| 1. | 138-7139Y | [1] | STEERING COLUMN GP | |
| 2. | 185-7234 | [1] | SUPPORT AS | |
| 3. | 108-4708 | [1] | CONSOLE AS | |
| | 7T-1099 | [3] | LINK | |
| | 102-2868 | [2] | GRIP-HANDLE | |
| 4. | 5P-2228 | [4] | BOLT(1/2-13X1-IN) | |
| 5. | 6V-8188 | [4] | NUT(1/2-13-THD) | |
| 6. | 8T-4223C | [8] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 7. | 5P-1075 | [2] | WASHER-HARD(10.2X22.5X3-MM THK) | |
| 8. | 161-1697 | [2] | PLATE | |
| 9. | 6V-8801 | [4] | NUT(3/8-16-THD) | |
| 10. | 8T-4896 | [10] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 11. | 104-1824 | [1] | BAR | |
| 12. | 5M-3062 | [5] | BOLT(3/8-16X0.75-IN) | |
| 13. | 104-3962 | [1] | COVER AS | |
| | 8T-4223 | [2] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 14. | 081-8353 | [2] | BOLT(3/8-16X0.625-IN)(3/8-16-2A THD) | |
| 15. | 3K-6060 | [2] | LOCKNUT(3/8-16-THD) | |
| 16. | 108-4678 | [1] | PLATE | |
| 17. | 7V-5547 | [2] | BOLT-SPECIAL | |
| 18. | 108-6247 | [1] | EYEBOLT | |
| 19. | 8T-9393 | [4] | BOLT(5/8-11X1.5-IN) | |
| 20. | 141-4760 | [1] | PLATE-COVER | |
| 21. | 7X-0594 | [2] | WASHER-HARD(20X38X3-MM THK) | |
| 22. | 140-8372 | [2] | CLAMP AS | |
| 23. | 2K-3673 | [1] | BOLT-TRUNNION(5/8-11X1.84-IN)(5/8-11 NC THD) | |
| 24. | 170-3495C | [4] | BEARING AS | |
| 25. | 1D-5118 | [2] | NUT-JAM(5/8-11-THD) | |
| 26. | 7X-0346 | [5] | BOLT(5/8-11X2-IN) | |
| 27. | 7X-0448 | [3] | NUT(5/8-11-THD) | |
| 28. | 109-2776 | [1] | SUPPORT AS | |
| 29. | 4L-6454 | [2] | BOLT(3/8-16X1-IN) | |
| 30. | 109-2777 | [1] | SPRING-EXTENSION | |
| 31. | 169-3653 | [1] | SHAFT AS | |
| 32. | 6V-0894 | [1] | SEAL-O-RING | |
| 33. | 109-2237 | [1] | PEDAL AS | |
| 34. | 8T-4994 | [3] | WASHER-HARD(20X36.5X3.5-MM THK) | |
| 35. | 134-5930 | [3] | SPACER(19X41X12.7-MM THK) | |
| 36. | 8T-7368CM | [2] | SCREW-MACHINE(10-32X28.58-MM) | |
| 37. | 4B-4274 | [9] | WASHER(5.5X13X1.2-MM THK) | |
| 38. | 9X-6270 | [1] | BOLT-SPECIAL | |
| 39. | 4S-6336 | [1] | PLUG-BUTTON | |
| 40. | 114-9949 | [1] | PLATE | |
| 41. | 4B-1282 | [4] | SCREW-MACHINE(1/4-20X0.75-IN) | |
| 42. | 113-0924 | [1] | LATCH | |
| 43. | 3L-2540 | [4] | BOLT-SOCKET HEAD(10-24X0.75-IN) | |
| 44. | 031-0249 | [4] | LOCKNUT(10-24-THD)(10-24 3B THD) | |
| 45. | 8T-9007BE | | SEAL(109CM) | |
| 46. | 6B-6683 | [4] | NUT(5/8-18-THD) | |
| 47. | 8T-4122 | [19] | WASHER-HARD(17X32X3.5-MM THK) | |
| 48. | 8T-4138M | [2] | BOLT(M6X1X20-MM) | |
| 49. | 9X-8256 | [2] | WASHER(6.6X12X2-MM THK) | |
| 50. | 150-6598 | [1] | ARM | |
| 51. | 214-4863Y | [1] | SENSOR GP-POSITION(ROTARY)(BRAKE PEDAL) | |
| 52. | 115-6300 | [1] | PIN AS | |
| 53. | 3L-5919 | [1] | SPRING-GOVERNOR SHAFT | |
| 54. | 4B-2047 | [3] | NUT(10-24-THD) | |
| 55. | 3B-4618 | [1] | PIN-COTTER | |
| 56. | 5L-5976 | [1] | END | |
| 57. | 8T-1688 | [3] | SCREW-MACHINE(10-24X12.7-MM) | |
| 58. | 134-8035 | [1] | CAM & LEVER AS | |
| 59. | 7X-9918 | [1] | GRIP-HANDLE | |
| 60. | 8F-3291 | [1] | PIN | |
| 61. | 030-7571 | [4] | BOLT(3/8-16X1-IN) | |
| 62. | 3B-4621 | [1] | PIN-COTTER | |
| 63. | 166-0691 | [1] | BLOCK AS-MOUNTING(POSITION SENSOR) | |
| 64. | 169-3757 | [1] | BRACKET AS | |
| 65. | 7S-9868C | [4] | FITTING-GREASE | |
| 66. | 8T-7566C | [1] | PIN-SPRING | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
