| 1. | 9S-8004 | [9] | PLUG(9/16-18-THD) | |
| 2. | 3J-1907 | [12] | SEAL-O-RING | |
| 3. | 7R-3825 | [1] | KIT-RELIEF VALVE | |
| | | | (INCLUDES PLUG AS, O-RING SEAL, SPRING, POPPET & NUT) |
| 4. | 7X-9232J | [3] | PLUG-VENT(FILTER OIL) | |
| 5. | 9S-4191 | [3] | PLUG(9/16-18-THD) | |
| 6. | 9S-8008 | [2] | PLUG(1-1/16-12-THD) | |
| 7. | 3D-2824 | [2] | SEAL-O-RING | |
| 8. | 9S-8002 | [1] | PLUG(7/16-20-THD) | |
| 9. | 3J-7354 | [1] | SEAL-O-RING | |
| 10. | 229-8393 | [2] | KIT-VALVE | |
| | | | (EACH INCLUDES VALVE & O-RING SEALS) |
| 12. | 426-4845Y | [1] | VALVE GP-PUMP CONTROL | |
| 13. | 7R-3394 | [1] | FITTING | |
| 14. | 7R-3453 | [1] | KEY-WOODRUFF | |
| 15. | 109-5165 | [1] | SHAFT-CHARGE | |
| 16. | 1G-9196 | [1] | PIN | |
| 17. | 108-8537 | [1] | PUMP GP-GEROTOR(CHARGE) | |
| 18. | 1G-9198 | [1] | COUPLING | |
| 19. | 5E-8743 | [2] | BUSHING-TERMINAL | |
| 20. | 109-5166 | [1] | COVER-CHARGE | |
| 21. | 6V-8837M | [6] | BOLT(M6X1X16-MM) | |
| 22. | 5E-8771 | [1] | SEAL-O-RING | |
| 23. | 349-9071 | [1] | FLANGE-ADAPTER | |
| 24. | 7X-2557M | [4] | BOLT(M16X2X140-MM) | |
| 25. | 340-7078 | [1] | SEAL | |
| 26. | 6H-1717 | [2] | BOLT(1/2-13X1.125-IN) | |
| 27. | 6V-5215M | [6] | BOLT(M8X1.25X16-MM) | |
| 28. | 364-0736 | [2] | CYLINDER AS | |
| 29. | 8T-0269M | [4] | BOLT-SOCKET HEAD(M6X1X20-MM) | |
| 30. | 229-8396 | [1] | PLATE-RETAINER | |
| 31. | 319-5224J | [1] | KIT-SEAL | |
| | 1G-9188 | [1] | SEAL-O-RING | |
| | 319-5223 | [1] | SEAL-LIP TYPE | |
| | | | (ALSO INCLUDES SEAL-CARRIER) |
| 32. | 6V-7700 | [1] | RING-RETAINING | |
| 33. | 1G-9185 | [1] | BEARING-ROLLER | |
| 34. | 126-6643 | [1] | SHAFT-PUMP | |
| 35. | 364-0735 | [1] | KIT-SERVO PISTON | |
| 36. | 161-3931 | [2] | POST-GUIDE | |
| 37. | 307-8769 | [1] | LEVELER | |
| 38. | 1G-9182 | [1] | SEAL-O-RING | |
| 39. | 203-8494 | [1] | INSERT AS | |
| 40. | 132-6697JM | [6] | BOLT(M8X1.25X20-MM) | |
| 41. | 5E-8765L | [3] | NUT | |
| 42. | 319-5225 | [1] | COVER | |
| 43. | 456-1382 | [2] | SPRING | |
| 44. | 307-8306 | [2] | SEAT-SPRING | |
| 45. | 203-8505 | [2] | SHIM(0.51-MM THK) | |
| 46. | 077-8353 | [2] | PIN(SPRING) | |
| 47. | 319-5219 | [1] | KIT-BEARING | |
| | | | (INCLUDES CRADLE-BEARINGS) |
| 48. | 319-5226 | [1] | KIT-SWASHPLATE | |
| | | | (INCLUDES SCREW, BOLT, LINKS, SERVO ARM, PINS, WASHER & SWASHPLATE-VARIABLE) |
| 49. | 366-0724 | [1] | BLOCK-SLIDER | |
| 50. | 1G-9193 | [1] | BEARING-JOURNAL | |
| 51. | 126-6640 | [1] | BRACKET-LIFTING | |
| 52. | 8T-0338M | [2] | BOLT-SOCKET HEAD(M8X1.25X45-MM) | |
| 53. | 098-3039 | [1] | WASHER(8.33X15X2.12-MM THK) | |
| 54. | 134-1827 | [1] | SPACER | |
| 55. | 5E-8777 | [2] | PLUG | |
| 56. | 5E-8747 | [2] | VALVE-CHECK | |
| 57. | 126-6638J | [1] | GASKET-END CAP | |
| 58. | 145-6892 | [1] | PLATE-VALVE | |
| 59. | 319-5221Y | [1] | ROTATING GP-PUMP | |
| | | | |
| | | | PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE NUMBER ARE NOT SERVICED SEPARATELY |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 456-1383J | [1] | KIT-SEAL | |
| | | | (INCLUDES BOLTS, NUTS, O-RING SEALS, RING KIT-PISTONS, GASKETS, BACKUP RING & PARTS MARKED "J" IN GRAPHIC) |
| | 456-1384L | [1] | KIT-SEAL | |
| | | | (INCLUDES GASKET, 0-RING SEALS, SEAL KITS & PARTS MARKED "L" IN GRAPHIC) |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | L | | KIT MARKED L SERVICES PART(S) MARKED L |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
