| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
HYD HOSE TBH CART PRESSURE
|
| 5. |
22517
|
[2] |
LINE
|
FLX
hydraulic 1/2" od x 31" ~ 1/2" fjic x 1/2" fjic
|
| 6. |
84268227
|
[2] |
HYD TUBE,12.70 mm OD x 1550 mm L
|
SAS
12.7 mm x 1550 mm
|
| 8. |
412764A1
|
[1] |
HYDRAULIC VALVE,3/8" FPT x 3/8" FPT
|
FLX
ball 3/8" fpt
|
| 9. |
22447
|
[3] |
VALVE
|
FLX
1 1/4" gpm p. comp deltrol pressure compensated
|
| 13. |
87504025
|
[1] |
FILTER
|
SAS
hyd in-line 8forb 25 m
|
| 14. |
21395
|
[2] |
FITTING
|
FLX
3/8" mpt x 1/4" mjic with .0313" orifice
|
| 15. |
22448
|
[3] |
FITTING
|
FLX
hydraulic - straight adapter 3/8" morb x 3/8" morb
|
| 16. |
412756A1
|
[1] |
FITTING
|
FLX
1/2" mb 1/2" fjx Superseded by part number: 87698808
|
| 17. |
76350
|
[11] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
|
| 18. |
128996
|
[5] |
TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC
|
WIN
|
| 19. |
216791
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree
|
PA
|
| 21. |
235131
|
[1] |
90 ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/8"-18, NPTF
|
WIN
|
| 22. |
128818
|
[1] |
UNION,3/4" - 16 ORB x 3/4" - 16 JIC
|
BHB
|
| 23. |
86513087
|
[1] |
FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree
|
WIN
|
| 24. |
86533577
|
[1] |
HYD CONNECTOR
|
BEL
#6 9/16-18 37º 3/8-18
|
| 25. |
FLX3169
|
[4] |
CLAMP
|
FLX
plastic, hydraulic tube Superseded by part number: 84307616
|
| 26. |
87936
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
|
NH
|
| 27. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 28. |
9637692
|
[3] |
NUT,3/8"-16, GB
|
NH
|
| 30. |
CC-106
|
[1] |
HOSE CLAMP
|
FLX
for 4 hoses
|
| 31. |
9358
|
[2] |
QUICK MALE COUPLING,1" - 11.5 NPTF
|
FLX
1"
|
| 32. |
9412
|
[1] |
QUICK MALE COUPLING
|
FLX
1/2" Superseded by part number: 9801618
|
| 33. |
GL-700.32
|
[1] |
DECAL
|
FLX
fan pressure
|
| 34. |
GL-700.33
|
[1] |
DECAL
|
FLX
fan return
|
| 35. |
GL-700.42
|
[1] |
DECAL
|
FLX
drain
|
| 36. |
87500077
|
[2] |
HYDRAULIC HOSE,25.4mm ID x 6401mm L, SAE 100R17
|
SAS
1" x 252" fl Superseded by part number: 47613762
|
| 37. |
87500627
|
[1] |
HYDRAULIC HOSE,19mm ID x 5512mm L
|
SAS
3/4" x 217" fl, 1/2" mpt x 1/2" fjic Superseded by part number: 47698270
|
