| | 529-8366Y | [1] | CONTROL GP-DIFFERENTIAL LOCK | |
| | 328-3988Y | [1] | CYLINDER GP-STEERING | |
| | 328-3989Y | [1] | CYLINDER GP-SUSPENSION | |
| | 484-5249Y | [1] | LINES GP-BRAKE(ACCUMULATOR) | |
| | 418-9997Y | [1] | LINES GP-COOLING | |
| | 529-8365Y | [1] | LINES GP-DRAIN(HYDRAULIC FAN MOTOR) | |
| | 538-3749Y | [1] | LINES GP-DRAIN(CASE) | |
| | 377-9292Y | [1] | LINES GP-HOIST | |
| | 377-9329Y | [1] | LINES GP-HYDRAULIC FAN(ATAAC) | |
| | 529-8367Y | [1] | LINES GP-HYDRAULIC FAN(RADIATOR) | |
| | 538-3780Y | [1] | LINES GP-PILOT | |
| | Y | [1] | LINES GP-PRESSURE TEST |
| | 538-3750Y | [1] | LINES GP-PUMP | |
| | 484-5265Y | [1] | LINES GP-RETURN | |
| | 484-5302Y | [1] | LINES GP-SECONDARY STEERING | |
| | 483-9470Y | [1] | LINES GP-SERVICE BRAKE | |
| | 483-9678Y | [1] | LINES GP-STEERING | |
| | 191-6005Y | [1] | PUMP & MTG GP-HYDRAULIC | |
| | 384-7707Y | [1] | PUMP & MTG GP-PISTON | |
| | 388-4101Y | [1] | PUMP & MTG GP-PISTON | |
| | 377-9307Y | [1] | PUMP & MTG GP-SECONDARY STEER | |
| | 378-1303Y | [1] | PUMP & MTG GP-TRANSFER GEAR | |
| | 495-8845Y | [1] | TANK GP-HYDRAULIC | |
| | 377-9316Y | [1] | VALVE & MTG GP-HOIST CONTROL | |
| | 516-5838Y | [1] | VALVE & MTG GP-MAIN CONTROL | |
| | Y | | SEPARATE ILLUSTRATION |
