凯斯零件查询(RBX461) - CASE IH ROUND BALER (12/01-12/02) (011) - MAIN FRAME, DRIVE & BACK WRAP ROLLER Case Agriculture

作者：广数供应链运营团队
浏览数：
时间：2025-01-25 21:44:23
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos. Part No Qty Parts name Comments
1. 86521602 [2]   SUPPORT   NH Superseded by part number: 87023400
2. 8050825 [4]   BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm   L Superseded by part number: F82059
3. 9842286 [1]   ROLLER   NH 3-1/2", Non-Silage Units Superseded by part number: 84600572
3. 86517669 [1]   ROLLER,101.6mm OD x 1176mm L   NH 3-1/2", Silage Units Superseded by part number: 84600591
4. 9823371 [1]   SHAFT   NH Includes: Ref. 117 Superseded by part number: 87023402
5. 614-12030 [2]   BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd   IH Superseded by part number: 9706687
6. 86514470 [2]   BUSHING,35.13mm ID x 41.38mm OD x 50.04mm L   NH
7. 86637506 [1]   GUIDE   NH Belt Superseded by part number: 84394681
8. 811-10030 [4]   CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8   CAS Superseded by part number: 86512446
9. 825-51410 [4]   FLANGE NUT,M10, Flg Ser   CAS Superseded by part number: 43435
10. 86637198 [2]   HALF-DISC   NH Infeed
11. 614-10020 [4]   BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd   CAS Superseded by part number: 43138
12. 492-11038 [4]   LOCK WASHER,3/8"   CAS Superseded by part number: 80680, 72187249
13. 86636672 [1]   DRIVE SHAFT   NH Output, 21.33" Long
14. 86636753 [1]   PIN   NH Tailgate Latch Pivot
15. 86636891 [1]   PLATE   NH Support
16. 412093 [2]   SELF-TAP SCREW   NH M6 x 1 x 12
17. 29684 [2]   WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk   NH 17/32" ID x 2" OD x 3/16" Thk
18. 65319 [2]   WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk   NH
19. NSS [1]   NOT SOLD SEPARAT   CON FRAME, Main
20. 134463 [1]   WASHER,.030" Thk   NH
21. 86637016 [1]   LINK CONROD   NH
. . 86636763 [1]   HUB   NH Spacer, Chain Connector, 4mm ID x 12.7mm O
22. 9822495 [2]   BUSHING,25.5mm ID x 31.82mm OD x 19.5mm L   NH
23. 86636886 [1]   BAR   NH
24. 768703 [4]   BUSHING,10.31mm ID x 15.88mm OD x 11.13mm L   NH
26. 495-21044 [1]   WASHER,3/8"   CAS Superseded by part number: 87779090, 80702
27. 80679 [2]   LOCK WASHER,1/20.507 CST ZND   NH
28. 825-1410 [1]   NUT,M10, Cl 8   CAS Superseded by part number: 100016
29. 811-12030 [1]   CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 30mm, Cl 8.8   CAS Superseded by part number: 120044
31. 829-1412 [1]   NUT,M12, Cl 10.9   CAS Superseded by part number: 337475
32. 86636884 [1]   BAR   NH
34. 814-10040 [1]   BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8   CAS Superseded by part number: 120112
35. 425-106 [2]   NUT,3/8"-16, Cl 5   CAS Superseded by part number: 9628503
37. 183356 [1]   EYEBOLT,3/8" - 16 x 10" L   NH G2, 3/8"-16 x 10-1/8"
38. 86512547 [1]   SPRING,Extension, 1.94" OD x 13 - 1/8" L   NH Extension
39. 86624825 [1]   ARM   NH
40. 87032323 [1]   SPROCKET   PA Half & Sprocket, 22T
41. 80717 [1]   LUBE NIPPLE,45 Degree, 1/8" NPT x 7/8" lg   NH
42. 86601368 [2]   BUSHING   NH Superseded by part number: 86977429
43. 9808110 [2]   WASHER,46mm ID x 60mm OD x 1.64mm Thk   NH Hardened, M45
44. 100-11162 [1]   SNAP RING,#162, Ext   CAS Superseded by part number: 45440
45. 87028608 [1]   CLUTCH   NH Half
46. 86640119 [1]   SPRING,Compression, 2.438" OD x 4.5" L   NH
47. 9829364 [1]   CAP COVER   NH End
48. 9849862 [1]   BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5   NH HH, Drilled, G5, 1/2"-13 x 1-1/2"
49. 9804060 [1]   CHAIN,80, 158 Links x 25.4mm = 4013.2mm   NH RC80, 1"-pitch, 158 Pitches
