卡特零件查询（AP-655C） 199-4253: DOOR GP-ACCESS

作者：广数供应链运营团队

浏览数：

时间：2025-01-25 08:39:22

Pos.	Part No	Qty	Parts name
1.	3B-4617	[4]	PIN-COTTER
2.	7R-3336	[4]	PIN
3.	108-7756	[3]	ROD(PROP)
4.	111-1777	[11]	BUMPER-RUBBER
5.	141-9203M	[39]	SCREW-BUTTON HEAD(M10X1.5X30-MM)
6.	142-3041B	[3]	SHIM(6-MM THK)
7.	142-5057B	[3]	SHIM(2-MM THK)
8.	152-1061	[3]	BAR
9.	177-1570	[3]	LATCH AS
			(EACH INCLUDES)
	217-0733	[1]	LOCK AS
10.	193-9297	[1]	PLATE(BENT)
11.	198-3133	[1]	HINGE
12.		[2]	HINGE
13.	198-5159	[4]	PLATE
14.	198-5466	[1]	COVER AS
	7X-2484	[1]	LATCH-HANDLE
15.	199-4218	[2]	HINGE
16.	199-4219	[1]	HINGE
17.	199-4220	[2]	BRACKET
18.	199-4226	[2]	BRACKET
19.	199-4236	[1]	DOOR AS
20.	199-4347	[1]	RAIL AS
21.	199-4348	[1]	RAIL AS
22.	199-7509	[1]	PLATE
23.	199-7511	[1]	PLATE
24.	199-7514	[1]	RAIL AS
25.	199-7521	[1]	DOOR AS
26.	204-5700	[1]	COVER
27.	207-1725	[1]	DOOR AS(LH)
	7T-1099	[2]	LINK
	7X-2484	[1]	LATCH-HANDLE
28.	207-1726	[1]	DOOR AS(RH)
	7X-2484	[1]	LATCH-HANDLE
29.	207-1733	[1]	COVER AS(LH)
30.	208-4729	[2]	HINGE
31.	208-6185	[1]	PLATE(BENT)
32.	208-6188	[1]	PLATE(BENT)(ASSEMBLE TO CENTER PLATE)
33.	208-6190	[2]	PLATE
34.	215-6604	[2]	HINGE
35.	215-6605	[2]	HINGE
36.	215-6607	[1]	PLATE AS
37.	215-6608	[1]	PLATE
38.	215-6609	[1]	PLATE AS
39.	215-6612	[1]	PLATE AS
40.	218-7290	[1]	PLATE
41.	218-7317	[1]	PLATE AS
42.	218-7319	[1]	PLATE AS
43.	218-7325	[1]	RAIL AS
44.	238-9819	[1]	DOOR AS
45.	222-2368	[1]	BRACKET
46.	251-3257	[1]	PLATE AS
47.	222-5151	[3]	PAWL
48.	223-2536	[1]	PLATE AS
49.	224-2103	[1]	PLATE AS
50.	229-5008	[1]	SHEET-RUBBER
51.	3B-4618	[3]	PIN-COTTER
52.	4I-3124M	[6]	BOLT(M8X1.25X32-MM)
53.	5C-7261M	[4]	NUT(M8X1.25-THD)
54.	5P-4116	[6]	WASHER-HARD(8.8X20.5X2-MM THK)
55.	8C-8585M	[20]	SCREW-BUTTON HEAD(M10X1.5X20-MM)
56.	8T-3991M	[3]	SCREW-BUTTON HEAD(M6X1X20-MM)
57.	8T-4121	[154]	WASHER-HARD(11X21X2.5-MM THK)
58.	8T-4133M	[93]	NUT(M10X1.5-THD)
59.	8T-4136M	[29]	BOLT(M10X1.5X25-MM)
60.	8T-4137M	[19]	BOLT(M10X1.5X20-MM)
61.	8T-4183M	[1]	BOLT(M12X1.75X40-MM)
62.	8T-4184M	[2]	BOLT(M12X1.75X45-MM)
63.	8T-4186M	[1]	BOLT(M10X1.5X40-MM)
64.	8T-4189M	[4]	BOLT(M8X1.25X20-MM)
65.	8T-4195M	[7]	BOLT(M10X1.5X30-MM)
66.	8T-4196M	[5]	BOLT(M10X1.5X35-MM)
67.	8T-4223	[7]	WASHER-HARD(13.5X25.5X3-MM THK)
68.	8T-4224	[12]	WASHER-HARD(8.8X16X2-MM THK)
69.	8T-4244M	[4]	NUT(M12X1.75-THD)
70.	8T-6868M	[1]	BOLT(M12X1.75X80-MM)
71.	8T-7547M	[2]	BOLT(M8X1.25X30-MM)
72.	5P-8309BE		SEAL
	B		USE AS REQUIRED
	E		ORDER BY THE CENTIMETER
	M		METRIC PART
