| 1. | 3S-9643 | [2] | SEAL-LIP TYPE(WATER TEMPERATURE REGULATOR) | |
| 2. | 4N-0641 | [2] | GASKET | |
| 3. | 248-5513 | [2] | REGULATOR-TEMPERATURE(92-DEG C)(COOLANT) | |
| 4. | 107-7954 | [1] | SPACER(10.2X22X8-MM THK) | |
| 5. | 125-0434 | [1] | SEAL-INTEGRAL | |
| 6. | 139-0166 | [1] | TUBE AS | |
| 7. | 139-0170 | [1] | BONNET-OIL COOLER | |
| 8. | 162-8682 | [1] | HOUSING-REGULATOR | |
| 9. | 166-2340 | [1] | SEAL | |
| 10. | 166-3501 | [1] | PIPE | |
| 11. | 196-4813 | [1] | COVER-WATER PUMP | |
| 12. | 197-8006 | [1] | SEAL-O-RING | |
| 13. | 223-7962 | [1] | CORE AS-OIL COOLER(ENGINE OIL) | |
| 14. | 227-8851 | [1] | MANIFOLD-HOUSING | |
| 15. | 231-4549 | [1] | BRACKET | |
| 16. | 248-2772 | [1] | BONNET-OIL COOLER | |
| 17. | 0L-1351 | [2] | BOLT(3/8-16X0.875-IN) | |
| 18. | 0L-1352 | [4] | BOLT(3/8-16X3.25-IN) | |
| 19. | 3B-1915 | [1] | BOLT(3/8-16X1.375-IN) | |
| 20. | 0S-1594 | [10] | BOLT(3/8-16X1-IN) | |
| 21. | 0S-1618 | [1] | BOLT(5/16-18X1-IN) | |
| 22. | 0T-0573 | [2] | BOLT(3/8-16X2.75-IN) | |
| 23. | 109-0076 | [1] | SEAL-O-RING | |
| 24. | 109-0077 | [2] | SEAL-O-RING | |
| 25. | 148-8407 | [1] | PLUG AS | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 9S-4191 | [1] | PLUG(9/16-18-THD) | |
| 26. | | [1] | PLUG AS |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 9S-4183 | [1] | PLUG(1-1/16-12-THD)(1-1/16-12-2A THD) | |
| 27. | 167-4407 | [1] | SEAL-O-RING | |
| 28. | 171-4358 | [2] | SEAL-O-RING | |
| 29. | 4F-0411 | [3] | BOLT(3/8-16X6.5-IN) | |
| 30. | 5M-2894 | [3] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 31. | 6V-5063 | [3] | SEAL-O-RING | |
| 32. | 6V-6609 | [4] | SEAL-O-RING | |
| 33. | 8T-6767 | [1] | PLUG-PIPE(3/8-18-THD) | |
| 34. | 9M-1974 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 35. | 9S-4183 | [3] | PLUG(1-1/16-12-THD)(1-1/16-12-2A THD) | |
| 36. | 9S-4185 | [4] | PLUG(3/4-16-THD) | |
| 37. | 8T-6761 | [1] | PLUG-PIPE(1-11-1/2 NPT THD) | |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
