691 Superseded by part number: ZN18C08007
85. ZS13C12065 [1]  SCREW KOB Superseded by part number: ZS18C12065
86. ZS18C12030 [5]  SCREW,Hex, M12 x 30mm KOBM12x1.75x30mm
87. ZW26X12000 [7]  LOCK WASHER KOBID 12 x OD 21 x Th 3.0mm
88. ZW16X12000 [1]  WASHER KOBID 12 x OD 24 x Th 2.3mm
89. ZN18C12010 [3]  NUT KOBM12x1.75mm
90. 2418P23469 [1]  TUBE KOB
91. 2418P23468 [1]  RIGID TUBE KOB
92. ZA33F28016 [1]  ELBOW KOB
96. 2416P16381 [1]  BRACKET
97. 2416P18274 [1]  BRACKET
98. 2420T4333D10 [8]  SCREW KOB
101. 2418P26609 [2]  TUBE  TUBE
102. 2418P26608 [2]  TUBE KOB
103. ZS13C12080 [1]  SCREW KOBM12x1.75x80mm Superseded by part number: ZS18C12080
104. ZW13H12000 [2]  WASHER KOB
106. 2436U2623F2 [1]  VALVE KOB
107. ZE72X08000 [1]  PLUG KOB1/2" PF, (Incls. O-Ring ZD12P01800)
108. 2436U1207F1 [1]  VALVE KOB
109. 2446U233F1 [1]  FILTER ASSY KOB
109-1. 2446U232S1 [1]  COVER KOB
109-2. 2446U233S2 [1]  ELEMENT KOB
109-3. 2446U232S3 [1]  CASE KOB
109-4. 2446U233S4 [1]  PLUG
109-5. 2446U233S5 [1]  VALVE
109-6. 2446U233S5 [1]  SPRING
109-7. 2446U233S7 [1]  PLUG KOB
109-8. ZD12P02800 [1]  O-RING KOBID 27.70 ± 0.27 x OD 34mm
109-9. ZD12G11500 [1]  O-RING,114.40mm ID x 120.60mm OD x 3.10mm KOBID 114.40 ± 0.94 x OD 120mm
109-10. ZD11P05000 [1]  O-RING KOB
109-11. ZD12G03000 [1]  O-RING,29.40mm ID x 35.60mm OD x 3.10mm KOBID 29.4 ± 0.29 x OD 35mm
109-12. 2446U233S12 [1]  SCREW KOB
109-13. ZD12P01200 [1]  O-RING KOBID 11.80 ± 0.19 x OD 16mm
110. 2416T13239 [1]  U-BRACKET KOB
111. ZA23F35020 [2]  HYD CONNECTOR KOB
112. 2444Z2348 [1]  HYD CONNECTOR KOB
113. 2418P22273 [1]  RIGID TUBE KOB, Serial Range: LLU00601-LLU00634
113. 2418P28842 [1]  RIGID TUBE KOB, Start Serial: LLU00635-
114. 2418T21535 [1]  TUBE, Serial Range: LLU00601-LLU00634  TUBE, Serial Range: LLU00601-LLU00634
114. 2418P28881 [1]  TUBE KOB, Start Serial: LLU00635-
115. 2418P23402 [1]  RIGID TUBE KOB, Serial Range: LLU00601-LLU00634
115. 2418P28882 [1]  TUBE KOB, Start Serial: LLU00635-
116. ZD12P03800 [3]  O-RING KOBID 37.70 ± 0.37 x OD 44.7mm
117. 2432T2326 [1]  CLAMP KOB
118. 2432T4355 [1]  CLAMP KOB
119. ZS18C12110 [2]  SCREW,Hex, M12 x 110mm KOBM12x1.75x110mm
120. ZS13C12130 [1]  SCREW KOBM12x1.75x130mm Superseded by part number: ZS18C12130
121. 2432P1083 [1]  LABEL KOB
122. 2416P18617 [1]  SUPPORT KOB
123. ZC26X28014 [1]  CLAMP KOBSingle Line -- 75x37x38mm (Ø28mm)
124. ZS13C16045 [2]  SCREW KOBScrew -- M16x2.0x45mm
