| 1. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 2. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
|
| 3. |
86632583
|
[4] |
WASHER,1.28" ID x 2" OD x 0.12" Thk
|
FOR
|
| 4. |
1313
|
[3] |
WASHER,1-1/2" ID x 2-1/4" OD x 10 Ga Thk
|
FLX
1 1/2" id 2 1/4" 10ga Superseded by part number: 81900328
|
| 5. |
88557
|
[1] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5, Full Thd
|
BEL
|
| 6. |
9706701
|
[2] |
BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5
|
PA
|
| 7. |
9706716
|
[1] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
NH
|
| 8. |
280954
|
[3] |
NUT,3/4"-10, G5
|
NH
|
| 9. |
281010
|
[1] |
LOCK NUT,7/8"-14, GC
|
BAS
|
| 10. |
86992215
|
[1] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 11. |
87340
|
[3] |
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
|
NH
|
| 12. |
81541
|
[5] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 13. |
87337
|
[3] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
NH
|
| 14. |
280375
|
[1] |
NUT,3/4"-10, GC
|
WIN
|
| 15. |
86511191
|
[3] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 16. |
88964
|
[1] |
BOLT,Hex, 5/16" - 18 x 4", Gr 5
|
PA
|
| 17. |
3419
|
[1] |
CAP
|
FLX
vinyl 1 5/8" x 1 1/2"
|
| 18. |
87577
|
[2] |
LOCK PIN,9.53mm OD x 50.8mm L, Slotted
|
NH
Superseded by part number: 86624061
|
| 19. |
86632557
|
[2] |
JAM NUT,Jam, 3/4"-10, G5
|
GFD
|
| 20. |
86624087
|
[4] |
PIN,1/4" x 1 3/4", Coiled
|
FOR
Superseded by part number: 86624099
|
| 21. |
87325445
|
[6] |
WASHER,1.25" ID x 1.88" OD x 0.07" Thk
|
SAS
1 1/4" id 1 7/8" 14ga
|
| 23. |
6567
|
[1] |
DECAL
|
FLX
grease 200 hours
|
| 24. |
6630
|
[1] |
DECAL
|
FLX
grease 100 hours
|
| 25. |
6717
|
[1] |
BOLT,Hex, 3/4" - 10 x 5", Gr 5, Full Thd
|
FLX
|
| 27. |
8670
|
[8] |
RIVET,Pop, 3/16" OD x 3/4" L
|
FLX
pop 3/16" x 3/4"
|
| 28. |
9478
|
[1] |
WEAR PLATE
|
FLX
lower auger support
|
| 29. |
51200862
|
[1] |
WEAR STRIP
|
FLX
auger saddle - rear Superseded by part number: GL-656A
|
| 30. |
87506268
|
[1] |
COIL SPRING
|
SAS
1/16" wire x 3/4" od x 2 1/2" long
|
| 31. |
21574
|
[1] |
WASHER
|
FLX
31/64" id 19/32" 1/16"
|
| 32. |
CA-218
|
[1] |
CLAMP
|
FLX
auger tube
|
| 33. |
GL-253
|
[1] |
BRACKET
|
FLX
spring
|
| 34. |
GL-490
|
[1] |
SUPPORT
|
FLX
rear
|
| 35. |
GL-492
|
[1] |
LATCH
|
FLX
front, bottom saddle
|
| 36. |
GL-494
|
[1] |
ARM
|
FLX
lock front auger
|
| 37. |
GL-656A
|
[1] |
SADDLE
|
SAS
Auger, Complete with Poly Liner and Rivets
|
| 38. |
GL-750
|
[1] |
CLAMP
|
FLX
auger bottom
|
| 39. |
GL-751
|
[1] |
LINK
|
FLX
auger clamp front auger saddle
|
| 40. |
GL-756
|
[1] |
CLAMP
|
FLX
lock auger front saddle
|
| 41. |
GL-791
|
[1] |
HEADLESS PIN
|
FLX
lower auger support - long
|
| 42. |
GL-792
|
[1] |
HEADLESS PIN
|
FLX
lower auger support - short
|
| 43. |
GL-796
|
[1] |
LOCK
|
FLX
front, auger support
|
| 44. |
GL-820
|
[1] |
BRACKET
|
FLX
Auger Support Rear Superseded by part number: 47410514
|
| 45. |
GL-700.04
|
[1] |
DECAL
|
FLX
auger brake
|
