| | 3E-6389Y | [1] | LAMP GP-DOME(24-VOLT)(CAB) | |
| | 172-9973Y | [1] | LAMP GP-FLOOD(24-VOLT) | |
| | | | |
| | 141-0275 | [1] | LEVER GP-STEERING COLUMN | |
| | 213-8477 | [1] | SWITCH GP-MULTIFUNCTION(TURN SIGNAL, WIPER, WASHER) | |
| | 218-3262 | [1] | SWITCH GP-PARKING BRAKE | |
| | 203-7154 | [1] | SWITCH AS(PARKING BRAKE)(PARKING BRAKE) | |
| | 3E-3377 | [1] | WEDGE-RECEPTACLE LOCK(4-PIN) | |
| | 8T-8729 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9G-3695 | [1] | PLUG-SEAL | |
| | 188-3369 | [1] | KIT-KNOB | |
| | 172-7071 | [2] | SWITCH GP-PRESSURE(SERVICE BRAKE) | |
| | | | (EACH INCLUDES) |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | | | |
| | 162-7264 | [1] | CABLE AS | |
| | 8D-6946 | [1] | FLASHER AS(24-VOLT)(TURN SIGNAL) | |
| | 236-0910 | [1] | HARNESS AS-CAB(HEADLINER) | |
| | 186-3735 | [14] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 245-0160 | [1] | PLUG AS(3-PIN) | |
| | 245-0162 | [1] | PLUG AS(6-PIN) | |
| | 245-8026 | [2] | PLUG AS-CONNECTOR(2-PIN)(2-PIN) | |
| | 8T-8737 | [6] | PLUG-SEAL | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 245-0165 | [1] | RECEPTACLE AS(2-PIN) | |
| | 245-0166 | [1] | RECEPTACLE AS(3-PIN) | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 186-3736 | [14] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 124-8616 | [2] | TERMINAL-RECEPTACLE(18-GA TO 22-GA) | |
| | 124-8617 | [2] | TERMINAL-RECEPTACLE(18-GA TO 22-GA) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2274 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | 155-2260 | [2] | KIT-CONNECTING PLUG(3-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 235-2672 | [1] | HARNESS AS-CAB(SERVICE BRAKE SWITCH) | |
| | 186-3735 | [11] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2274 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 8T-8737 | [2] | PLUG-SEAL | |
| | 245-0170 | [1] | RECEPTACLE AS(12-PIN) | |
| | 186-3736 | [9] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 235-2673 | [1] | HARNESS AS-CAB(MAIN) | |
| | 8N-1548 | [1] | PIN-CONNECTOR(4-GA) | |
| | 186-3735 | [124] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0852 | [6] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 3E-5519 | [1] | PLUG AS-CONNECTOR(5-PIN) | |
| | 9X-1054 | [4] | PLUG AS-CONNECTOR(4-PIN) | |
| | 147-1445 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| | 159-9322 | [1] | SEAL-O-RING | |
| | 147-1446 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| | 159-9322 | [1] | SEAL-O-RING | |
| | 245-0159 | [2] | PLUG AS(2-PIN) | |
| | 245-0162 | [1] | PLUG AS(6-PIN) | |
| | 245-0164 | [2] | PLUG AS(12-PIN) | |
| | 245-8023 | [1] | PLUG AS-CONNECTOR(40-PIN) | |
| | 8T-8737 | [97] | PLUG-SEAL | |
| | 188-6210 | [2] | RECEPTACLE AS-CONNECTOR(1-PIN) | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 245-0171 | [1] | RECEPTACLE AS(8-PIN) | |
| | 245-8020 | [2] | RECEPTACLE AS | |
| | 245-8022 | [1] | RECEPTACLE AS | |
| | 186-3736 | [67] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 9W-0844 | [2] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 180-9340 | [88] | SOCKET-CONNECTOR(14-GA TO 18-GA) | |
| | 131-1490 | [3] | TERMINAL AS(6-GA TO 8-GA) | |
| | 9X-1056 | [21] | TERMINAL-RECEPTACLE(14-GA TO 16-GA) | |
| | 155-2258 | [2] | WEDGE-PLUG LOCK(12-PIN) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 155-2263 | [1] | WEDGE-PLUG LOCK(6-PIN) | |
| | 3E-3389 | [1] | WEDGE-RECEPTACLE LOCK(8-PIN) | |
| | 235-2674 | [1] | HARNESS AS-CAB(OPERATOR CONTROLS) | |
