神钢零件查询(NIBBLER) - BREAKER & EXTRA ATTACHMENTS - SK220 ASN LQU0001 & SK200LC ASN LLU0601 (1/91-12/97) (02-008[01]) - REMOTE CONTROL ASSY (EXTRA) Kobelco

作者：广数供应链运营团队
浏览数：
时间：2025-01-23 09:32:42
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos.Part NoQtyParts nameComments
. . 24100J16496F1 [1]  REMOTE CONTROL ASSY
. . 24100J16496F2 [1]  REMOTE CONTROL ASSY
. . 24100J16496F3 [1]  REMOTE CONTROL ASSY
1. 2410T323 [1]  BLOCK KOB
2. 2436U1453F2 [1]  SOLENOID VALVE KOB Superseded by part number: 2436U1453F4
3. 2436U1453F1 [1]  SOLENOID VALVE KOB Superseded by part number: 2436U1453F3
6. 2445R373F1 [1]  ACCUMULATOR KOB
7. 2436U1282D2108 [1]  VALVE PRESSURE RELIE KOB
9. 2436U1171D31 [1]  CHECK VALVE KOB
10. 2479U1378 [2]  PRESSURE SWITCH KOB Superseded by part number: 2479U2010
11. 2418T22461D1 [1]  PLATE KOBPLATE
12. 2416P15419 [1]  BRACKET KOB
13. 2436R914F2 [1]  INLET MANIFOLD KOB
16. 2444Z2522F1 [1]  TEE KOB
17. 2444Z2336 [4]  TEE KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100)
18. 2444Z2457 [1]  TEE KOB
20. 2444Z2526 [1]  TEE KOB
21. 2444Z2892 [1]  TEE KOB(Incls. O-Ring ZD12P01400)
24. 2444Z3465 [1]  TEE KOB(Incls. O-Ring ZD12P01100)
25. 2444T3309 [1]  TEE KOB(2) 3/8" PF x 1/4" PF x 60mm Long (Incls. O-Ring ZD12P01100)
26. 2444T2666 [1]  TEE KOB
27. 2444T3298 [1]  TEE KOB3/8" PF - 1/4" PF (Incls. O-Ring ZD12P01100)
28. 2444Z3832 [1]  TEE HIT
29. 2444T3402 [1]  TEE KOBTee -- (Incls. O-Ring 237-6004) Superseded by part number: HH55V06006G3
30. ZH52X04000 [5]  TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring KOB1/4" PF (Incls. O-Ring 237-6004)
31. ZH52X06000 [2]  TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400)
32. 2444Z2447F1 [3]  ELBOW UNION KOBUnion Elbow
33. 2444Z2338 [10]  90 ELBOW KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100)
34. 2444Z2345 [1]  90 ELBOW KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800)
35. 2444Z3185 [4]  ELBOW KOB
36. 2444Z3186 [4]  ELBOW KOB
37. 2444Z4081 [2]  ELBOW KOB Superseded by part number: HH35X04004G3
38. 2444Z3281 [1]  ELBOW KOB
39. ZH32X04000 [20]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004)
40. ZH32X06000 [11]  90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006
42. 2444Z3783 [1]  90 ELBOW KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100)
46. 2444Z2335 [3]  CONNECTION KOB
47. 2444Z2337 [12]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01100)
49. 2444T2533 [2]  TEE KOB(Incls. O-Ring ZD12P01400) Superseded by part number: 87635046
50. 2444Z2525 [11]  HYD CONNECTOR KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408
51. 2444Z2542 [1]  HYD CONNECTOR HIT
52. 2444Z2891 [2]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01400)
53. 2444Z3280 [1]  HYD CONNECTOR KOB
