| 1. |
88206
|
[6] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 2. |
80702
|
[3] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 3. |
80755
|
[4] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 4. |
80680
|
[11] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 5. |
86500692
|
[4] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd
|
IMO
|
| 6. |
9628503
|
[6] |
NUT,3/8"-16, G5
|
NH
|
| 7. |
86508773
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
NH
|
| 8. |
6909
|
[1] |
KNOB
|
FLX
plastic 4-prong 3/8" thru hole brass insert
|
| 9. |
9148
|
[4] |
LOCK NUT
|
FLX
#10-32, stainless steel
|
| 10. |
9460
|
[1] |
CAP
|
FLX
1/4" x 1 1/4" x 3"
|
| 11. |
51200020
|
[4] |
SCREW
|
FLX
#10-32 x 1 1/4", stainless steel
|
| 12. |
87020816
|
[1] |
LOCK PIN,4.76mm OD x 31.75mm L
|
EML
|
| 13. |
51200897
|
[4] |
LINKAGE YOKE
|
FLX
clevis 3/8" x 2 1/2" long
|
| 14. |
9834
|
[4] |
CLEVIS PIN
|
FLX
3/8" x 1 1/16"
|
| 15. |
51200068
|
[2] |
DAMPER
|
FLX
air control valve
|
| 16. |
51200078
|
[2] |
PIPE UNION NUT
|
FLX
coupling 3/8"-16 x 1 1/8", G2
|
| 17. |
GI-319
|
[1] |
MOUNTING PLATE
|
FLX
air control decal
|
| 18. |
GI-500.16
|
[1] |
DECAL
|
FLX
air control
|
| 19. |
GI-681
|
[2] |
BODY
|
FLX
air valve
|
| 20. |
GI-682
|
[1] |
ROD
|
FLX
control, long - 3rd tank
|
| 21. |
GI-683
|
[2] |
ROD
|
FLX
air valve pivot 3rd tank
|
| 22. |
GI-684
|
[1] |
ARM
|
FLX
control, air control option
|
| 23. |
GI-685
|
[1] |
ARM
|
FLX
short control 3rd tank
|
| 24. |
GI-686
|
[1] |
CONTROL PANEL
|
FLX
3rd tank
|
| 25. |
GI-687
|
[1] |
LINK
|
FLX
control, 3rd tank
|
| 26. |
GL-700.24
|
[1] |
DECAL
|
FLX
air control pointer
|
