| 1. | 6V-8639 | [1] | CONNECTOR | |
| 2. | 6V-8636 | [4] | CONNECTOR | |
| 3. | 6W-0210 | [6] | BOLT(5/16-18X1.5-IN) | |
| 4. | 6V-8781 | [1] | TEE | |
| 5. | 6V-8724 | [1] | ELBOW | |
| 6. | 6V-8627 | [4] | ELBOW | |
| 7. | 6V-8723 | [5] | ELBOW | |
| 8. | 6V-8987 | [2] | ELBOW | |
| 9. | 6V-9168 | [2] | NUT(11/16-16-THD) | |
| 10. | 6V-9836 | [2] | TEE-SWIVEL | |
| 11. | 9S-4185 | [1] | PLUG(3/4-16-THD) | |
| 12. | 6V-9843 | [1] | TEE | |
| 13. | 6V-8634 | [3] | CONNECTOR | |
| 14. | 6V-8936 | [1] | REDUCER | |
| 15. | 6V-8633 | [1] | CONNECTOR | |
| 16. | 6V-4144 | [1] | COUPLER AS-QUICK CONNECT(FLUID SAMPLING) | |
| 17. | 6V-9873 | [1] | CONNECTOR | |
| 18. | 5E-8837 | [2] | ADAPTER | |
| 19. | 5R-6867 | [1] | COUPLER AS-QUICK DISCONNECT(MALE) | |
| 20. | 5R-5677 | [1] | CAP-DUST(DUST) | |
| 21. | 5R-5676 | [1] | PLUG-DUST | |
| 22. | 5R-6868 | [1] | COUPLER AS-QUICK DISCONNECT(FEMALE) | |
| 23. | 3K-0360 | [12] | SEAL-O-RING | |
| 24. | 6V-8398 | [5] | SEAL-O-RING | |
| 25. | 3J-1907 | [13] | SEAL-O-RING | |
| 26. | 6V-8397 | [33] | SEAL-O-RING | |
| 27. | 4J-5477 | [8] | SEAL-O-RING | |
| 28. | 3D-2824 | [1] | SEAL-O-RING | |
| 29. | 3J-7354 | [1] | SEAL-O-RING | |
| 30. | 203-4274Y | [2] | CYLINDER GP-HYDRAULIC(SCREED HOIST) | |
| 31. | 106-1879 | [4] | PIN | |
| 32. | 3B-4629 | [8] | PIN-COTTER | |
| 33. | 203-4275CY | [1] | CYLINDER GP-HYDRAULIC(AUGER RAISE, LOWER) | |
| 34. | 203-4276CY | [1] | CYLINDER GP-HYDRAULIC(AUGER RAISE, LOWER) | |
| 35. | 8C-6868 | [2] | CONNECTOR | |
| 36. | 134-4720Y | [1] | VALVE GP-BANK | |
| 37. | 9B-7237 | [6] | BOLT(3/8-16X1.25-IN) | |
| 38. | 6V-8801 | [6] | NUT(3/8-16-THD) | |
| 39. | 8T-4896 | [14] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 40. | 111-7379 | [1] | PLATE | |
| 41. | 169-0166Y | [1] | VALVE GP-COUNTERBALANCE | |
| 42. | 7X-0264 | [2] | BOLT(1/4-20X2.5-IN) | |
| 43. | 5S-7379 | [2] | BOLT(3/8-16X0.875-IN) | |
| 44. | 8T-4205 | [2] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 45. | 8R-6709I | [1] | HOSE AS | |
| 46. | 154-2821I | [1] | HOSE AS | |
| 47. | 6V-9200 | [1] | ELBOW | |
| 48. | 111-4455I | [1] | HOSE AS | |
| 49. | 128-2748I | [3] | HOSE AS | |
| 50. | 179-1972I | [4] | HOSE AS | |
| 51. | 6V-8729 | [1] | UNION | |
| 52. | 179-1969I | [1] | HOSE AS | |
| 53. | 154-2835I | [4] | HOSE AS | |
| 54. | 154-2837I | [1] | HOSE AS | |
| 55. | 160-6039I | [1] | HOSE AS | |
| 56. | 3S-2093 | [6] | STRAP-CABLE | |
| 57. | 154-1420BE | | SLEEVE | |
| 58. | 6V-9850 | [2] | ELBOW | |
| 59. | 8T-0855 | [1] | GAUGE GP-PRESSURE(SCREED COUNTERBALANCE) | |
| 60. | 6V-3989 | [1] | FITTING | |
| 61. | 1G-9959 | [2] | CLAMP | |
| 62. | 4M-5282 | [2] | BOLT(1/4-20X1.5-IN) | |
| 63. | 7V-5628 | [1] | PLATE | |
| 64. | 6V-9844 | [1] | TEE-SWIVEL | |
| 65. | 6V-0852 | [1] | CAP-DUST | |
| 66. | 168-4988 | [2] | ELBOW | |
| 67. | 6R-3341 | [24] | CLAMP | |
| 68. | 3V-0046 | [14] | PLATE | |
| 69. | 8C-6561C | [12] | BOLT(5/16-18X1.375-IN) | |
| 70. | 154-1425 | [1] | ISOLATOR-GAUGE | |
| 71. | 7R-7964 | [6] | PLATE | |
| 72. | 6W-2463 | [16] | CLAMP | |
| 73. | 7J-8611 | [1] | ELBOW-PIPE | |
| 74. | 6V-8934 | [2] | ADAPTER | |
| 75. | 4P-7581 | [1] | CLIP(LADDER) | |
| 76. | 8T-4224 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 77. | 7K-1181 | [1] | STRAP-CABLE | |
| 78. | 8C-3121C | [2] | BOLT(5/16-18X1.5-IN) | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | E | | ORDER BY THE CENTIMETER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | Y | | SEPARATE ILLUSTRATION |
