| 1. | 515-2395 | [19] |
CLAMP,3/8", Insul, 3/8" Bolt |
CAS Superseded by part number: 86572009 |
| 2. | 121-226 | [18] |
SERRATED BOLT,Hex, 3/8" - 16 x 1" |
CAS Superseded by part number: 87034804 |
| 3. | 232-5316 | [21] |
FLANGE NUT,Flg, 3/8"-16 |
CAS3/8-16 HFTLN GR/G Superseded by part number: 86521609 |
| 4. | 433-512 | [1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5 |
CAS Superseded by part number: 280327 |
| 5. | 496-21034 | [1] |
WASHER,11/32" x 11/16" x 0.89", HDN |
CAS Superseded by part number: 86637953 |
| 6. | 492-11031 | [1] |
LOCK WASHER,5/16" |
CASWASHER, LOCK, 5/16" Superseded by part number: 83990583 |
| 7. | 425-105 | [1] |
NUT,5/16"-18, G5 |
CAS Superseded by part number: 9635082, 72187221 |
| 8. | 700708090 | [3] |
CLAMP |
L3/8 CLAMP Superseded by part number: 86637978 |
| 9. | 425-1512 | [8] |
JAM NUT,Jam, 3/4"-10, G5 |
IH3/4-16 HJN GR2 Superseded by part number: 219758 |
| 10. | 705566 | [8] |
WASHER |
IH3/4 HARDENED PLAIN WASHER |
| 11. | 700706398 | [4] |
SENSOR |
CASPTO SENSOR |
| 12. | 515-23159 | [8] |
CLAMP,5/8", Insul, 3/8" Bolt |
CAS Superseded by part number: 86594406 |
| 13. | 70013064 | [1] |
PRESSURE TRANSDUCER ASM | |
| 14. | 515-25127 | [2] |
CLAMP,1/2", Insul, 1/2" Bolt |
CAS Superseded by part number: 86632595 |
| 15. | 700713985 | [1] |
HARNESS |
CAS-WIRE, MAIN |
| 16. | S95446 | [1] |
CLAMP,1 5/16", Insul, 1/2" Bolt |
CAS1-1/4 CLAMP |
| 17. | 515-23190 | [1] |
CLAMP,3/4", Insul, 3/8" Bolt |
CAS Superseded by part number: 86624005 |
| 18. | 700710188 | [2] |
SCREW |
CAS#6-32 X 3/4 CRPHMS GR2 STLNS |
| 19. | 492-11006 | [2] |
LOCK WASHER,#6 |
CASWasher, Lock, #6 Superseded by part number: 87276 |
| 20. | 225-14106 | [2] |
NUT,#6-32 |
CAS Superseded by part number: 88458, 87779111 |
| 21. | 700706645 | [1] |
TERMINAL STRIP |
CASSTRIP |
| 22. | L18337 | [7] |
CABLE TIE,9.95"-12.1" lg |
CASSTRAP - tie, 15 inch, nylon Superseded by part number: 529070 |
| 23. | 700710751 | [2] |
HARNESS |
CASCABLE |
| 24. | 163-16 | [2] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 3/4" |
CAS1/4-20 X 3/4 HWHMS |
| 25. | 1703354 | [2] |
NUT |
IH1/4-20 HFTLN GR/G |
| 26. | 751321 | [6] |
CLAMP |
CAS1/4 CLAMP Superseded by part number: 80272535 |
| 27. | 413-412 | [2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5 |
CAS Superseded by part number: 9707580, 72187189 |
| 28. | 496-11028 | [6] |
WASHER,9/32" x 5/8" x .065, HDN |
CAS1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587 |
| 29. | 492-11025 | [6] |
LOCK WASHER,1/4" |
CASWASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682 |
| 30. | 425-104 | [6] |
NUT,1/4"-20, Cl 5 |
CAS Superseded by part number: 7770, 72187220 |
| 31. | 700113863 | [3] |
SENSOR |
CASSWITCH ASSEMBLY |
| 32. | 700706340 | [3] |
MAGNET |
CAS |
| 33. | 434-412 | [4] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5 |
CAS1/4-20 X 3/4 RHSNB Superseded by part number: 280638 |
| 34. | 700706459 | [1] |
WIRE HARNESS |
CASHARNESS-CABLE |
| 35. | 529070 | [2] |
CABLE TIE,368.3mm L |
NHTIE-CABLE |
