| 1. |
84205381
|
[1] |
HOUSING
|
SAS
4 1/2" Axle, RH
|
| 2. |
84205385
|
[1] |
HOUSING
|
SAS
4 1/2" Axle, LH
|
| 3. |
84205409
|
[2] |
TUBE,211 mm L
|
SAS
Tie Rod Superseded by part number: 280375, 9861, ST2111, A50532, 84249764, 9863\C, 88043, 86977740, 87334418, 86577093, 86523960, 84544029, 84572240, 84544457, 86528705, 84544455, 9864, 9790660, 9869, 86639566, 84544043, 87530607, 84205400, 84205398, 84205381, 80752, 84546010, 426-1472, 4219, 280658, 280223, 22792, 84551188, 280183, 1027683
|
| 4. |
87506222
|
[2] |
WHEEL ASSY
|
SAS
30.5lx32 r3 10h +0.0
|
| 5. |
84213741
|
[2] |
HUB ASSY w spindle
|
|
| 6. |
429-2912
|
[20] |
FLANGE NUT,Flg, 3/4"-16, G8
|
CAS
Superseded by part number: 9790660
|
| 7. |
4219
|
[2] |
WASHER
|
FLX
2.062 ID 4.250 X 0.188
|
| 8. |
280223
|
[2] |
BOLT,Hex, 3/4"-10 x 6 1/2", G5
|
GI
|
| 9. |
426-1472
|
[2] |
BOLT,Hex, 7/8" - 9 x 4-1/2", Gr 8
|
CAS
Superseded by part number: 47390930
|
| 10. |
280375
|
[2] |
NUT,3/4"-10, GC
|
WIN
|
| 11. |
280658
|
[2] |
NUT,7/8"-9, GB
|
GI
|
| 12. |
84205400
|
[2] |
PIN
|
SAS
50.8 mm x 461 mm ul
|
| 14. |
86639566
|
[2] |
NUT,5/8"-11, GB
|
FOR
|
| 15. |
87490803
|
[2] |
BOLT
|
SAS
Hex, 7/8"-9 x 7 1/2", G5
|
| 17. |
84205418
|
[2] |
SPACER
|
SAS
Spacer 28.58 mm od x 23.04 mm id x 20.5 mm Long
|
| 18. |
86624165
|
[2] |
WASHER,0.91" ID x 1.25" OD x 0.06" Thk
|
FOR
|
| 19. |
84205416
|
[4] |
SPACER
|
SAS
Spacer 28.58 mm od x 23.04 mm id x 9.5 mm Long
|
| 20. |
84205404
|
[4] |
END
|
SAS
Tie Rod, 22.225 mm id
|
| 21. |
1460
|
[4] |
JAM NUT
|
FLX
jam 7/8" Superseded by part number: 86636806
|
