神钢零件查询(NIBBLER) - BREAKER & EXTRA ATTACHMENTS - SK220 ASN LQU0001 & SK200LC ASN LLU0601 (1/91-12/97) (03-004[01]) - UPPER HYDRAULICS (NIBBLER & BREAKER) P/N 24100J16039 F1,F2,F3 Kobelco

作者：广数供应链运营团队
浏览数：
时间：2025-01-23 09:34:40
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos.Part NoQtyParts nameComments
. . 24100J16039F1 [1]  HYDR LINES, UPP
. . 24100J16039F2 [1]  HYDR LINES, UPP
. . 24100J16039F3 [1]  HYDR LINES, UPP
1. 2444R1071D1 [1]  FLEXIBLE HOSE KOB
2. ZC15X10500 [4]  CLIP KOB
3. 2418P23745 [1]  TUBE KOB
4. ZD11G07500 [1]  O-RING,74.40mm ID x 80.60mm OD x 3.10mm KOBID 74.40 ± 0.65 x OD 80mm
5. ZS23C12030 [4]  SCREW,Hex Socket Head, M12 x 30mm KOBM12x1.75x30mm
6. ZW22K12000 [4]  LOCK WASHER KOBID 12.2 x OD 17.8 x Th 2.5mm
7. ZE13X12000 [4]  CLAMP KOBHalf -- (Incls. Capscrew & Lockwasher)
8. ZD12P02600 [4]  O-RING KOBID 25.70 ± 0.26 x OD 32mm
10. ZW22X10000 [18]  LOCK WASHER KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
11. 2444Z2323D9 [2]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1172D3
11. 2444R1172D3 [2]  HOSE KOBLLU00830 to
12. ZC36X28014 [4]  CLAMP KOBDouble Line -- 100x38x16mm (Ø30mm)
13. 2418P26605 [1]  TUBE  TUBE
14. 2418P26606 [1]  TUBE KOB Superseded by part number: 2418P22208
15. 2416T26634 [1]  BLOCK KOB
16. ZS13C12060 [4]  SCREW KOBM12x1.75x60mm Superseded by part number: ZS18C12060
17. ZW22X12000 [17]  LOCK WASHER KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
18. ZA23F28016 [14]  CONNECTION KOB1" PF - M36x1.50x49mm Long
19. ZD12P02900 [21]  O-RING KOBID 28.70 ± 0.29 x OD 35mm
20. 2436U2816F1 [1]  CONTROL VALVE KOB Superseded by part number: 2436U2816F2
21. 2420T4331D4 [3]  SCREW,M12 x 1.75 x 150mm KOBM12x1.75x150mm
22. ZN13C12010 [8]  NUT KOBM12x1.75mm Superseded by part number: ZN18C12010
24. ZS13C16055 [4]  SCREW KOBM16x2.0x55mm
25. ZW22X16000 [6]  WASHER, LOCK KOBID 16 x OD 28.0 x Th 4.0mm
27. ZA23F28012 [2]  HYD CONNECTOR KOB
28. ZD12P02400 [11]  O-RING KOBID 23.70 ± 0.24 x OD 30mm
30. 2418P12279 [1]  RIGID TUBE KOB
31. 2432T2242 [2]  CLAMP KOBDouble -- 106x38x12mm (Ø23xØ29mm)
32. 2416P14905 [1]  SUPPORT KOB
34. ZW11X08000 [3]  WASHER KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000
35. ZA33F22012 [3]  ELBOW KOB
36. 2418P26607 [1]  TUBE  TUBE
37. 2418T23797 [1]  TUBE *5  TUBE *5
38. 2418P18112 [1]  RIGID TUBE KOB
39. 2418T23798 [1]  TUBE  TUBE
40. 2432Z467 [2]  CLAMP KOB
41. 2405T1717 [2]  BUSHING KOB
42. ZS13C12100 [1]  SCREW KOB Superseded by part number: ZS18C12100
45. 2444R1173D2 [4]  FLEXIBLE HOSE KOB
46. ZH22X08000 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
47. ZX21M08110 [1]  FLEXIBLE HOSE KOB1100mm Long (43-19/64 in)
48. ZH52X08000 [1]  TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring KOB(Incls. O-Ring 237-6008)
49. ZX21M08150 [1]  HOSE KOB1500mm Long (59-3/64 in)
50. ZS13C12055 [3]  SCREW KOBM12x1.75x55mm Superseded by part number: ZS18C12055
51. ZH22X12016 [1]  HYD CONNECTOR KOB
