| 1. | D8NN4010JA | [1] | AXLE HOUSING | FORR.H. Superseded by part number: 83934812 |
| 1. | D0NN4011A | [1] | BELL HOUSING | BASL.H., Includes: Ref. 2 thru 4 Superseded by part number: D8NN4011GA |
| 2. | NDA4222A | [2] | BEARING ASSY,73.05 mm ID x 112.7379 mm OD x 25.527 mm | GI Superseded by part number: 81803416 |
| 3. | NDA4221A | [2] | BEARING ASSY,73.05 mm ID x 112.7379 mm OD x 25.527 mm | GI Superseded by part number: 81803410 |
| 4. | E3NN4969BA | [2] | RETAINER | BAS Superseded by part number: C5NN4969E |
| 5. | D0NN4244A | [2] | SHAFT | BASIncludes: Ref. 6 Superseded by part number: E3NN4244CA |
| 6. | C5NN1N118J | [16] | BOLT | FOR Superseded by part number: 81815607 |
| 6. | 9809140 | [16] | BOLT | FOR |
| 7. | 83417133 | [2] | O-RING,3.63mm Thk x 336.91mm ID | FOR |
| 8. | 304955S36 | [1] | BOLT,Hex, 5/8"-11 x 3 3/4", G5 | BASScrew, Cap, HH, G5, 5/8"-11 x 3-3/4" Superseded by part number: 16445 |
| 9. | TUAA1243A | [2] | BEARING CUP,3.626" ID x 6.001" OD x 1.5685" | WIN Superseded by part number: 272684 |
| 10. | 377525S | [4] | STUD | FOR Superseded by part number: 83417087 |
| 11. | 87996 | [12] | BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5 | WINBolt, Hex, 1/2"-13 x 4 1/2", G5 |
| 12. | 280963 | [16] | NUT,Nut, 1/2-20 GR 5 ZND | NHNut, G5, 1/2"-20 |
| 13. | C7NN4N029F | [2] | GEAR REDUCTION UNIT | FOR |
| 13. | D0NN4N029A | [2] | PINION CARRIER | BASGEAR CARRIER Superseded by part number: 81802412, 81802412, C5NN4A007A, 81802412, C5NN4A007A, C5NN4A008A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, D0NN4N030A, 81802412, C5NN4A007A, C5NN4A008A, D0NN4044A, D0NN4048A, D0NN4N030A, DAPN4013A |
| . . | C7NN4N030E | [2] | SUPPORT | FOR Superseded by part number: 83928243 |
| . . | D0NN4N030A | [2] | CARRIER | BASIncludes: Ref. 14 thru 20 Superseded by part number: 82936258 |
| 14. | C7NN4N031C | [2] | RETAINER,4.52" ID | FOR Superseded by part number: 81820847 |
| 15. | TAJAA1244A | [2] | BEARING ASSY,3.751" ID x 6.001" OD x 1.562" | FOR Superseded by part number: 81802412 |
| 16. | C7NN4048D | [6] | SHAFT | FOR Superseded by part number: 81820848 |
| 16. | D0NN4048A | [6] | SHAFT | BAS Superseded by part number: 81823521 |
| 17. | C5NN4044A | [6] | GEAR | FOR Superseded by part number: 81803329 |
| 17. | D0NN4044A | [6] | GEAR,20 Teeth | BAS Superseded by part number: 81823520 |
| 18. | 81803272 | [12] | THRUST WASHER,45.92mm ID x 67.69mm OD x 0.81mm Thk | FORWASHER,THRUST |
| 19. | C5NN4A008A | [6] | SPACER | FOR Superseded by part number: 81803274 |
| 20. | CFPN4013A | [6] | KIT | FOR Superseded by part number: 81823609 |
| 20. | DAPN4013A | [6] | KIT | BAS Superseded by part number: 81823554 |
| 21. | C5NN4374AC | [1] | SPACER | FOR Superseded by part number: 81803492 |
| 21. | C5NN4374A | [1] | SPACER | FOR Superseded by part number: 81803490 |
| 21. | C5NN4374B | [1] | SPACER | FOR Superseded by part number: 81803493 |
| 21. | C5NN4374C | [1] | SPACER | FOR |
| 21. | C5NN4374D | [1] | SHIM,mm ID x 66.55mm OD x 1.68mm Thk | FOR |
| 21. | C5NN4374E | [1] | SPACER | FOR |
| 21. | C5NN4374F | [1] | SPACER | FOR Superseded by part number: 81803497 |
| 21. | C5NN4374G | [1] | SPACER | FOR |
| 21. | C5NN4374H | [1] | SPACER | FOR |
| 21. | C5NN4374J | [1] | SPACER | FOR |
| 21. | C5NN4374K | [1] | SPACER | FOR |
