Pos.	Part No	Qty	Parts name	Comments
. .	24100J15268F1	[1]	HYDR LINES, UPP
2.	2436U1213F1	[1]	CONTROL VALVE	KOB
3.	2436U1303F1	[1]	PILOT VALVE	KOB
4.	2436U1207F1	[1]	VALVE	KOB
5.	2446U233F1	[1]	FILTER ASSY	KOB
5-1.	2446U232S1	[1]	COVER	KOB
5-2.	2446U233S2	[1]	ELEMENT	KOB
5-3.	2446U232S3	[1]	CASE	KOB
5-4.	2446U233S4	[1]	PLUG
5-5.	2446U233S5	[1]	VALVE
5-6.	2446U233S6	[1]	SPRING
5-7.	2446U233S7	[1]	PLUG	KOB
5-8.	ZD12P02800	[1]	O-RING	KOBID 27.70 ± 0.27 x OD 34mm
5-9.	ZD12G11500	[1]	O-RING,114.40mm ID x 120.60mm OD x 3.10mm	KOBID 114.40 ± 0.94 x OD 120mm
5-10.	ZD11P05000	[1]	O-RING	KOB
5-11.	ZD12G03000	[1]	O-RING,29.40mm ID x 35.60mm OD x 3.10mm	KOBID 29.4 ± 0.29 x OD 35mm
5-12.	2446U233S12	[1]	SCREW	KOB
5-13.	ZD12P01200	[1]	O-RING	KOBID 11.80 ± 0.19 x OD 16mm
6.	2416T13239	[1]	U-BRACKET	KOB
7.	2418P24507	[1]	RIGID TUBE	KOB
8.	2418P24508	[1]	TUBE,BRAZED	TUBE,BRAZED
9.	2418P24509	[1]	TUBE, Serial Range: LLU00601-LLU00634	TUBE, Serial Range: LLU00601-LLU00634
9.	2418P28885	[1]	TUBE,BRAZED, Start Serial: LLU00635-	TUBE,BRAZED, Start Serial: LLU00635-
10.	2418P24510	[1]	TUBE, Serial Range: LLU00601-LLU00634
10.	2418P28886	[1]	TUBE,BRAZED, Start Serial: LLU00635-	TUBE,BRAZED, Start Serial: LLU00635-
11.	2418P22273	[1]	RIGID TUBE	KOB, Serial Range: LLU00601-LLU00634
11.	2418P28842	[1]	RIGID TUBE	KOB, Start Serial: LLU00635-
12.	ZA23H15006	[1]	HYD CONNECTOR	KOB
13.	ZA23F28012	[1]	HYD CONNECTOR	KOB
14.	ZA23F28016	[2]	CONNECTION	KOB1" PF - M36x1.50x49mm Long
15.	ZA23F35020	[2]	HYD CONNECTOR	KOB
16.	2444T2535	[1]	HYD CONNECTOR	KOB
17.	2444T2952	[2]	HYD CONNECTOR	KOB
18.	2444Z2348	[1]	HYD CONNECTOR	KOB
19.	2444Z3747	[1]	HYD CONNECTOR	KOBCONNECTOR
20.	ZA33F28016	[2]	ELBOW	KOB
21.	2444Z3770	[1]	TEE	KOBTEE
22.	ZD12P01400	[1]	O-RING	KOBID 13.80 ± 0.19 x OD 18mm
23.	ZD12P02400	[4]	O-RING	KOBID 23.70 ± 0.24 x OD 30mm
24.	ZD12P02900	[4]	O-RING	KOBID 28.70 ± 0.29 x OD 35mm
25.	ZD12P03800	[3]	O-RING	KOBID 37.70 ± 0.37 x OD 44.7mm
26.	ZX28N08250	[1]	FLEXIBLE HOSE	HIT
27.	ZX22M08080	[1]	HOSE ASSY.	KOB800mm Long (31-1/2 in)
28.	2444Z2285D15	[1]	HOSE	KOB
29.	2444Z2285D12	[1]	FLEXIBLE HOSE	KOB, Serial Range: LLU00601-LLU00634
29.	2444R1174D3	[1]	HOSE	KOB, Start Serial: LLU00635-
30.	2444Z3743D2	[2]	FLEXIBLE HOSE	KOB
