| <!-- 3179706 -->Y | [1] | FILM GP(PRODUCT LINK) |
| 336-3545Y | [1] | RADIO GP-COMMUNICATION(PRODUCT LINK 121SR) | |
| 239-9954Y | [1] | CONTROL GP-UNPROGRAMMED(PRODUCT LINK 300) | |
| 262-2043Y | [1] | ELECTRONICS GP-COMMUNICATION(PRODUCT LINK 300) | |
| <!-- COMMENT --> |
|
|
| 263-8948 | [1] | ANTENNA AS(600-CM) | |
| 223-4296 | [1] | ANTENNA(FLEXIBLE) | |
| <!-- COMMENT --> |
| S/N B1L505-2049; B1M411-2195; B1N321-1157; B1P622-3927; B1R194-444; B1W185-340 |
| 310-2393 | [1] | ANTENNA AS(450-CM) | |
| 355-0598 | [1] | NUT-SPECIAL | |
| 301-0589 | [1] | ANTENNA(FLEXIBLE) | |
| <!-- COMMENT --> |
| S/N B1L2050-UP; B1M2196-UP; B1N1158-UP; B1P3928-UP; B1R445-UP; B1W341-UP |
| 274-9047 | [1] | HARNESS AS-CONTROL(RADIO, PRODUCT LINK) | |
| 8T-8729 | [8] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| 160-7690 | [1] | PLUG AS-CONNECTOR(70-PIN) | |
| 159-9322 | [1] | SEAL-O-RING | |
| 245-0164 | [1] | PLUG AS(12-PIN) | |
| 8T-8737 | [64] | PLUG-SEAL | |
| 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| 8T-8730 | [9] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| 194-5226 | [13] | WIRE AS(16-GA) | |
| <!-- COMMENT --> |
| -OR- |
| 194-5227 | [13] | WIRE AS(14-GA) | |
| 155-2258 | [1] | WEDGE-PLUG LOCK(12-PIN) | |
| 102-8801 | [1] | KIT-RECEPTACLE(12-PIN) | |
| <!-- COMMENT --> |
| (INCLUDES RECEPTACLE AS & WEDGE) |
| 273-9763 | [1] | PLATE AS | |
| <!-- COMMENT --> |
| -OR- |
| 388-7601 | [1] | PLATE AS | |
| 278-0298 | [1] | PLATE AS-MOUNTING | |
| 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| 278-0318 | [1] | PLATE AS-MOUNTING | |
| 7T-1099 | [1] | LINK | |
| <!-- COMMENT --> |
| S/N B1L505-2049; B1M411-2195; B1N321-1157; B1P622-3927; B1R194-444; B1W185-340 |
| 317-9750 | [1] | PLATE AS | |
| 7T-1099 | [1] | LINK | |
| <!-- COMMENT --> |
| S/N B1L2050-UP; B1M2196-UP; B1N1158-UP; B1P3928-UP; B1R445-UP; B1W341-UP |
| <!-- COMMENT --> |
|
|
| 5C-9553M | [4] | BOLT(M6X1X16-MM) | |
| 8C-8451M | [4] | BOLT(M6X1X40-MM) | |
| 8T-4136M | [2] | BOLT(M10X1.5X25-MM) | |
| 8T-4137M | [1] | BOLT(M10X1.5X20-MM) | |
| 5P-9085 | [3] | CLIP(LOOP) | |
| 3E-0105 | [3] | MOUNT | |
| 9X-9896 | [8] | MOUNT(ISOLATION) | |
| 2U-5119 | [3] | SCREW | |
| <!-- COMMENT --> |
| S/N B1L505-2107; B1M411-2282; B1N321-1176; B1P622-4144; B1R194-456; B1W185-346 |
| 5I-3166M | [3] | SCREW(M5X0.8X8-MM) | |
| <!-- COMMENT --> |
| S/N B1L2108-UP; B1M2283-UP; B1N1177-UP; B1P4145-UP; B1R457-UP; B1W347-UP |
| 6C-9224 | [3] | SCREW | |
| <!-- COMMENT --> |
| -OR- |
| 375-6042M | [3] | SCREW-HEX FLANGE(M5X0.8X8-MM) | |
| 8C-5608 | [4] | SPACER(6.5X9.5X25.4-MM THK) | |
| 3S-2093 | [16] | STRAP-CABLE | |
| 9X-6165 | [4] | WASHER(6.5X22X2.5-MM THK) | |
| 114-6658 | [3] | WASHER(6.5X17X1-MM THK) | |
| <!-- COMMENT --> |
| -OR- |
| 161-6987 | [3] | WASHER-HARD(5.2X16X1.5-MM THK) | |
| 8T-4121 | [3] | WASHER-HARD(11X21X2.5-MM THK) | |
| <!-- NOTE -->M |
| METRIC PART |
| <!-- NOTE -->Y |
| SEPARATE ILLUSTRATION |
