凯斯零件查询(3555) - PRECISION AIR CART (11/15-) (77.100.XX[20]) - CONVEYOR TAIL Case Agriculture

作者：广数供应链运营团队

浏览数：

时间：2025-01-25 03:06:37

Pos.	Part No	Qty	Parts name	Comments
1.	47686591	[2]	FLANGE	SAS BLOCK 1 1/4" SHAFT BEARING 8" CONVE
2.	84056369	[1]	BOLT,Hex, M16 x 300mm, Cl 8.8	ZED
3.	47751992	[4]	BLOCK	SAS FLANGE BLOCK 1" SHAFT BEARING
4.	47753227	[1]	SPROCKET	SAS Idler
5.	47753226	[1]	SPROCKET	SAS 1" BORE W/KEYWAY
6.	47686592	[1]	DRUM	SAS DRIVE ROLLER, 5"
7.	47753225	[1]	SPROCKET	SAS 1-1/4" BORE W/KEYWAY
8.	47686596	[1]	ROLLER	SAS IDLER ROLLER, 3"
9.	47686597	[1]	ROLLER	SAS DRIVE ROLLER, 3"
10.	47751964	[1]	COVER	SAS TAIL BOX TRANSITION
11.	47752007	[1]	GUARD	SAS LOWER DRIVE
12.	47686620	[2]	PLATE	SAS CONNECTOR
13.	47686631	[1]	PLATE	SAS TAIL BOX TRANSITION
14.	47686643	[1]	BRACKET	SAS TAIL
15.	NS	[2]	NOT SERVICED	BAS 3" DRIVE ROLLER GUIDE
16.	47751854	[1]	MOUNT	SAS TAIL CLEANOUT MOUNT
17.	47686650	[1]	PLATE	SAS 3" DRIVE ROLLER GUIDE
18.	47751996	[1]	COVER	SAS HOLD DOWN, FLAP LEFT
19.	47751998	[1]	COVER	SAS HOLD DOWN, FLAP RIGHT
20.	47686652	[2]	ROLLER	SAS 5" ROLLER GUIDE
21.	47686656	[2]	MOUNT	SAS 5" BEARING MOUNT
22.	47751940	[1]	COVER	SAS TAIL REAR FLAP
23.	47752001	[1]	COVER	SAS FLAP, HOPPER BACK
24.	47751969	[2]	COVER	SAS FLAP, HOPPER SIDE
25.	47686658	[1]	MOUNT	SAS BOX FLAP MOUNT LEFT
26.	47686659	[1]	PILLOW BLOCK	SAS BOX FLAP MOUNT RIGHT
27.	47686661	[1]	HANDLE	SAS HOPPER HANDLE RIGHT
28.	47752014	[2]	SUPPORT	SAS HOPPER RIM
29.	47752017	[1]	SUPPORT	SAS HOPPER RIM END
30.	47752018	[1]	HANDLE	SAS HANDLE LATCH PLATE
31.	47686670	[1]	HANDLE	SAS HANDLE LATCH PIN
32.	47752020	[1]	HANDLE	SAS HANDLE LATCH, UPPER STOP
33.	47686669	[1]	HANDLE	SAS HOPPER HANDLE, LOWER STOP
35.	47751923	[1]	MOUNT	SAS INCLINE CLEANOUT MOUNT ASSY
36.	47751938	[1]	MOUNT	SAS INCLINE CLEANOUT DOOR
37.	47751920	[1]	HANDLE	SAS HOPPER HANDLE LEFT
38.	47751896	[1]	DOOR	SAS TAIL CLEANOUT DOOR
39.	47894227	[1]	COVER	SAS FLOWGUARD FLAP
40.	47752010	[1]	SUPPORT	SAS FLOWGUARD SUPPORT
41.	47752015	[1]	SCREEN	SAS 2"x 2"
42.	47752002	[2]	STRAP	SAS STRAP, SIDE
43.	47752000	[1]	STRAP	SAS STRAP, END
45.	47752009	[1]	CANVAS	SAS Hopper
46.	86512520	[7]	BOLT,Hvy Hex, M8 x 12mm, Cl 8.8, Full Thd	WIN For #10
47.	86511842	[14]	BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8	NH For 19,22,24,41,42
48.	9804277	[14]	FLANGE NUT,Hex, M8 x 1.25, Cl 8	NH For 19,22,24,41,42 Superseded by part number: 86505868
49.	86508568	[4]	BOLT,Hex, M6 x 1 x 16mm, Cl 8.8	NH For Plate #12
50.	86619800	[4]	FLANGE NUT,M6 x 1, Cl 8	RAC For Plate #12
