| 1. | 3S-2093 | [2] | STRAP-CABLE | |
| 2. | 6G-2256 | [2] | CLAMP | |
| 3. | 336-9301 | [1] | CABLE AS | |
| | 5P-0747E | | CABLE(00-GA, BLACK)(133-CM) | |
| | 1P-0810B | | TAPE-ELECTRICAL | |
| | 235-2678 | [2] | TERMINAL-RING | |
| 4. | 356-9741 | [1] | CABLE AS | |
| | 5P-0761E | | CABLE(00-GA, RED)(81-CM) | |
| | 6V-2722D | | TUBE-HEAT SHRINK(25.4-MM DIA)(0.01-M) | |
| | 8N-0869 | [1] | COVER-TERMINAL(RED) | |
| | 235-2677 | [1] | TERMINAL-RING | |
| | 235-2678 | [1] | TERMINAL-RING | |
| 5. | 459-8366 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 395-2969 | [1] | BRACKET | |
| 6. | 459-8374 | [2] | PLATE AS | |
| | | | (EACH INCLUDES) |
| | 395-2970 | [1] | BRACKET | |
| 7. | 460-0301 | [4] | STUD | |
| 8. | 488-0719 | [1] | PLATE AS | |
| | 9R-9359M | [2] | BOSS(M10X1.5X28-MM) | |
| 9. | 494-0027 | [2] | CABLE AS | |
| | | | (EACH INCLUDES) |
| | 3S-6049 | [1] | TERMINAL AS-BATTERY(POSITIVE) | |
| | 3S-6050 | [1] | TERMINAL AS-BATTERY(NEGATIVE) | |
| | | | (EACH TERMINAL AS-BATTERY INCLUDES) |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| | 7T-9987 | [1] | COVER AS-TERMINAL(RED) | |
| | 7T-9988 | [1] | COVER AS-TERMINAL(BLACK) | |
| | | | (EACH COVER AS-TERMINAL INCLUDES) |
| | 8L-8413 | [1] | STRAP-CABLE(WHITE) | |
| | 159-8049E | | CABLE(00-GA, RED)(32-CM) | |
| 10. | 494-0029 | [1] | CABLE AS | |
| | 1S-7252 | [1] | TERMINAL-CABLE(00-GA, 3/8-IN SCREW) | |
| | 7T-4925 | [1] | COVER-TERMINAL(BLACK) | |
| | 7T-9988 | [1] | COVER AS-TERMINAL(BLACK) | |
| | 8L-8413 | [1] | STRAP-CABLE(WHITE) | |
| | 3S-6050 | [1] | TERMINAL AS-BATTERY(NEGATIVE) | |
| | 9S-5755 | [1] | TERMINAL AS(NEGATIVE) | |
| | | | (EACH TERMINAL AS INCLUDES) |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| | 037-5197 | [1] | BOOT | |
| | 159-8050E | | CABLE(00-GA, BLACK)(80-CM) | |
| 11. | 525-4369 | [1] | CABLE AS | |
| | 3S-6049 | [1] | TERMINAL AS-BATTERY(POSITIVE) | |
| | 9S-5754 | [1] | TERMINAL AS-BATTERY(POSITIVE) | |
| | | | (EACH TERMINAL AS INCLUDES) |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 7T-4924 | [1] | COVER-TERMINAL(RED) | |
| | 8N-0869 | [1] | COVER-TERMINAL(RED) | |
| | 159-8049E | | CABLE(00-GA, RED)(81-CM) | |
| | 235-2677 | [1] | TERMINAL-RING | |
| | 7T-9987 | [1] | COVER AS-TERMINAL(RED) | |
| | 8L-8413 | [1] | STRAP-CABLE(WHITE) | |
| 12. | 115-2422 | [4] | BATTERY GP(12-VOLT, MAINTENANCE FREE, WET) | |
| | | | (EACH INCLUDES) |
| | 123-1373 | [6] | CAP AS-FILLER(7/8-9-THD) | |
| 13. | 263-6342 | [7] | CLIP | |
| 14. | 2G-8767 | [2] | WASHER(10.5X60X3-MM THK) | |
| 15. | 8T-0389M | [4] | LOCKNUT(M10X1.5-THD) | |
| 16. | 8T-4121 | [17] | WASHER-HARD(11X21X2.5-MM THK) | |
| 17. | 8T-4136M | [9] | BOLT(M10X1.5X25-MM) | |
| 18. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 19. | 8T-4195M | [2] | BOLT(M10X1.5X30-MM) | |
| 20. | 8T-4226 | [4] | WASHER-PLATED(10.5X45X3-MM THK) | |
| | B | | USE AS REQUIRED |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