52. 2444Z2517D2 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1170D4
52. 2444R1170D4 [1]  HOSE KOBLLU00830 to
53. 2444Z2418 [1]  ELBOW KOB
54. ZS13C08050 [1]  SCREW KOBM08x1.25x50mm Superseded by part number: ZS18C08050
55. ZH32X12000 [1]  90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012)
56. ZX32M12135 [1]  FLEXIBLE HOSE KOB
57. 2418P22207 [1]  TUBE KOB
58. ZD11G06000 [1]  O-RING,59.40mm ID x 65.60mm OD x 3.10mm KOBID 59.40 ± 0.61 x OD 65mm
59. ZS13C10030 [4]  SCREW KOBM10x1.50x30mm Superseded by part number: ZS18C10030
60. R44P0089D13 [3]  COUPLING KOB Superseded by part number: ZG15F04500
60-3. R44P0089D13S3 [2]  GASKET KOB
61. 2418P23146 [1]  RIGID TUBE KOB
62. 2432T2388 [1]  CLAMP  CLAMP
63. ZX21M12040 [1]  FLEXIBLE HOSE KOB400mm Long (15-3/4 in)
64. ZW22X08000 [7]  LOCK WASHER KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583
65. 2416T24091 [1]  BRACKET
66. ZS13C08035 [2]  SCREW KOBM08x1.25x35mm Superseded by part number: ZS18C08035
67. 2418P22214 [1]  TUBE KOB
68. R44P0089D8 [1]  ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L KOB
68-3. R44P0089D8S3 [2]  GASKET KOB
69. 2436R393S4 [1]  VALVE KOB
70. R44P0089D4 [1]  COUPLING KOB Superseded by part number: ZG15F05100
70-3. R44P0089D4S3 [2]  GASKET,50.85mm ID x 67.20mm OD KOB
71. 2418P27522 [1]  FLANGE KOB
72. 2444T2958 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
73. 2444Z3359D5 [1]  FLEXIBLE HOSE KOB, Serial Range: LLU00703-LLU00829 Superseded by part number: 2444R1168D1
73. 2444R1168D1 [1]  HOSE KOBLLU00830 to
74. 2444R2486D2 [1]  HOSE KOB
75. ZA23F18008 [2]  HYD CONNECTOR KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied)
76. ZA33F18008 [2]  ELBOW KOB
77. ZD12P01800 [4]  O-RING KOBID 17.8mm x OD 20.2mm
80. 2418T24411D2 [2]  SPACER KOB
81. 2418T24324D4 [1]  SPACER
82. 2432R225D12 [2]  CLAMP KOBClamp, Single -- ID 31 x 69.5mm Long Superseded by part number: ZC46X31014
83. ZW13H16000 [6]  WASHER KOBID 17 x OD 32 x Th 4.5mm
84. ZN13C08007 [5]  NUT KOBM08x1.25mm, Serial Range: LLU00703-LLU00811 Superseded by part number: ZN18C08007
85. ZS13C12065 [1]  SCREW KOBM12x1.75x65mm Superseded by part number: ZS18C12065
86. ZS18C12030 [11]  SCREW,Hex, M12 x 30mm KOBM12x1.75x30mm
87. ZW26X12000 [9]  LOCK WASHER KOBID 12 x OD 21 x Th 3.0mm
88. ZW16X12000 [6]  WASHER KOBID 12 x OD 24 x Th 2.3mm
89. ZN18C12010 [5]  NUT KOBM12x1.75mm
90. 2418P23469 [1]  TUBE KOB
91. 2418P23468 [1]  RIGID TUBE KOB
92. ZA33F28016 [2]  ELBOW KOB
96. 2416P16381 [1]  BRACKET
97. 2416P18274 [1]  BRACKET
98. 2420T4333D10 [8]  SCREW KOB
101. 2418P26609 [2]  TUBE  TUBE
102. 2418P26608 [2]  TUBE KOB
104. ZW13H12000 [2]  WASHER KOB
106. 2436U2623F2 [1]  VALVE KOB
107. ZE72X08000 [1]  PLUG KOB1/2" PF, (Incls. O-Ring ZD12P01800)
112. 2444Z4130 [1]  TEE KOB
113. 2444R1119D140 [1]  HOSE KOB1400mm Long (55-1/8 in)
114. 2432Z290 [7]  CLIP KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3
115. 2418P24401 [1]  RIGID TUBE KOB
