| 1. |
84388675
|
[1] |
ECU
|
SAS
|
| . . |
84388675R
|
[1] |
REMAN-INSTR CLUSTER
|
SAS
3580 (3/10-)
|
| . . |
84388675C
|
[1] |
CORE-CLUSTER, INSTR
|
SAS
Return Number
|
| 2. |
280492
|
[2] |
BOLT,Hex, 1/4" - 20 x 3 1/2", Gr 5
|
GI
|
| 3. |
80701
|
[2] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 4. |
80682
|
[2] |
LOCK WASHER,1/4"
|
PA
|
| 5. |
7770
|
[2] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 6. |
84249760
|
[1] |
BRACKET
|
SAS
Switch Mount Multiple
|
| 7. |
87872
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
NH
|
| 8. |
280736
|
[2] |
NUT,5/16"-18, GC
|
NH
|
| 9. |
84307649
|
[1] |
SWITCH
|
SAS
Calibration Superseded by part number: 47739163
|
| 10. |
87641950
|
[3] |
SWITCH
|
SAS
meter on/off - *NOTE* IF SWITCH HAS INLINE FUSE ORDER PART NUMBER 13924 Superseded by part number: 47737283
|
| 11. |
21304
|
[4] |
SELF-TAP SCREW
|
FLX
#6-32 x 5/16"
|
| 12. |
51200136
|
[1] |
BATTERY BOX
|
FLX
with strap and lid Superseded by part number: ZQC120171001
|
| 12. |
B2472W
|
[1] |
WET BATTERY
|
IH
US Only - Not Illustrated
|
| 12. |
CC2472W
|
[1] |
WET BATTERY
|
MKT
Canada Only - Not Illustrated
|
| 13. |
GL-283
|
[1] |
TRAY
|
FLX
mount, battery - swivel
|
| 15. |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 16. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 17. |
86523851
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
WIN
|
| 18. |
6854
|
[1] |
PIN
|
FLX
quick - 1/4" x 2 1/2" usable
|
| 19. |
9966
|
[1] |
RELAY
|
FLX
electrical, 12 volt
|
| 20. |
51200085
|
[1] |
RIVET
|
FLX
pop 3/16" x 7/16"
|
| 21. |
412731A1
|
[1] |
CLAMP
|
FLX
cable, nylon
|
| 22. |
4285
|
[2] |
WASHER
|
FLX
3/4" id 18ga Superseded by part number: 87326958
|
| 23. |
419978A1
|
[1] |
HARNESS
|
FLX
lighting, cart, tow behind Superseded by part number: 15475
|
| 24. |
419982A1
|
[1] |
HARNESS
|
FLX
alternator VR air cart
|
| 25. |
84213650
|
[1] |
HARNESS
|
SAS
Tow Behind, Air Cart
|
| 26. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
electronic control unit
|
