| 1. | 86506979 | [1] |
SHIELD |
NHLH |
| 2. | 86511226 | [1] |
SHIELD |
NHRH |
| 3. | 905-8016 | [8] |
BOLT,Hex Flg, M8 x 16mm |
CAS Superseded by part number: 86511478 |
| 4. | 515-2279 | [3] |
CLAMP,5/16", Insul, 5/16" Bolt |
CAS Superseded by part number: 853764 |
| 5. | 614-10020 | [2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd |
CAS Superseded by part number: 43138 |
| 6. | 892-11010 | [2] |
LOCK WASHER,M10 |
CAS Superseded by part number: 140028 |
| 7. | 134580 | [2] |
WIRE CLAMP,6.3mm, Coat, 10.3mm Bolt Hole, J Type |
NHJ |
| 8. | 825-1410 | [1] |
NUT,M10, Cl 8 |
CAS Superseded by part number: 100016 |
| 9. | 86522001 | [1] |
SHIELD |
NH |
| 10. | 614-6016 | [3] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd |
CAS Superseded by part number: 86508568 |
| 11. | 825-5146 | [6] |
SERRATED NUT,M6, Flg Ser |
CAS Superseded by part number: 86511444 |
| 12. | 237910 | [1] |
WIRE CLAMP,7.9mm, Coat, 7.1mm Bolt Hole, P Type |
NH |
| 12. | 237980 | [1] |
WIRE CLAMP,11.11mm, Coat, 7.14mm Bolt Hole, P Type |
NH7/16" x 1/4" Bolt |
| 13. | 495-11053 | [2] |
WASHER,1/2", SAE |
CAS Superseded by part number: 87364, 72187259 |
| 14. | 694181 | [1] |
MAGNET |
NHTailgate Latch |
| 15. | 495-21044 | [10] |
WASHER,3/8" |
CAS Superseded by part number: 87779090, 80702 |
| 16. | 231-5145 | [16] |
SERRATED NUT,Flg, USR, 5/16"-18 |
CAS Superseded by part number: 72187067, 145458 |
| 17. | 614-4020 | [2] |
BOLT,Hex, M4 x 0.7 x 20mm, Cl 8.8, Full Thd |
CAS Superseded by part number: 412255 |
| 18. | 493-41020 | [1] |
LOCK WASHER,Ext Tooth, #10 |
CAS Superseded by part number: 9672521 |
| 19. | 86500902 | [1] |
POTENTIOMETER,3000 Ohm, 16 VDC |
NHBale Shape Sensing Superseded by part number: 86977396 |
| 20. | 825-5148 | [8] |
SERRATED NUT,M8, Flg Ser |
CAS Superseded by part number: 86505868 |
| 21. | 263117 | [1] |
CABLE TIE,292.1mm L, Nylon, Black |
NHCABLE STRAP |
| 22. | 433-548 | [4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3", Gr 5 |
CAS Superseded by part number: 281006 |
| 23. | 86637389 | [2] |
SPRING |
NHBale Shape |
| 24. | 718782 | [4] |
SPACER |
NH |
| 25. | 495-21031 | [2] |
WASHER,1/4" |
CAS Superseded by part number: 80701, 72187262 |
| 26. | 492-11031 | [4] |
LOCK WASHER,5/16" |
CAS Superseded by part number: 83990583 |
| 27. | 825-1408 | [6] |
NUT,M8, Cl 8 |
CAS Superseded by part number: 43362 |
| 28. | 177822 | [2] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk |
NH21/64" ID x .500" OD x .170" Lg. |
| 29. | 86637391 | [2] |
ARM |
NH |
| 30. | 217465 | [2] |
SPRING |
NHExtension |
| 31. | 614-8020 | [4] |
BOLT,Hex, M8 x 1.25 x 20mm |
CAS Superseded by part number: 120104 |
| 32. | 86619565 | [2] |
SUPPORT |
NH |
| 33. | 86509329 | [2] |
MOUNTING PLATE |
NHIncludes: Ref. 40 Superseded by part number: 87362420 |
| 34. | 100-3437 | [2] |
SNAP RING,#37, Ext |
CAS Superseded by part number: 86000439 |
| 35. | 86592582 | [1] |
WIRE HARNESS |
NHNet-Twine, Refer to Fig. 034 |
| 35. | 86624226 | [1] |
HARNESS |
NHTwine Only, Refer to Fig. 033 |
| 36. | 9848810 | [4] |
SWITCH |
NHHall Effect, Tailgate Latch Superseded by part number: 87019854 |
| 37. | 322358 | [4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk |
NH |
| 38. | 425-105 | [1] |
NUT,5/16"-18, G5 |
CAS Superseded by part number: 9635082, 72187221 |
| 39. | 86613601 | [1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk |
NHUrethane |
| 40. | 86509761 | [2] |
BUSHING |
NH |
