| 1. |
86983411
|
[1] |
STEERING COLUMN
|
FAR
Assembly, Adjustable
|
| 2. |
343214A1
|
[1] |
PLATE
|
BN
Pump Support
|
| 3. |
140017
|
[6] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 4. |
86500689
|
[4] |
NUT,M10 x 1.5, Cl 10
|
NH
|
| 5. |
450945A1
|
[1] |
STOP DEVICE
|
FAR
Steering Pump Shaft
|
| 6. |
9515003
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9
|
BHB
|
| 7. |
373193A1
|
[1] |
BOOT
|
CAS
Steering
|
| 8. |
301200A1
|
[1] |
STEERING WHEEL
|
CAS
deluxe
|
| 9. |
86625266
|
[1] |
WASHER,17.5mm ID x 30mm OD x 4mm Thk
|
GI
|
| 10. |
86639148
|
[1] |
NUT,M14 x 1.5, Cl 8
|
FAR
|
| 11. |
410874A1
|
[1] |
PUMP
|
BN
steering valve
|
| 12. |
1977448C2
|
[1] |
WASHER
|
IH
Support, Boot
|
| 13. |
361024A3
|
[1] |
CAP
|
CAS
steering wheel, deluxe
|
| 14. |
311748A3
|
[1] |
PEDAL
|
CAS
steering adjust Superseded by part number: 87448446
|
| 15. |
282892A1
|
[2] |
BUSHING,8mm ID x 9.6mm OD x 8mm L
|
CAS
bearing, Nylon
|
| 16. |
86639231
|
[1] |
NUT,M8, Cl 10
|
FAR
|
| 17. |
514-633
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 18. |
311812A1
|
[1] |
SPRING
|
CAS
Extension
|
| 19. |
729-845
|
[1] |
CLEVIS PIN,M8 x 45
|
CAS
Superseded by part number: 86639111
|
| 20. |
86639115
|
[1] |
COTTER PIN,M2 x 12
|
FAR
|
| 21. |
323657A1
|
[1] |
PAD
|
CAS
Foot Release Pedal
|
| 22. |
A59514
|
[4] |
RUBBER BUSHING,13.49mm ID x 34.29mm OD x 41.1mm L
|
CAS
Mount, Front
|
| 23. |
495-81145
|
[4] |
WASHER,13/32" x 1 3/4" x .120"
|
CAS
Superseded by part number: 86637950
|
| 24. |
627-10070
|
[4] |
BOLT,Hex, M10 x 1.5 x 70mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 86639030
|
| 25. |
373194A1
|
[1] |
HOUSING
|
CAS
Boot Mounting
|
| 26. |
86983451
|
[1] |
SEAL
|
FAR
Closed Cell Foam
|
| 27. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 28. |
80043233
|
[2] |
SCREW
|
FOR
Hex, M8 x 20, 10.9 Superseded by part number: 43233
|
| 29. |
214-1580
|
[1] |
HOSE CLAMP,#80, 4.62" - 5.5", Type F Worm, W/ Liner
|
CAS
Superseded by part number: 86637707
|
| 30. |
L100096
|
[1] |
ISOLATOR
|
CAS
Bushing, Steering Noise
|
| 31. |
BN7807271
|
[2] |
SCREW,3/8" - 24 x 1.16"
|
BN
Cap Lock, 12 Pt
|