54. 2444Z3322D3 [1]  HYD CONNECTOR KOB1/8"PF x 1/8"PT x 25mm Long (Incls. O-Ring)
55. 2444Z3759 [1]  HYD CONNECTOR KOB
56. 2444Z3163 [3]  HYD CONNECTOR KOBCONNECTOR Superseded by part number: 2444Z3178D2
57. 2444Z3943 [1]  ELEC CONNECTOR KOB3/8" PF - 3/8"PFx 35mm Long (Incls. O-Ring ZD12P01400)
58. 2444Z3819 [1]  HYD CONNECTOR KOB
59. 2444T2505 [1]  HYD CONNECTOR KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400)
60. ZH22X04006 [1]  HYD CONNECTOR KOB(Incls. O-Ring 237-6006)
61. ZH22X04000 [17]  HYD CONNECTOR,1/4" NPT x 1/4" NPT KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100)
62. ZH22X06000 [2]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01400)
64. ZE72X04000 [5]  PLUG KOB(PF 1/4) (Incls. O-Ring ZD12P01100)
67. 2425Z519 [3]  BALL KOB
69. 2420R1182D095 [1]  HOSE  HOSE
70. 2420R1182D200 [1]  HOSE  HOSE
71. 2418P20737 [1]  RIGID TUBE KOB
72. 2420R1182D035 [1]  HOSE KOB Superseded by part number: 2420R349D035
73. ZH22X08000 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P01800)
74. 2420R1182D085 [3]  HOSE KOBHOSE Superseded by part number: 2420R349D085
75. 2420R1182D045 [1]  HOSE  HOSE
76. 2420R1182D050 [1]  HOSE KOBHOSE Superseded by part number: HX21E04050DX
77. 2420R1182D065 [2]  FLEXIBLE HOSE KOBHOSE Superseded by part number: 2420R349D065
78. 2420R1182D075 [3]  HOSE  HOSE
79. 2420R1182D140 [1]  FLEXIBLE HOSE KOBHOSE Superseded by part number: HX21E04140DX
80. 2420R1182D185 [1]  HOSE  HOSE
81. 2420R1182D145 [1]  HOSE  HOSE
82. 2420R1182D165 [1]  HOSE  HOSE
83. 2420R1182D230 [1]  HOSE ASSY. KOB Superseded by part number: 2420R349D230
84. 2420R1182D055 [2]  HOSE  HOSE
85. 2420R1182D060 [1]  FLEXIBLE HOSE KOBHOSE Superseded by part number: 2420R349D060
86. 2420R1182D070 [1]  HOSE  HOSE
87. 2420R1182D100 [2]  HOSE KOB
88. 2420R1183D054 [1]  HOSE  HOSE
89. 2444R1120D150 [1]  HOSE KOB1500mm Long (59-3/64 in)
90. 2444R1119D080 [2]  FLEXIBLE HOSE HIT
91. 2444R1119D200 [1]  HOSE KOBPF 3/8, 2000mm Long (78-3/4 in)
92. 2444R1119D100 [1]  HOSE KOB3/8" PF, 1000mm Long (39-3/8 in)
93. 2420R1183D140 [1]  HOSE KOB
94. 2444R1119D044 [1]  HOSE KOB Superseded by part number: 2444R1119D046
95. 2420R1183D165 [1]  FLEXIBLE HOSE KOBHOSE Superseded by part number: HX21E06165DX
96. 2420R1183D170 [3]  FLEXIBLE HOSE KOB
97. 2420R1183D180 [4]  HOSE  HOSE
98. 2420R1183D185 [1]  HOSE  HOSE
99. 2420R1183D210 [8]  FLEXIBLE HOSE KOBHOSE Superseded by part number: HX21E06210DX
100. 2420R1183D160 [1]  HOSE  HOSE
101. 2420R1185D080 [1]  HOSE  HOSE
102. 2420R1183D255 [2]  HOSE  HOSE
103. ZS13C10030 [3]  SCREW KOBM10x1.50x30mm Superseded by part number: ZS18C10030
104. 2420R1183D290 [2]  HOSE  HOSE
105. ZS13C08016 [4]  SCREW KOBM08x1.25x16mm Superseded by part number: ZS18C08016
