| | 122-9303LY | [1] | BUFFER GP-SENSOR(500-HZ PWM) | |
| | 122-9309NY | [1] | BUFFER GP-SENSOR(5000-HZ PWM) | |
| | 168-3551Y | [1] | SENSOR GP-POSITION(STEERING) | |
| | 266-1478Y | [1] | SENSOR GP-POSITION(ROTARY) | |
| | 1V-6652QY | [1] | SWITCH AS-TOGGLE(FUEL PUMP CONTROL) | |
| | | | |
| | 6T-3643H | [2] | CIRCUIT BREAKER AS(15-AMPERE) | |
| | 6T-3642J | [1] | CIRCUIT BREAKER AS(10-AMPERE) | |
| | 6T-3644 | [1] | CIRCUIT BREAKER AS(20-AMPERE) | |
| | | | (EACH CIRCUIT BREAKER AS INCLUDES) |
| | 6V-8376 | [2] | SCREW-MACHINE(8-32X0.25-IN) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| | 171-2208 | [1] | CIRCUIT BREAKER AS(60-AMPERE) | |
| | 4E-5724 | [2] | WASHER(7X12X1-MM THK) | |
| | 8T-0122 | [2] | NUT-FULL(1/4-28-THD) | |
| | 253-2111 | [2] | LOCKWASHER | |
| | 145-7883W | [1] | HARNESS AS-PANEL(POTENTIOMETER) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 110-6824 | [1] | POTENTIOMETER(ENGINE SPEED) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-1813E | | SLEEVE(139-CM) | |
| | 270-8384 | [1] | POTENTIOMETER AS(ENGINE SPEED) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 5P-5623D | | WIRE-ELECTRICAL(16-GA, BLACK)(0.9-M) | |
| | 6V-2689D | | TUBE-HEAT SHRINK(6.35-MM DIA)(0.1-M) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9X-1813E | | SLEEVE(25-CM) | |
| | | | -OR- |
| | 378-3321 | [1] | POTENTIOMETER AS(ENGINE SPEED) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 5P-5677D | | WIRE(18-GA, BLACK)(0.9-M) | |
| | 8T-6342E | | TUBE-HEAT SHRINK(3.2-MM DIA)(10-CM) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9X-1813E | | SLEEVE(25-CM) | |
| | 3E-6477 | [1] | RELAY AS(24-VOLT) | |
| | 105-4684 | [1] | RELAY AS(24-VOLT)(GRADE, SLOPE) | |
| | 255-5011 | [1] | RELAY AS(24-VOLT)(SCREED CONTROL) | |
| | 3D-9718X | [1] | SWITCH AS-PUSH BUTTON(SCREED HORN) | |
| | 6V-8376 | [2] | SCREW-MACHINE(8-32X0.25-IN) | |
| | 6V-8832 | [1] | NUT(5/8-32-THD) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| | 246-8912TV | [2] | SWITCH GP-TOGGLE(FEEDER CONTROL) | |
| | 8C-9812 | [2] | SWITCH AS-TOGGLE(FEEDER CONTROL) | |
| | 109-7187 | [1] | SWITCH AS-TOGGLE(SCREED HOIST) | |
| | | | (EACH SWITCH AS-TOGGLE INCLUDES) |
| | 3L-8187 | [3] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [3] | SCREW-MACHINE(6-32X0.25-IN) | |
| | 7N-8008S | [1] | SWITCH AS-TOGGLE(THROTTLE CONTROL) | |
| | 3L-8187 | [6] | LOCKWASHER | |
| | 6T-3631 | [2] | NUT-HEX(15/32-32-THD) | |
| | 6T-3632 | [1] | LOCKWASHER | |
| | 6T-3633 | [1] | RING-LOCKING | |
| | 6V-8374 | [6] | SCREW-MACHINE(6-32X0.25-IN) | |
| | 4D-1836P | [2] | SWITCH-TOGGLE(VIBRATORY CONTROL) | |
| | | | |
| | 116-5277 | [2] | BLOCK(CONTACT) | |
| | 245-7724 | [1] | ELEMENT-COUPLING | |
| | 254-6825 | [2] | GLOW PLUG(24-VOLT) | |
| | 8M-6176 | [1] | LAMP(12-VOLT) | |
| | 116-5270 | [1] | LAMP(24-VOLT) | |
| | 7N-5876 | [10] | LAMP(24-VOLT, 0.2-AMPERE) | |
| | 187-9608 | [1] | NOZZLE(BURNER) | |
| | 6R-4315 | [1] | NOZZLE(SPRAY DOWN) | |
| | 8T-0315 | [3] | SEAL-O-RING | |
| | 2H-3934 | [3] | SEAL-O-RING | |
| | 2M-9780 | [3] | SEAL-O-RING | |
| | 2S-4078 | [3] | SEAL-O-RING | |
| | 4K-1388 | [3] | SEAL-O-RING | |
| | 6K-6307 | [3] | SEAL-O-RING | |
| | 6V-8400 | [3] | SEAL-O-RING | |
| | 7J-9108 | [3] | SEAL-O-RING | |
| | 7M-8485 | [3] | SEAL-O-RING | |
| | 3D-2824 | [3] | SEAL-O-RING | |
| | 3J-1907 | [3] | SEAL-O-RING | |
| | 3J-7354 | [3] | SEAL-O-RING | |
| | 3K-0360 | [3] | SEAL-O-RING | |
| | 4J-5477 | [3] | SEAL-O-RING | |
| | 5K-9090 | [3] | SEAL-O-RING | |
| | 6V-8397 | [3] | SEAL-O-RING | |
| | 6V-8398 | [3] | SEAL-O-RING | |
| | 6V-9746 | [3] | SEAL-O-RING | |
| | 077-4701 | [1] | SWITCH(PROPEL MODE) | |
| | 9U-6219 | [1] | TOOL BOX | |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | H | | USED FOR FEEDERS, FUEL, PROPEL, SCREED, WORK LIGHTS |
| | J | | USED FOR BEACON, EXTENDERS, GRADE, LIFT, SCREED HORN, VIBRATOR |
| | L | | USED FOR FEEDER |
| | N | | USED FOR PROPEL |
| | P | | USED FOR FRONT WHEEL ASSIST, HAZARD BEACON, SCREED ASSIST, VIBRATOR, WORK LIGHTS |
| | Q | | USED FOR BURNER SPRAY, FUEL PUMP |
| | S | | USED FOR SCREED CROWN, SCREED HEIGHT, SCREED SLOPE, THROTTLE |
| | T | | USED FOR EXTENDERS,FEEDERS DISPLAY MODE,GRADE JOG,HOPPERS,PROPEL DISPLAY MODE |
| | V | | USED FOR SCREED DISPLAY MODE, FEEDERS |
| | W | | USED FOR FEEDER POTENTIOMETER, SPEED POTENTIOMETER |
| | X | | USED FOR ENGINE HEAT, SCREED HORN |
| | Y | | SEPARATE ILLUSTRATION |
