| 1. | 322996A1 | [1] |
BOX |
CASevaporator |
| 2. | 86990262 | [1] |
CORE |
FAREvaporator And Heater |
| 3. | 322994A1 | [4] |
GASKET,3mm Thk |
CASflange seal |
| 4. | 87306776 | [1] |
CASE ASSY. |
FARTop HVAC |
| 4A. | 87409377 | [1] |
FILTER |
FARRecirculated Air |
| 5. | 87033212 | [1] |
VALVE |
CASthermal expansion HFC-134A |
| 6. | 1250522C3 | [2] |
FITTING |
IHfitting, drain |
| 7. | 1977334C1 | [2] |
HOSE |
IHCut From: 198091C1, 610 mm (24 1/8") |
| 8. | 109239C2 | [2] |
CHECK VALVE |
IHDrain |
| 9. | 86637781 | [1] |
GROMMET,1" ID x 1 3/8" Groove Dia |
FAR |
| 10. | 322989A1 | [1] |
GROMMET |
CASbulkhead, A/C |
| 11. | 322990A1 | [1] |
GROMMET |
CASbulkhead, heater |
| 12. | 87324951 | [1] |
GASKET,3mm Thk |
RACTop Cover, HVAC |
| 13. | 87429903 | [1] |
CONTROL UNIT |
RACmodule, climate |
| 14. | 323611A1 | [1] |
BLOWER |
CAScab, 12V with resistor Superseded by part number: 84222526 |
| 14. | 84222526R | [1] |
REMAN-BLOWER |
RACFLX3010, FLX3510, Both FLOATER, cab, 12V with resistor (8/04-8/06), Reman for New PN 323611A1 |
| 14. | 84222526C | [1] |
CORE-BLOWER |
RACReturn Number |
| 14A. | 323610A1 | [1] |
BLOWER |
CAScab, 12V Superseded by part number: 84222524 |
| . . | 84222524R | [1] |
REMAN-BLOWER |
RACFLX3010, FLX3510 BOTH (8/04-8/06), Reman for New P/N 323610A1 |
| . . | 84222524C | [1] |
CORE-BLOWER |
RACReturn Number |
| 14B. | 360032A1 | [1] |
BRACKET |
CASresistor |
| 14C. | 401360A1 | [1] |
RESISTOR |
CASblower, 12V |
| 15. | 322985A1 | [1] |
HEATER TUBE |
CASheater outlet |
| 16. | 322987A1 | [1] |
HEATER TUBE,0.625" OD, 138.2, 79.2 mm Length |
CASheater inlet |
| 17. | 87306495 | [1] |
COVER |
FARTop HVAC |
| 18. | 427356A1 | [1] |
CONTROL VALVE |
CASAssembly, Heater Superseded by part number: 47644646 |
| 19. | 322995A1 | [4] |
GASKET,3mm Thk |
CASflange seal |
| 20. | 324484A1 | [1] |
INSULATOR |
CASHVAC, bottom |
| 21. | 86517328 | [5] |
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk |
NH |
| 22. | 86508568 | [4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8 |
NH |
| 23. | 83990583 | [4] |
LOCK WASHER,M8 x 14.8mm OD x 2.1mm Thk |
BRR |
| 24. | 43234 | [4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd |
NH |
| 25. | 88538 | [1] |
LOCK WASHER,Ext-Int Tooth, 1/4" |
GI |
| 26. | 86500688 | [4] |
NUT,Hex, M6 x 1.0, Cl 10.9 |
WIN |
| 27. | 86637777 | [2] |
GROMMET,1/2" ID x 13/16" Groove Dia, Diag Cut |
FAR |
| 28. | 1954736C1 | [6] |
HOSE CLAMP,#24 |
IH |
| 29. | 105849A1 | [1] |
RELAY |
CAS20 amp Superseded by part number: 87414866 |
| 30. | 87323959 | [1] |
HARNESS |
RAC |
| 31. | 86625035 | [1] |
CLAMP,12.7mm, Coat, 7.1mm Bolt Hole, P Type |
FAR |
| 32. | 281-14512 | [4] |
SELF-TAP SCREW,Hex Wash Hd, #10 x 3/4" |
CAS Superseded by part number: 86637791 |
| 33. | 322839A1 | [1] |
TUBE,16mm OD, 211.5, 159.8mm Length |
CASA/C suction |
| 34. | 322840A1 | [1] |
TUBE,10mm OD, 158.4, 163.9mm L |
CASA/C liquid |
| 35. | 87323829 | [1] |
SWITCH, A/C LOW PRES |
RAC Superseded by part number: 84419250 |
| 36. | 9827058 | [1] |
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro |
NH |
| 37. | 9827059 | [1] |
O-RING,1.78mm Thk x 14mm ID, 70 Duro |
NH |
| 38. | 1321290C2 | [1] |
HEATER HOSE,15.50 mm ID x 127.00 mm |
IHCut from 97252CX |
| 39. | 324022A1 | [1] |
HEATER HOSE,15.50 mm ID x 54.00 mm |
CASSupply, Cut from : 97252CX |
| 40. | 324023A1 | [1] |
HEATER HOSE,15.50 mm ID x 64.00 mm |
CASSupply, Cut from : 97252CX |
| 42. | 368313A1 | [1] |
PLASTIC PLUG |
CASHVAC |
| 43. | 87306773 | [1] |
FOAM INSULATION |
FARFoil Side |
| 44. | 323016A1 | [1] |
SENSOR |
CASthermistor |
![凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (01-012[02]) - HVAC CCM BREAKDOWN Case Agriculture](https://www.ar-webbuild.com/uploadfile/ueditor/image/202506/1748758670ee2115.png "凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (01-012[02]) - HVAC CCM BREAKDOWN Case Agriculture")