116. 2418P19073 [1]  RIGID TUBE KOBTUBE
117. 2416P12753 [1]  SUPPORT KOB
118. 2416P12752 [1]  SUPPORT KOB
119. 2432T2340 [2]  CLAMP KOB
120. ZS13C10050 [2]  SCREW KOBM10x1.50x50mm Superseded by part number: ZS18C10050
123. ZA23F22012 [2]  HYD CONNECTOR KOB3/4"PF - M30x1.50 x 46mm Long
125. 2418P28844 [1]  RIGID TUBE KOB
126. ZA23B22000 [1]  HYD CONNECTOR KOBM30x1.50x38mm Long
127. 2418P28838 [1]  RIGID TUBE KOB
128. ZA23H22012 [1]  HYD CONNECTOR KOB
129. ZA53B22000 [1]  TEE KOB
130. 2418T25155 [1]  RIGID TUBE KOB
132. 2436U1198F1 [1]  CONTROL VALVE KOB Superseded by part number: YN30V00011F3
136. 2416P12072 [1]  U-BRACKET KOB
137. ZS13C12040 [4]  SCREW KOBM12x1.75x40mm Superseded by part number: ZS18C12040
140. 2418P28839 [1]  CLAMP KOB
141. 2432T4355 [2]  CLAMP KOB
142. ZS13C12110 [1]  SCREW KOBM12x1.75x110mm Superseded by part number: ZS18C12110
143. 2418P28840 [1]  RIGID TUBE KOB
144. ZA33F28012 [3]  ELBOW KOB
145. 24100P1005F1 [1]  VALVE KOB Superseded by part number: 24100P1005F3
146. ZS13C08018 [4]  SCREW KOBM08x1.25x18mm Superseded by part number: ZS18C08020
148. 2436U1207F1 [1]  VALVE KOB
149. 24100P1739F2 [1]  VALVE PRESSURE RELIE KOB
150. 2418T25156 [1]  RIGID TUBE KOB
151. 2418P28841 [1]  RIGID TUBE KOB
152. 2444Z2348 [1]  HYD CONNECTOR KOB
153. ZD12P03800 [4]  O-RING KOBID 37.70 ± 0.37 x OD 44.7mm
154. 2446U233F1 [1]  FILTER ASSY KOB
155. ZS18C12110 [2]  SCREW,Hex, M12 x 110mm KOBM12x1.75x110mm
158. 2416T13239 [1]  U-BRACKET KOB
160. 2418P28842 [1]  RIGID TUBE KOB
162. ZA23F35020 [2]  HYD CONNECTOR KOB
163. 2418P28843 [1]  RIGID TUBE KOB
164. 2444Z3560D1 [1]  FLEXIBLE HOSE KOB
165. ZE12X20000 [2]  CLAMP KOB
166. ZS23C10030 [4]  SCREW,Hex Socket Head, M10 x 30mm KOBM10x1.50x30mm Superseded by part number: ZS28C10030
167. ZW22K10000 [4]  LOCK WASHER KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm
168. 2444Z3554 [1]  TEE KOB
169. ZS13C12130 [1]  SCREW KOBM12x1.75x130mm Superseded by part number: ZS18C12130
170. 2432P1083 [1]  LABEL KOB
171. ZT22A05000 [1]  KEY KOBScrew -- 05mm
172. 2432T2326 [2]  CLAMP KOB
174. ZW11X10000 [1]  WASHER KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000
176. 2416T27325 [1]  U-BRACKET KOB
177. 2416T25554 [1]  U-BRACKET KOB
178. 2416T25555 [1]  U-BRACKET KOB
179. 2420T2948D5 [3]  U-BOLT KOBM08x1.25x ID 45 x 80.5mm Long
180. ZC27X28012 [1]  CLAMP KOBCLAMP Superseded by part number: YN43H01097P1
181. ZC27X22012 [3]  COLLAR HIT
182. ZS13C10060 [1]  SCREW KOBM10x1.50x60mm Superseded by part number: ZS18C10060
183. ZS13C10055 [3]  SCREW KOBM10x1.50x55mm Superseded by part number: ZS18C10055
186. ZN13C10008 [1]  NUT KOBM10x1.50mm Superseded by part number: ZN18C10008
188. ZW13H08000 [4]  WASHER KOBLLU00812 to
189. ZS13C10035 [2]  SCREW KOBM10x1.50x35mm LLU00812 to Superseded by part number: ZS18C10035
190. 2416P19377 [1]  SUPPORT KOBLLU00812 to
191. ZW13H10000 [2]  WASHER KOBID 11 x OD 24 x Th 3.2mm LLU00812 to Superseded by part number: ZW16H10000
