| 1. |
84213594
|
[1] |
FRAME
|
SAS
Air Tube
|
| 2. |
84213601
|
[3] |
|
|
| 3. |
GL-603
|
[1] |
PIVOT PIN
|
FLX
center manifold lift - front
|
| 4. |
87325444
|
[2] |
WASHER,1.02" ID x 1.5" OD x 0.07" Thk
|
SAS
1 1/64" id 1 1/2" 14ga
|
| 5. |
5868
|
[2] |
WASHER,0.5" ID x 1" OD x 0.06" Thk
|
FLX
1/2" id 1" 16ga
|
| 6. |
87689
|
[2] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 7. |
86992215
|
[2] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 8. |
GL-103
|
[1] |
PIVOT PIN
|
FLX
center manifold lift - rear
|
| 9. |
84466864
|
[1] |
PANEL
|
SAS
Hose Collector
|
| 10. |
9635884
|
[6] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
|
| 11. |
80664
|
[6] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 12. |
280736
|
[6] |
NUT,5/16"-18, GC
|
NH
|
| 13. |
9637692
|
[4] |
NUT,3/8"-16, GB
|
NH
|
| 14. |
CC-105
|
[4] |
HOSE CLAMP
|
FLX
for 2 hoses
|
| 15. |
87506228
|
[1] |
HYDRAULIC VALVE
|
SAS
1 spool
|
| 16. |
87404
|
[2] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
PA
|
| 17. |
280129
|
[8] |
NUT,1/4"-20
|
NH
|
| 18. |
21346
|
[1] |
HOOK
|
FLX
c shape Superseded by part number: 82987584
|
| 19. |
280236
|
[3] |
COTTER PIN,1/16" x 1/2"
|
WIN
|
| 20. |
8632
|
[1] |
CLEVIS PIN
|
FLX
1/4" x 3/4" fl
|
| 21. |
GL-114
|
[1] |
HANDLE
|
FLX
control valve
|
| 22. |
9534
|
[1] |
SPECIAL BOLT
|
FLX
l-shaped lock up
|
| 23. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 24. |
9460
|
[1] |
CAP
|
FLX
1/4" x 1 1/4" x 3"
|
| 25. |
84213613
|
[1] |
ROCKSHAFT
|
SAS
Center Manifold
|
| 26. |
87364
|
[20] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 27. |
9637916
|
[10] |
BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 5
|
NH
|
| 28. |
280980
|
[10] |
NUT,7/16"-14, GC
|
NH
|
| 29. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 30. |
GL-905
|
[3] |
PLATE
|
FLX
AIR CONTROL HANDLE BEARING
|
| 31. |
51200077
|
[3] |
BUSHING
|
FLX
flange, nyliner 13/16" x 75 x .14 split
|
| 32. |
87361
|
[6] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
| 33. |
9707580
|
[6] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 34. |
23235
|
[1] |
HOSE
|
SAS
1 3/4" x 50' flexthane black
|
| 37. |
84674
|
[6] |
HOSE CLAMP,33.3mm - 57.1mm, Worm Gear
|
WIN
|