| | 186-3735 | [117] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 245-0160 | [1] | PLUG AS(3-PIN) | |
| | 245-0161 | [1] | PLUG AS(4-PIN) | |
| | 245-0162 | [1] | PLUG AS(6-PIN) | |
| | 245-0164 | [2] | PLUG AS(12-PIN) | |
| | 8T-8737 | [12] | PLUG-SEAL | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 245-8020 | [1] | RECEPTACLE AS | |
| | 245-8022 | [1] | RECEPTACLE AS | |
| | 186-3736 | [39] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 155-2258 | [2] | WEDGE-PLUG LOCK(12-PIN) | |
| | 155-2271 | [1] | KIT-CONNECTING PLUG(4-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 155-2263 | [1] | WEDGE-PLUG LOCK(6-PIN) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 102-8801 | [1] | KIT-RECEPTACLE(12-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 235-3903 | [1] | HARNESS AS-RADIO | |
| | 186-3735 | [12] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 9X-1054 | [1] | PLUG AS-CONNECTOR(4-PIN) | |
| | 245-0159 | [1] | PLUG AS(2-PIN) | |
| | 245-0160 | [2] | PLUG AS(3-PIN) | |
| | 245-0162 | [1] | PLUG AS(6-PIN) | |
| | | [2] | PLUG AS(8-PIN) |
| | 245-0164 | [3] | PLUG AS(12-PIN) | |
| | 8T-8737 | [14] | PLUG-SEAL | |
| | 245-0168 | [1] | RECEPTACLE AS-CONNECTOR(8-PIN) | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 186-3736 | [71] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 5P-4571 | [4] | TERMINAL-BLADE(14-GA TO 16-GA) | |
| | 9X-1056 | [4] | TERMINAL-RECEPTACLE(14-GA TO 16-GA) | |
| | 155-2258 | [3] | WEDGE-PLUG LOCK(12-PIN) | |
| | 155-2259 | [2] | WEDGE-PLUG LOCK(8-PIN) | |
| | 155-2270 | [2] | KIT-CONNECTING PLUG(2-PIN) | |
| | | | (EACH INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 102-8801 | [1] | KIT-RECEPTACLE(12-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 163-6088 | [1] | MODULE AS(INTERMITTENT WIPER) | |
| | 102-8803 | [1] | KIT-RECEPTACLE(3-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 186-3735 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 238-7385 | [1] | PLATE AS | |
| | 245-8682 | [1] | PLATE AS | |
| | 3E-5239 | [6] | RELAY AS(24-VOLT)(BRAKE LIGHT) | |
| | 7G-1060 | [1] | STRAP AS-GROUND | |
| | 9D-4068 | [1] | SWITCH AS-PUSH BUTTON(DOME LIGHT) | |
| | 147-1380 | [1] | SWITCH AS-FOOT(DIFFERENTIAL LOCK) | |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 8T-8729 | [2] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | | | |
| | 8T-4137M | [12] | BOLT(M10X1.5X20-MM) | |
| | 095-0642M | [2] | BOLT-SOCKET HEAD(M5X0.8X50-MM) | |
| | 096-4833M | [2] | BOLT-SOCKET HEAD(M5X0.8X20-MM) | |
| | 4P-7581 | [1] | CLIP(LADDER) | |
| | 5P-9085 | [3] | CLIP(LOOP) | |
| | 6D-3479 | [2] | CLIP(LOOP) | |
| | 6D-4246 | [1] | CLIP(LOOP) | |
| | 8M-2770 | [1] | CLIP(LOOP) | |
| | 8M-2773 | [3] | CLIP(LOOP) | |
| | 124-0174 | [1] | CLIP(LOOP) | |
| | 205-4285 | [1] | CONVERTER-POWER(24-VOLT TO 12-VOLT) | |
| | 5P-6419 | [1] | GROMMET | |
| | 116-5710 | [1] | GROMMET | |
| | 6T-3631 | [1] | NUT-HEX(15/32-32-THD) | |
| | 4V-6981 | [2] | SCREW-BUTTON HEAD(1/4-20X0.75-IN) | |
| | 6V-9491M | [4] | SCREW-MACHINE(M4X0.7X20-MM) | |
| | 8T-0337M | [4] | SCREW-MACHINE(M4X0.7X12-MM) | |
| | 8T-6411M | [6] | SCREW-MACHINE(M6X1X12-MM) | |
| | M | [30] | SCREW-PAN HEAD(M4X0.7X16-MM) |
| | 3J-1907 | [2] | SEAL-O-RING | |
| | 3S-2093 | [50] | STRAP-CABLE | |
| | 7K-1181 | [2] | STRAP-CABLE | |
| | 4B-4863 | [4] | WASHER(4.7X11X1.2-MM THK) | |
| | 8C-9660 | [30] | WASHER(4.6X7.9X0.8-MM THK) | |
| | 9X-8256 | [6] | WASHER(6.6X12X2-MM THK) | |
| | 8T-4121 | [12] | WASHER-HARD(11X21X2.5-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
