Pos.	Part No	Qty	Parts name	Comments
1-54.	NSS	[1]	NOT SOLD SEPARAT	CONINJECTION PUMP ASSY A TYPE NO 0901004200 (ME039621) (FOR M0 ONLY)
1-2A.	VA1901101850	[1]	HOUSING,PUMP
1.	NSS	[1]	NOT SOLD SEPARAT	CONHOUSING,PUMP
1A.	VA0902210030	[1]	HYD CONNECTOR	KOBADAPTER
1B.	VA0902410010	[1]	PLUG	KOBAIR BREATHER ASSY
2.	VA9490430010	[1]	STUD
2A.	VA9490431630	[2]	STUD
3.	VA0901501820	[6]	PUMP ELEMENT SUB ASSY (FOR M0,M3 ONLY)
3.	VA0901502850	[6]	ELEMENT PUMP ELEMENT SUB ASSY (FOR M2 ONLY)	ELEMENT PUMP ELEMENT SUB ASSY (FOR M2 ONLY)
3.	VA0901502780	[6]	PUMP ELEMENT SUB ASSY (FOR M4 ONLY)
3.	VA0901502620	[6]	PUMP ELEMENT SUB ASSY (FOR M5 ONLY)
4.	VA0901401070	[6]	VALVE SEAT	KOBDELIVERY VALVE ASSY (FOR M0,M2,M3 ONLY)
4.	VA0901400780	[6]	DELIVERY VALVE ASSY (FOR M5 ONLY)
4.	VA0901401250	[6]	STD INLET VALVE	KOBSTD ENGINE INLET VALVE DELIVERY VALVE ASSY (FOR M2,M5 ONLY) Superseded by part number: VAME703516
5.	VA0901370110	[6]	GASKET GASKET,DELIVERY/V	GASKET GASKET,DELIVERY/V
6.	VA0901360490	[6]	SPRING,DELIVERY/V (FOR M0,M5 ONLY)
6.	VA0901360630	[6]	SPRING,DELIVERY/V (FOR M2,M3,M4 ONLY)
6A.	VA0901330140	[6]	STOPPER,DELIVERY/V
6B.	VA9080110180	[6]	O-RING	KOBO-RING
6C.	VA9020804610	[1]	WASHER T = 0.1
6C.	VA9021804620	[1]	WASHER T = 0.2
6C.	VA9490135140	[1]	WASHER T=0.15
7.	VA0901310420	[6]	CLAMP	KOBHOLDER,DELIVERY/V
a.	VA0902120010	[1]	RACK,CONTROL
9.	VA0902150010	[1]	SCREW,GUIDE
10.	VA0901610160	[6]	SLEEVE,CONTROL (FOR M0,M3 ONLY)
10.	VA0901610330	[6]	SLEEVE,CONTROL (FOR M2,M4,M5 ONLY)
11.	VA0901560010	[6]	PINION,CONTROL
12.	VA0901570010	[6]	SCREW,CLAMP
13.	VA0901630010	[6]	SEAT,SPG UPPER
14.	VA0901640010	[6]	SPRING,PLUNGER
15.	VA0901650010	[6]	SEAT,SPG LOWER
16.	VA0901700130	[6]	TAPPET ASSY
17.	VA0901890060	[6]	PLUG,SCREW
18.	VA0901910620	[1]	CAMSHAFT
20.	VA9491010120	[1]	BEARING,ROLLER
20A.	VA9491010071	[1]	BEARING,ROLLER
21.	VA0901930020	[1]	RING,ADJUST
21A.	VA0901930050	[1]	RING,ADJUST
23.	VA0902010351	[1]	COVER,BRG
29-29D.	VA0902700691	[1]	COVER PLATE ASSY
29.	VA0902600130	[1]	PLATE,COVER
29C.	VA0902430030	[2]	PACKING PACKING	PACKING PACKING
29D.	VA0902760020	[2]	SCREW
31.	VA0902300031	[3]	LOCK PLATE SET
37.	VA9491400060	[1]	Q-RING
37A.	VA0902060040	[1]	GASKET GASKET,BRG COVER	GASKET GASKET,BRG COVER
39.	VA0903610040	[1]	BEARING,CTR
40.	VA0903660021	[2]	SCREW,GUIDE
41.	VA9490181030	[2]	WASHER,PLAIN
43.	VA0903100170	[1]	OVER FLOW VALVE ASSY (FOR M0,M3 ONLY)
43.	VA0903100080	[1]	VALVE OVER FLOW VALVE ASSY (FOR M2,M4 ONLY)	VALVE OVER FLOW VALVE ASSY (FOR M2,M4 ONLY)
43.	VA0903100110	[1]	VALVE OVERF OVER FLOW VALVE ASSY (FOR M5 ONLY)	VALVE OVERF OVER FLOW VALVE ASSY (FOR M5 ONLY)
44.	VA0902220070	[4]	WASHER	KOBWASHER Superseded by part number: VA0594601401
45.	VA9491800310	[1]	JACK SCREW	KOBSCREW,HOLLOW
47.	VA9491400380	[1]	O-RING 0-RING	O-RING 0-RING
48.	VA9491800060	[1]	SCREW	KOBSCREW,HOLLOW
50.	VA0902510010	[2]	WASHER	KOBWASHER
51.	VA0901940010	[1]	SHIM T=0.10
51.	VA0901940020	[1]	SHIM T=0.12
51.	VA0901940030	[1]	SHIM T=0.14
51.	VA0901940040	[1]	SHIM T=0.16
51.	VA0901940050	[1]	SHIM T=0.18
51.	VA0901940060	[1]	SHIM T=0.50
51.	VA0901940110	[1]	SHIM T=0.30
51.	VA0901940290	[1]	SHIM T=0.20
51A.	VA0901940070	[1]	SHIM T=0.10
51A.	VA0901940080	[1]	SHIM T=0.15
51A.	VA0901940090	[1]	SHIM T=0.30
51A.	VA0901940100	[1]	SHIM T=0.50
54.	VA9141806201	[4]	BOLT,W/WSR
55.	VA0900180081	[1]	COVER,CONTROL RACK
56.	VA9490140210	[1]	WA5HER, 5PG
57.	VA0900120220	[1]	NUT,TIMER ROUND
55.	VA9491300210	[1]	KEY,WOODRUFF
61.	VA9491402840	[1]	O-RING 0-RING	O-RING 0-RING
63.	VA9490502680	[4]	NUT
64.	VA9490115020	[4]	WASHER
65.	VA0900920100	[1]	BRACKET