31.	2432T2326	[2]	CLAMP	KOB
32.	2432T2539	[2]	CLAMP
33.	ZS18C12030	[11]	SCREW,Hex, M12 x 30mm	KOBM12x1.75x30mm
34.	ZS13C10090	[4]	SCREW	KOBM10x1.50x90mm Superseded by part number: ZS18C10090
35.	ZS13C12040	[3]	SCREW	KOBM12x1.75x40mm Superseded by part number: ZS18C12040
36.	ZS18C12110	[2]	SCREW,Hex, M12 x 110mm	KOBM12x1.75x110mm
37.	ZS13C12130	[2]	SCREW	KOBM12x1.75x130mm Superseded by part number: ZS18C12130
38.	ZW22X10000	[5]	LOCK WASHER	KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
39.	ZW22X12000	[7]	LOCK WASHER	KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
40.	ZW26X12000	[9]	LOCK WASHER	KOBID 12 x OD 21 x Th 3.0mm
41.	ZN18C12010	[5]	NUT	KOBM12x1.75mm
42.	2416P16221	[1]	SUPPORT
43.	ZS13C10050	[1]	SCREW	KOBM10x1.50x50mm Superseded by part number: ZS18C10050
44.	2416T20885	[1]	BLOCK,TAPPED
45.	ZC37X18112	[1]	CLAMP	KOB
47.	2444Z3155	[1]	90 ELBOW,PF 3/8" Fem x PF 3/8" Male	KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1
48.	2436P231F1	[3]	VALVE PRESSURE RELIE	KOB
48-1.	2436P232	[1]	BODY VALVE
48-2.	2436T305	[1]	VALVE
48-3.	2418T8945D3	[1]	SPACER ID 30 x OD 44 x Th 3.2mm	SPACER ID 30 x OD 44 x Th 3.2mm
48-4.	ZR16X03000	[1]	SNAP RING	KOB
48-5.	2420Z922	[1]	CAPSCREW	CAPSCREW
48-6.	ZD11G03000	[2]	O-RING,29.40mm ID x 35.60mm OD x 3.10mm	KOB
48-7.	ZD12G02500	[1]	O-RING,24.40mm ID x 30.60mm OD x 3.10mm	KOBID 24.4 ± 0.25 x OD 30mm
48-8.	ZD85G02500	[1]	BACK-UP RING	KOBRing, Back-Up -- ID 25 x OD 30 x Th 1.25mm
48-9.	ZD12G03000	[1]	O-RING,29.40mm ID x 35.60mm OD x 3.10mm	KOBID 29.4 ± 0.29 x OD 35mm
48-10.	ZD75G03000	[1]	BACK-UP RING	KOB
49.	ZS13C08020	[2]	SCREW	KOBM08x1.25x20mm Superseded by part number: ZS18C08020
50.	ZS13C08025	[4]	SCREW	KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313
51.	ZW22X08000	[6]	LOCK WASHER	KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583
52.	2432P2450	[1]	LABEL	KOB
53.	2432P1052	[1]	LABEL	LABEL
54.	2432R225D12	[6]	CLAMP	KOBClamp, Single -- ID 31 x 69.5mm Long Superseded by part number: ZC46X31014
55.	ZW16X12000	[3]	WASHER	KOBID 12 x OD 24 x Th 2.3mm
56.	2414T4934F2	[1]	COVER ASSY
56-2.	2427Z1454	[1]	INSULATION ,SOUND
56-3.	2416Z263D2	[1]	FOAM INSULATION	KOBSHEET,RUBBER
56-4.	2414P8764	[1]	COVER
57.	24100J15071F1	[1]	HYD LINE UPP
