| 1. | 143-9644 | [2] | PLATE-RETAINER | |
| 2. | 177-2215 | [3] | STRAP-DUAL CLAMP | |
| 3. | 200-6345 | [5] | SADDLE-MOUNTING(DUAL SWIVEL) | |
| 4. | 204-2281 | [10] | STRAP-CABLE | |
| 5. | 347-4044 | [1] | BRACKET AS | |
| 6. | 348-6675 | [1] | PLATE AS | |
| 7. | 368-8494 | [1] | HARNESS AS-CHASSIS | |
| | 245-1045 | [1] | COVER | |
| | 245-1044 | [2] | LOCK-CONNECTOR | |
| | 9X-3401 | [39] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 127-5485 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 155-2270 | [17] | KIT-CONNECTING PLUG(2-PIN) | |
| | 174-0503 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 245-1042 | [1] | PLUG AS-CONNECTOR(64-PIN) | |
| | 267-7207M | [1] | BOLT-SPECIAL(M6X1-THD) | |
| | 267-7208 | [1] | RING-RETAINING | |
| | 274-4990 | [1] | SEAL | |
| | 245-1048 | [44] | PLUG-CONNECTOR(1-PIN) | |
| | 8T-8737 | [34] | PLUG-SEAL | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 103-0213 | [1] | RECEPTACLE AS-CONNECTOR(70-PIN) | |
| | 134-2540 | [1] | RECEPTACLE AS-CONNECTOR | |
| | 8N-1543 | [1] | SOCKET-CONNECTOR(10-GA) | |
| | 180-9340 | [36] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 267-9572 | [20] | SOCKET-CONNECTION(18-GA) | |
| | 131-1488 | [1] | TERMINAL AS-RING(6-GA TO 8-GA) | |
| | 6H-3586 | [1] | TERMINAL-RING(6-GA TO 8-GA, 1/4-IN SCREW) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(4-CM) | |
| | 131-1492 | [2] | TERMINAL AS-RING(6-GA TO 8-GA) | |
| | | | (EACH INCLUDES) |
| | 3K-4528 | [1] | TERMINAL-RING(6-GA TO 8-GA, 1/2-IN SCREW) | |
| | 119-3662E | | TUBE-HEAT SHRINK(10.85-MM DIA)(4-CM) | |
| | 2L-8071 | [1] | TERMINAL-RING(10-GA TO 12-GA, 1/2-IN SCREW) | |
| | 7N-9017 | [2] | TERMINAL-RING(18-GA TO 22-GA, NO. 10 SCREW) | |
| | 125-7874E | | TUBE-HEAT SHRINK(5.72-MM DIA)(25-CM) | |
| 8. | 372-3307 | [1] | BRACKET | |
| 9. | 096-6166 | [2] | WASHER-HARD(4.5X9X1-MM THK) | |
| 10. | 130-5301 | [5] | CLIP | |
| 11. | 139-0428 | [4] | CLAMP | |
| 12. | 4P-7428 | [1] | CLIP(LADDER) | |
| 13. | 4P-7429 | [2] | CLIP(LADDER) | |
| 14. | 4P-7581 | [2] | CLIP(LADDER) | |
| 15. | 4P-7582 | [2] | CLIP | |
| 16. | 6V-9672M | [2] | SCREW-MACHINE(M4X0.7X16-MM) | |
| 17. | 7K-1181 | [15] | STRAP-CABLE | |
| 18. | 8T-4179M | [2] | BOLT(M12X1.75X20-MM) | |
| 19. | 8T-4200M | [2] | BOLT(M8X1.25X16-MM) | |
| 20. | 8T-4223 | [3] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 21. | 8T-4224 | [2] | WASHER-HARD(8.8X16X2-MM THK) | |
| 22. | 8T-4244M | [1] | NUT(M12X1.75-THD) | |
| 23. | 9X-2480M | [4] | BOLT(M6X1X45-MM) | |
| 24. | 5C-2874M | [1] | NUT(M5X0.8-THD) | |
| 25. | 8T-0328 | [1] | WASHER-HARD(5.5X10X1-MM THK) | |
| 26. | 7E-0976 | [1] | BOOT | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
