纽荷兰零件查询(CV1100) - VIBRATORY ROLLER (7/01-) (12-001-00[01]) - CHASSIS New Holland Constructuion

作者：广数供应链运营团队

浏览数：

时间：2025-01-21 19:19:58

Pos.	Part No	Qty	Parts name	Comments
1.	ND054164	[1]	PIN	STA
2.	ND052387	[1]	PIN	STA
3.	ND030891	[1]	COVER	STA
4.	ND052500	[2]	FLEXIBLE HOSE	STA
5.	ND103151	[1]	DOOR	STA
6.	ND018499	[1]	SUPPORT	STA
7.	ND031973	[1]	COVER	STA
8.	ND103152	[1]	DOOR	STA
9.	ND103160	[1]	DOOR	STA
10.	ND103146	[1]	SUPPORT	STA
11.	ND048918	[1]	PIN	STA
12.	ND048624	[1]	PLATE	STA
13.	ND049010	[1]	PIN	STA Superseded by part number: ND118345
14.	ND052389	[1]	PIN	STA
15.	ND030796	[1]	TIE-ROD	STA
16.	ND030875	[1]	COVER	STA
17.	ND052503	[3]	TIE-ROD	STA
18.	ND049548	[4]	WASHER	STA
19.	ND049782	[4]	HINGE	STA
21.	ND103134	[2]	COVER	STA
22.	ND031350	[1]	PLATE	STA
24.	ND031643	[1]	PARTITION	STA
25.	ND049707	[4]	COVER PLATE	STA
26.	ND018489	[1]	COVER	STA
28.	ND103186	[1]	SHIELD	STA
29.	ND103167	[1]	RUBBER PAD	STA
31.	ND069432	[1]	FLOAT	STA
33.	ND051282	[8]	WASHER	STA
34.	ND103114	[1]	GUARD	STA
35.	ND103194	[1]	SHIELD	STA
36.	ND103193	[1]	PAD	STA
37.	ND090748	[3]	STEP	STA
38.	ND090769	[1]	FILLER CAP	STA
39.	ND065647	[1]	PLUG	STA
41.	ND090802	[1]	SCREEN	STA
42.	ND021289	[4]	BOLT	STAM6 x 20
43.	ND024121	[7]	BOLT	STAM5 x 12
44.	ND021183	[2]	BOLT	STAM8 x 30
45.	ND023792	[1]	BOLT	STAM5 x 16 Superseded by part number: ND110229
48.	ND021293	[15]	BOLT	STAM8 x 16
49.	ND021184	[4]	BOLT	STAM8 x 35
50.	ND021294	[15]	BOLT	STAM8 x 20
51.	ND023825	[12]	SCREW	STAM10 x 16 Superseded by part number: ND092562
52.	ND024702	[28]	STUD	STAM10 x 16
53.	ND021301	[8]	BOLT	STAM10 x 20
54.	ND021302	[4]	BOLT	STAM10 x 25
56.	ND021846	[2]	NUT	STAM5
57.	ND021848	[31]	NUT	STAM8 Superseded by part number: ND034087
58.	ND034088	[32]	NUT	STA
59.	ND021847	[5]	NUT	STAM6
60.	ND026461	[2]	NUT	STAM6
62.	ND029308	[3]	WASHER	STAID 5,1
63.	ND029247	[8]	WASHER	STAID 5,3
64.	ND029310	[32]	WASHER	STAID 8,2
65.	ND029249	[5]	WASHER	STAID 8,4
66.	ND029311	[8]	WASHER	STAID 10,2
67.	ND029250	[13]	WASHER	STAID 10,5
69.	ND029276	[1]	WASHER	STAID 30
70.	ND029309	[4]	SPRING WASHER	STAID 6.1
71.	ND029248	[4]	WASHER	STAID 6,4
73.	ND079083	[1]	BUMPER	STA
74.	ND064758	[4]	PLUG	STA
75.	ND079228	[2]	BUMPER	STA
78.	ND029374	[1]	COTTER PIN	STA3,2 x 20
79.	ND029396	[1]	COTTER PIN	STA6,3 x 40
83.	ND101584	[1]	TAPE	STA
87.	ND073360	[2]	PACKING RING	STA24 x 30 x 2
88.	ND103102	[1]	FRAME	STA
