| 1. | 1A-4168 | [1] | NUT(1-1/4-12-THD) | |
| 2. | 7C-4550 | [1] | SEAL(ROTATING SHAFT) | |
| 3. | 8I-0795 | [1] | BEARING | |
| 4. | 8T-4401 | [1] | BEARING | |
| 5. | 104-7685 | [2] | BOLT AS-SPECIAL(1-14X5-IN) | |
| 6. | 105-9058B | [2] | SHIM(1.5-MM THK) | |
| 7. | 105-9059B | [2] | SHIM(0.51-MM THK) | |
| 8. | 105-9066 | [8] | WASHER-HARD(128.25X165X6.35-MM THK) | |
| 9. | 213-8147 | [1] | POTENTIOMETER AS(TRACTION CONTROL) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 8T-8729 | [1] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 5P-5677E | | WIRE(18-GA, BLACK)(0.3-M EACH) | |
| | 9X-1813E | | SLEEVE(25-CM) | |
| 10. | 302-5962Y | [1] | VALVE GP-FLOW DIVIDER(FRONT WHEEL ASSIST) | |
| 11. | 302-5965Y | [1] | LINES GP-PROPEL(FRONT WHEEL ASSIST) | |
| 12. | 312-2262Y | [1] | BOGIE GP(LH) | |
| 13. | 312-2263Y | [1] | BOGIE GP(RH) | |
| 14. | 316-5717 | [1] | KNOB AS(POTENTIOMETER) | |
| 15. | 335-3074 | [1] | ROD | |
| 16. | 353-5791 | [1] | HARNESS AS-WIRING | |
| 17. | 061-6915 | [1] | NUT(1-1/4-12-THD) | |
| 18. | 3B-4619 | [2] | PIN-COTTER | |
| 19. | 4D-1836 | [1] | SWITCH-TOGGLE(FRONT WHEEL ASSIST) | |
| 20. | 4D-7794 | [1] | CLIP | |
| 21. | 5P-5297 | [2] | RING-RETAINING(EXTERNAL) | |
| 22. | 7K-1181 | [1] | STRAP-CABLE | |
| 23. | 7M-9651 | [2] | NUT-SLOTTED(1-14-THD) | |
| 24. | 8T-4199M | [1] | BOLT(M8X1.25X12-MM) | |
| 25. | 8T-4224 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 26. | 8T-5361 | [4] | WASHER-HARD(28X49X5-MM THK) | |
| | B | | USE AS REQUIRED |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