106. ZS13C08040 [2]  SCREW KOBM08x1.25x40mm Superseded by part number: ZS18C08040
107. ZS13C10020 [6]  SCREW KOBM10x1.50x20mm Superseded by part number: ZS18C10020
108. ZS18C12025 [2]  SCREW,Hex, M12 x 25mm KOBM12x1.75x25mm
109. ZS18C10030 [4]  SCREW,Hex, M10 x 30mm KOBM10x1.50x30mm
110. ZW26X10000 [5]  LOCK WASHER KOBID 10 x OD 18 x Th 2.5mm
111. ZW22X08000 [6]  LOCK WASHER KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583
112. ZW22X10000 [11]  LOCK WASHER KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
113. ZW26X12000 [2]  LOCK WASHER KOBID 12 x OD 21 x Th 3.0mm
115. 2436U1444F1 [1]  VALVE KOB
116. 2436U1171D21 [1]  CHECK VALVE KOB
118. 2444T2529 [2]  TEE KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100)
119. ZH32X08000 [1]  90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800)
120. ZH32X04006 [1]  90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400)
121. 2444Z2447F2 [1]  90 ELBOW KOB
123. 2444Z2535 [1]  HYD CONNECTOR KOB
127. ZH22X12000 [1]  HYD CONNECTOR KOB(Incls. O-Ring ZD12P02400)
128. ZS13C10025 [2]  CAPSCREW KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025
129. 2420R1182D400 [1]  HOSE  HOSE
130. 2420R1182D360 [1]  HOSE  HOSE
131. 2420R1182D380 [1]  HOSE  HOSE
133. 2420R1182D170 [1]  FLEXIBLE HOSE KOBHOSE Superseded by part number: HX21E04170DX
136. 2420R1182D110 [2]  HOSE KOB1100mm Long (43-19/64 in) Superseded by part number: 2420R349D110
137. 2420R1182D120 [1]  HOSE  HOSE
138. ZX21M12045 [1]  FLEXIBLE HOSE KOB450mm Long (17-23/32 in)
139. ZX22M08045 [1]  HOSE KOB
140. 2436U2755F1 [1]  PILOT VALVE KOBASSEMBLY Superseded by part number: 2436U2755F3
141. 2436U2606F1 [2]  PILOT VALVE KOB
142. ZS23C06030 [8]  SCREW,Hex Socket Head, M6 x 30mm KOBM06x1.0x30mm
143. ZW22K06000 [6]  LOCK WASHER KOBID 06 x OD 10 x Th 1.5mm
144. ZW11K06000 [8]  WASHER KOBID 06 x OD 11.5 x Th 1.6mm
145. ZN13C14011 [2]  NUT KOBM14x2.0mm Superseded by part number: ZN18C14011
148. 2406R256F1 [2]  HANDLE KOB
150. 2414N4225 [2]  BOOT KOB
151. 2432Z290 [51]  CLIP KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3
152. 2420Z1188 [3]  GROMMET KOB
153. 2420Z1287 [1]  GROMMET KOB
163. 2432Z290D6 [15]  CLIP KOBWire Ties -- 292mm Long Superseded by part number: PY01P01043D5
164. 2414Z199D025 [43]  PROTECTIVE SLEEVE KOBHose -- 250mm Long (9-27/32 in)
165. 2420T3483 [2]  GROMMET KOB
166. 2432R314 [2]  CLIP KOB
170. 2444Z2477F6 [1]  HYD CONNECTOR KOB
179. 2420R1182D040 [4]  FLEXIBLE HOSE KOBHOSE Superseded by part number: 2420R349D040
183. 2420R1184D055 [1]  HOSE  HOSE
188. 2444Z3758 [1]  HYD CONNECTOR KOB
191. 2444R1111F3 [1]  HYD CONNECTOR KOB
191-1. 2417T537 [1]  SPRING KOB
191-2. 2425Z551 [1]  BALL  BALL
191-4. 2444Z3775 [1]  TEE KOB Superseded by part number: 2444Z3134
