| 1. |
611362R91
|
[2] |
CHAIN (AG)
|
IH
roller, #60 (10 foot bulk) Superseded by part number: 611362R91X
|
| 2. |
241-1316
|
[2] |
LINK,19.05mm Pitch
|
CAS
connector, #60 R/C
|
| 3. |
861468
|
[1] |
KEY
|
HFI
gib, 5/16 x 2-3/4
|
| 4. |
700135575
|
[1] |
SPROCKET ASSY.
|
HFI
WA 23 tooth
|
| 5. |
95-81182
|
[2] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
BUSHING narrow rim machinery, 3/4 x 14 gauge
|
| 6. |
95-81051
|
[2] |
WASHER,19.84mm ID x 31.75mm OD x 3.81mm Thk
|
CAS
BUSHING narrow rim machinery, 3/4 x 10 gauge
|
| 7. |
700105787
|
[1] |
SPACER
|
HFI
|
| 8. |
700135570
|
[1] |
SPROCKET ASSY.
|
HFI
(Includes Ref. 20 and 21)
|
| 9. |
700135550
|
[1] |
SPACER
|
HFI
|
| 10. |
7770787
|
[1] |
FITTING,Sq Nk, 1/2" - 13 x 4", Gr 5, Full Thd
|
CAS
BOLT full thread round head square neck, 1/2-13 x 4
|
| 11. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 12. |
700135564
|
[1] |
MOUNTING PARTS
|
HFI
WA
|
| 13. |
700135944
|
[1] |
SHIELD
|
HFI
|
| 14. |
7883366
|
[2] |
SCREW,Hex Washer, 3/8" - 16 x 1/2"
|
CAS
hex washer head machine, 3/8-16 x 1/2
|
| 15. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 16. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8 Superseded by part number: 86632588
|
| 17. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
hex flange top lock, 3/8-16 GR/G Superseded by part number: 86521609
|
| 18. |
413-1272
|
[1] |
BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5
|
CAS
SCREW hex cap, 3/4-10 x 4-1/2 Superseded by part number: 88007
|
| 19. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 20. |
100-21175
|
[2] |
SNAP RING,1.75", Int, #175
|
CAS
Superseded by part number: 66967
|
| 21. |
T39594
|
[1] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