| 21A. | 81823557 | [1] | SPACER | A Superseded by part number: 81803491 |
| 21A. | D0NN4374B | [1] | SPACER | BAS Superseded by part number: C5NN4374L |
| 21A. | D0NN4374C | [1] | SPACER | BAS Superseded by part number: C5NN4374M |
| 21A. | 81823560 | [1] | SPACER | A Superseded by part number: C5NN4374D |
| 21A. | 81823561 | [1] | SPACER | A |
| 21A. | 81823562 | [1] | SPACER | A |
| 21A. | 81823563 | [1] | SPACER | A Superseded by part number: 81803507 |
| 21A. | D0NN4374H | [1] | SPACER | BAS Superseded by part number: C5NN4374U |
| 21A. | D0NN4374J | [1] | SPACER | BAS Superseded by part number: C5NN4374V |
| 21A. | 81823566 | [1] | SPACER | A Superseded by part number: 81803510 |
| 21A. | 81823567 | [1] | SPACER | A Superseded by part number: 81803511 |
| 22. | C5NN4N237A | [2] | BEARING WASHER,38.1mm ID x 81.28mm OD x 12.649mm | FOR Superseded by part number: 81803449 |
| 22A. | D0NN4N237A | [2] | WASHER | BAS Superseded by part number: 81823556 |
| 23. | C5NN4N240B | [2] | BUCKLE | FOR Superseded by part number: 82847560 |
| 23A. | D0NN4N240A | [2] | LOCKING PLATE | BAS Superseded by part number: 81823525 |
| 24. | 88969 | [2] | BOLT,Hex, 9/16" - 18 x 1 1/2", Gr 5 | GIScrew, Cap, HH, G5, 9/16"-18 x 1-1/2" |
| 24. | 304842S36 | [2] | BOLT,Hex, 7/8"-9 x 2", G5 | FOR Superseded by part number: 413-1432 |
| 25. | 81803341 | [2] | RING GEAR | FOR |
| 26. | C5NN4049A | [2] | GEAR | FOR |
| 26. | D0NN4049A | [2] | PLANETARY GEAR | BAS Superseded by part number: 81823522 |
| 27. | NSS | [2] | NOT SERVICED SEPARATELY | CONHousing, Refer to Fig. 3 for Components |
| 29. | 83955514 | [1] | HOUSING | FORR.H. |
| 29. | D4NN2N100A | [1] | HOUSING | FORL.H. Superseded by part number: E4NN2N100CA |
| 30. | 81803515 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.02mm Thk | BAS |
| 30. | C5NN4548B | [1] | SHIM,3.80" ID x 4.40" OD x 0.046" Thk | FOR(1.118/1.168 mm) Superseded by part number: 81803516 |
| 30. | 81803517 | [1] | SHIM,96.52mm ID x 111.76mm OD x 1.32mm Thk | BAS(1.270/1.321 mm)) |
| 30. | C5NN4548D | [1] | SHIM,3.80" ID x 4.40" OD x 0.058" Thk | FOR(1.422/1.473 mm) Superseded by part number: 81803518 |
| 30. | C5NN4548E | [1] | SHIM,3.80" ID x 4.40" OD x 0.064" Thk | FOR(1.575/1.626 mm) Superseded by part number: 81803519 |
| 30. | C5NN4548F | [1] | SHIM,3.80" ID x 4.40" OD x 0.070" Thk | FOR(1.727/1.778 mm) Superseded by part number: 81803520 |
| 30. | C5NN4548G | [1] | SHIM,3.80" x 4.40" x .074/.076" Thk | FOR(1.880/1.930 mm) Superseded by part number: 81803521 |
| 30. | C5NN4548H | [1] | SHIM,3.80" x 4.40" x .080/.082" Thk | FOR(2.032/2.083 mm) Superseded by part number: 81803522 |
| 31. | 510892 | [1] | BEARING CUP,112.71mm OD x 23.81mm W | GIRH |
| . . | 957E4222 | [1] | BEARING ASSY,107.975 mm ID x 158.775 mm OD x 23.02 mm | BASL.H. Superseded by part number: 81803420 |
| 32. | 510884 | [1] | ROLLER BEARING,66.69mm ID x 30.05mm W | WINRH |
| . . | 957E4221 | [1] | BEARING ASSY,107.975 mm ID x 158.775 mm OD x 23.02 mm | BASBearing Assy, Cone & Roller, Rear Axel, Differential, LH Superseded by part number: 81803413 |
| 33. | C5NN4194B | [1] | BLOCK | FOR Superseded by part number: 81803367 |
| 34. | 80680 | [1] | LOCK WASHER,3/8 0.381 CST ZND | NH |
| 35. | 88206 | [1] | BOLT,Hex, 3/8" - 16 x 1", Gr 5 | NH |
