| 1. | 106-8704 | [1] | SUPPRESSOR AS-ARC | |
| | 186-3735 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| 2. | 155-2270C | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) |
| 3. | 3P-2404 | [1] | CLIP | |
| 4. | 9W-0844 | [2] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| 5. | 138-8069 | [2] | MOUNTING GP-HYD OIL COOLER | |
| | | | (EACH INCLUDES) |
| | 8T-8912 | [2] | BOLT(5/16-18X2.25-IN) | |
| 6. | 141-7572 | [1] | COOLER AS-HYDRAULIC OIL | |
| 7. | 141-7574 | [1] | FAN AS | |
| 8. | 145-5225I | [1] | HOSE AS | |
| 9. | 142-2659 | [1] | KIT-FAN MOUNTING(HYDRAULIC OIL COOLER) | |
| 10. | 142-5049 | [1] | BRACKET-MOUNTING | |
| 11. | 157-2578I | [1] | HOSE AS | |
| 12. | 172-7049 | [2] | MOUNT AS(LH) | |
| 13. | 172-7053 | [2] | MOUNT AS(RH) | |
| 14. | 172-9253 | [1] | HARNESS AS-MOTOR(HYDRAULIC COOLING FAN) | |
| | 102-8802 | [2] | KIT-RECEPTACLE(2-PIN) | |
| | | | (EACH INCLUDE RECEPTACLE AS & WEDGE) |
| | 155-2270 | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) |
| 15. | 155-2261C | [1] | WEDGE-PLUG LOCK(2-PIN) | |
| 16. | 4L-6454 | [2] | BOLT(3/8-16X1-IN) | |
| 17. | 4M-0061 | [4] | BOLT(5/16-18X0.75-IN) | |
| 18. | 6V-1889 | [10] | CLIP(LOOP) | |
| 19. | 6V-8801 | [2] | NUT(3/8-16-THD) | |
| 20. | 153-6237C | [3] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 6V-9004 | [1] | ELBOW | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| 21. | 3R-2360 | [1] | CLIP | |
| 22. | 164-5567C | [1] | COUPLER AS-QUICK DISCONNECT(MALE) | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-3965 | [1] | FITTING(QUICK DISCONNECT) | |
| 23. | 7K-1181 | [5] | STRAP-CABLE | |
| 24. | 5P-1076 | [1] | WASHER-HARD(13.5X30X4-MM THK) | |
| 25. | 8T-4224 | [6] | WASHER-HARD(8.8X16X2-MM THK) | |
| 26. | 8T-4896 | [1] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 27. | 160-2247G | | SLEEVE-ABRASION(30.71-IN) | |
| 28. | 148-8430C | [1] | TEE AS | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| | 7X-0873 | [1] | TEE | |
| 29. | 6V-0852C | [1] | CAP-DUST | |
| 30. | 8C-3121 | [2] | BOLT(5/16-18X1.5-IN) | |
| 31. | 9X-1386E | | SLEEVE(65-CM) | |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | E | | ORDER BY THE CENTIMETER |
| | G | | ORDER BY THE INCH |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