191-5. 2444Z3787 [1]  HYD CONNECTOR KOB Superseded by part number: 2444Z2294
191-8. 2444Z3820 [1]  90 ELBOW KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100)
192. 2444Z3766 [1]  ELBOW KOB
194. 2444Z3761 [1]  TEE KOB
198. 2444R1119D035 [1]  FLEXIBLE HOSE KOB350mm Long (13-49/64 in)
200. 2444Z2544 [2]  TEE KOB1/4"PTx60mm Long (No O-Ring supplied)
202. 2444Z3817F1 [1]  ELBOW UNION KOBUnion Elbow
203. 2444Z3619 [1]  HYD CONNECTOR KOB
206. 2420R1182D080 [1]  HOSE  HOSE
208. 2432N568 [1]  INSTALLER JIG KOB Superseded by part number: 2432N1751
209. 2432N578 [1]  PLATE KOB
210. 2432N696 [1]  INSTALLER JIG KOB Superseded by part number: 2432N1750
211. 2432N1084 [1]  INSTALLER JIG KOB Superseded by part number: 2432N1752
214. 2444T2524 [1]  HYD CONNECTOR KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100)
215. 2444Z2447F8 [1]  ELBOW UNION KOBUnion Elbow
218. 2420R1183D045 [1]  HOSE KOB
219. 2420R1183D195 [1]  HOSE  HOSE
220. 2444Z4080 [2]  HYD CONNECTOR KOB
223. 2436U1142F1 [1]  PILOT VALVE KOB
224. 2436U1314F1 [1]  VALVE KOB
225. 2406P5346 [1]  PEDAL KOB
226. 24100P2919F4 [1]  LOCK KOB
227. 2414P8766 [1]  TRIM KOB
228. 2412T953 [1]  DECAL KOB
229. 2479Z849 [1]  SWITCH KOB Superseded by part number: 2479Z514
230. 2479Z976D4 [1]  HARNESS KOB
231. 2479Z977 [1]  HARNESS KOB
232. 2479Z1441D2 [1]  HARNESS KOB
234. 2444T2592 [1]  TEE KOB3/8" PF - 1/4" PF (No O-Ring supplied)
238. 2444Z2461 [1]  TEE KOB1/4" PF (Incls. O-Ring ZD12P01100)
244. ZH42X04000 [1]  45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring KOBElbow, 45° -- (Incls. O-Ring 237-6004)
245. 2444Z2894 [1]  90 ELBOW KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100)
249. 2444T2580 [2]  TEE KOB3/8" PF x 61mm Long (No O-Ring supplied)
250. 2420R1185D045 [1]  HOSE  HOSE
251. 2444R1119D150 [1]  FLEXIBLE HOSE KOB
258. 2420R1182D186 [1]  HOSE
259. 2420R1182D210 [1]  FLEXIBLE HOSE KOBHOSE Superseded by part number: HX21E04210DX
260. 2420R1182D450 [1]  HOSE
261. 2420R1184D060 [1]  HOSE  HOSE
263. 2420R1184D030 [1]  HOSE  HOSE
265. ZS13C06020 [2]  CAPSCREW M06x1.0x20mm  CAPSCREW M06x1.0x20mm
266. ZS18C08025 [2]  SCREW,Hex, M8 x 25mm KOBM08x1.25x25mm
267. ZS23C10016 [1]  SCREW,Hex Socket Head, M10 x 16mm KOBM10x1.50x16mm Superseded by part number: ZS28C10016
268. ZS18C10020 [1]  SCREW,Hex, M10 x 20mm KOBM10x1.50x20mm
269. ZW22X06000 [2]  LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm  LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm
270. ZW26X08000 [2]  LOCK WASHER KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583
271. ZW22K10000 [1]  LOCK WASHER KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm
273. ZW16X10000 [1]  WASHER KOBID 10 x OD 21 x Th 2.0mm
274. 2420Z2185 [2]  GROMMET KOB