49. 9620569 [1]   CONNECTING LINK,RC80, 1 Link x 25.4mm = 25.4mm L   NH 80K Superseded by part number: 241-1418
50. 86634530 [1]   HUB   NH
51. NS [1]   NOT SERVICED   BAS SPROCKET 13T, Plastic, Production Only {87050058}
51. 66614 [1]   SPROCKET,RC80, 13T   NH 13T,Steel, Service Only, Includes: Bearing 144819C91 Superseded by part number: 84401598
53. 280656 [1]   CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 3 1/4", Gr 5   NH
54. 434-1044 [1]   CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 2 3/4", Gr 5   NH Superseded by part number: 280560
55. 492-11062 [2]   BEARING WASHER,5/8"   CAS Superseded by part number: 86729275
56. 425-1010 [1]   NUT,5/8"-11, G5   CAS Superseded by part number: 280374
57. 280637 [1]   CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 3", Gr 5   NH
58. 681659 [1]   SPACER   NH
59. 86584050 [2]   IDLER   NH Chain Superseded by part number: 87030996
60. 86508756 [1]   CARRIAGE BOLT   NH Carriage, Short Neck, G5, 1/2"-13 x 4"
61. 495-21056 [1]   WASHER,1/2"   CAS Superseded by part number: 72187265, 80700
62. 231-4148 [1]   NUT,1/2"-13, GB   CAS Superseded by part number: 86992215
65. 86637258 [3]   TUBE,19.05 mm OD x 228.60 mm L   NH
66. 86618710 [2]   SPRING,1-3/8" OD x 8-5/8" L   NH Compression
67. 86637254 [2]   ROD   NH
69. 433-828 [1]   CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5   CAS Superseded by part number: 88530
70. 232-4148 [2]   NUT,1/2"-13, GC   CAS Superseded by part number: 86992215
71. 76615 [1]   SPACER   NH Superseded by part number: 87010766
72. 27318 [1]   WASHER,26mm ID x 51mm OD x 1.5mm Thk   NH .060" Thick
73. 33298 [1]   WASHER,16.7mm ID x 41.3mm OD x 4.78mm Thk   NH 1-5/8"
75. 280667 [1]   CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 2 1/4", Gr 5   NH
77. 495-11066 [1]   WASHER,5/8", SAE   CAS Superseded by part number: 87365
78. 149261C91 [1]   BALL BEARING,16mm ID x 40mm OD x 18mm W   IH
79. 86637277 [1]   ARM   NH
81. 86637270 [1]   DRIVEN SPROCKET   NH 39T, Wide Pickup
82. 86518073 [1]   CHAIN,60H, 82 Links x 19.05mm = 1562.1mm   NH RC60H, 3/4"-pitch, 82 Pitches
83. 86637392 [1]   DRIVEN SPROCKET   NH 20T, Includes Ref. 119
84. 86637256 [1]   DRIVING SPROCKET   NH 25T
85. 9804061 [1]   CHAIN,80, 84 Links x 25.4mm = 2133.6mm   NH RC 80, 1"-pitch, 84 Pitches
86. 86636671 [1]   PLATE   NH Mounting
90. 832-46412 [1]   NUT,M12 x 1.75, Cl 8   CAS Superseded by part number: 100038
91. 86637291 [1]   SPACER   NH
92. 614-12040 [1]   BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd   IH Superseded by part number: 86629541
93. 694478 [4]   WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk   NH Hardened, 1/2"
95. 492-11044 [1]   LOCK WASHER,7/16"   CAS Superseded by part number: 81547
96. 86637248 [1]   DRIVEN SPROCKET   NH 18T
97. 86636633 [1]   WASHER,42.86mm ID x 57.15mm OD x 1.52mm Thk   NH 2-1/4" OD
99. 86514717 [1]   IDLER WHEEL   NH Nylon
100. 814-12090 [1]   BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8   CAS Superseded by part number: 86508581
103. 86636635 [1]   SPACER   NH
104. 9807783 [1]   BEARING ASSY,3.238" ID x 3.73" OD x 1"   NH Includes: Bearings
108. 131377 [1]   COLLAR   NH
109. 39856 [1]   WASHER,13.49mm ID x 38.1mm OD x 6.35mm Thk   NH 1/2"
110. 9845608 [1]   BLOCK   NH
112. 9636698 [1]   NUT,1/2"-13, GB   NH Superseded by part number: 88871
113. 86637304 [1]   BRACKET   NH
114. 433-848 [1]   CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 5   CAS Superseded by part number: 80280818
116. 140045 [1]   BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk   NH
117. 838-5526 [1]   LOCK PIN,M5 x 26, Slotted   CAS Superseded by part number: 82848074, 130045
119. 46962 [1]   BUSHING,2" ID x 2.13" OD x 1.25" L   NH
